Articles: By Dr. Ethan Siegel The solar system is a busy place, with five wandering planets visible to the naked eye alone. When any two pass close by each other from our point of view, we see an astronomical conjunction, but on very rare occasions, three planets will find themselves grouped together: a triple conjunction. Towards the end of May, Mercury, Venus and Jupiter will treat us to the best triple conjunction in years. On May 25th, Mercury will pass within 1.4° of Venus, then two days later Mercury comes within 2.4° of Jupiter, and finally on the 28th, Jupiter and Venus approach within 1° of one another. If it weren’t for the slight orbital tilt of our solar system’s planetary orbits, these conjunctions would all be occultations instead. During the nights of May 26th-27th, all three planets are visible immediately after sunset within the same 3° field of view, with the triple conjunction peaking in a triangular shape on the 26th. (For scale, the full Moon subtends about 1/2°.) The three planets appear close together for a few days more, making a line in the sky on the 30th/31st. How does this happen? Mercury and Venus race around the Sun far faster than Earth, with Mercury completing more than four revolutions around the Sun for each one that Earth makes. At the same time, Jupiter is far slower, taking 12 years to orbit just once around the Sun. Jupiter’s been high in the sky during the early parts of the night, but steadily lowers throughout May as Earth continues to move away from it, approaching its maximum distance from Earth. Mercury and Venus, meanwhile, begin to move out from behind the Sun during May: Venus at the beginning of the month and Mercury in the middle. Thus, during this triple conjunction, all three planets will be on the far side of the Sun, something that happens just 25% of the time in triple conjunctions involving Mercury and Venus! If you telescopically resolve these planets into disks, you’ll see our inner worlds in a nearly-full gibbous phase. Jupiter will appear largest in terms of angular diameter, followed by Venus and lastly by Mercury. Just a year ago, during its now-famous transit, Venus took up more than a full arc-minute in the sky; during this conjunction, it will just one-sixth that angular size and less than a third the apparent diameter of Jupiter. Nevertheless, Venus will still be more than six times as bright as Jupiter during this time, outshining all night-sky objects other than the Moon. Closer conjunctions of two naked-eye planets are frequent, but getting three or more like this happens just once or twice per decade, so don’t miss your chance to see it. And speaking of occultations, The Space Place has a great kid-friendly explanation of the Venus transit and solar eclipses of 2012 at http://spaceplace.nasa.gov/venus-transit. Dr. Ethan Siegel, a theoretical astrophysicist, is a professor at the University of Portland (OR) and Lewis & Clark College. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The image shows the configuration of Mercury, Venus, and Jupiter in the western sky just after sunset on May 26, 2013. Insets show the relative size appearance of the planets on that date. Exploring the Water WorldBy Diane K. Fisher In some ways, we know more about Mars, Venus and the Moon than we know about Earth. That’s because 70% of our solar system’s watery blue planet is hidden under its ocean. The ocean contains about 98% of all the water on Earth. In total volume, it makes up more than 99% of the space inhabited by living creatures on the planet. As dominant a feature as it is, the ocean—at least below a few tens of meters deep—is an alien world most of us seldom contemplate. But perhaps we should. The ocean stores heat like a “fly wheel” for climate. Its huge capacity as a heat and water reservoir moderates the climate of Earth. Within this Earth system, both the physical and biological processes of the ocean play a key role in the water cycle, the carbon cycle, and climate variability. This great reservoir continuously exchanges heat, moisture, and carbon with the atmosphere, driving our weather patterns and influencing the slow, subtle changes in our climate. The study of Earth and its ocean is a big part of NASA’s mission. Before satellites, the information we had about the ocean was pretty much “hit or miss,” with the only data collectors being ships, buoys, and instruments set adrift on the waves. Now ocean-observing satellites measure surface topography, currents, waves, and winds. They monitor the health of phytoplankton, which live in the surface layer of the ocean and supply half the oxygen in the atmosphere. Satellites monitor the extent of Arctic sea ice so we can compare this important parameter with that of past years. Satellites also measure rainfall, the amount of sunlight reaching the sea, the temperature of the ocean’s surface, and even its salinity! Using remote sensing data and computer models, scientists can now investigate how the oceans affect the evolution of weather, hurricanes, and climate. In just a few months, one satellite can collect more information about the ocean than all the ships and buoys in the world have collected over the past 100 years! NASA’s Earth Science Division has launched many missions to planet Earth. These satellites and other studies all help us understand how the atmosphere, the ocean, the land and life—including humans—all interact together. Find out more about NASA’s ocean studies at http://science.nasa.gov/earth-science/oceanography. Kids will have fun exploring our planet at The Space Place, http://spaceplace.nasa.gov/earth. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This image from September 2012, shows that the Arctic sea is the smallest recorded since record keeping began in 1979. This image is from NASA’s Scientific Visualization Studio at Goddard Space Flight Center. Your Daily Dose of AstonishmentBy Diane K. Fisher As a person vitally interested in astronomy, you probably have the Astronomy Picture of the Day website at apod.nasa.gov set as favorite link. APOD has been around since practically the beginning of the web. The first APOD appeared unannounced on June 16, 1995. It got 15 hits. The next picture appeared June 20, 1995, and the site has not taken a day off since. Now daily traffic is more like one million hits. Obviously, someone is responsible for picking, posting, and writing the detailed descriptions for these images. Is it a whole team of people? No. Surprisingly, it is only two men, the same ones who started it and have been doing it ever since. Robert Nemiroff and Jerry Bonnell shared an office at NASA’s Goddard Space Flight Center in the early-90s, when the term “World Wide Web” was unknown, but a software program called Mosaic could connect to and display specially coded content on other computers. The office mates thought “we should do something with this.” Thus was conceived the Astronomy Picture of the Day. Now, in addition to the wildly popular English version, over 25 mirror websites in other languages are maintained independently by volunteers. (See http://apod.nasa.gov/apod/lib/about_apod.html for links). An archive of every APOD ever published is at http://apod.nasa.gov/apod/archivepix.html. Dr. Nemiroff also maintains a discussion website at http://asterisk.apod.com/. But how does it get done? Do these guys even have day jobs? Dr. Nemiroff has since moved to Michigan Technological University in Houghton, Michigan, where he is professor of astrophysics, both teaching and doing research. Dr. Bonnell is still with NASA, an astrophysicist with the Compton Gamma Ray Observatory Science Support Center at Goddard. APOD is only a very small part of their responsibilities. They do not collaborate, but rather divide up the calendar, and each picks the image, writes the description, and includes the links for the days on his own list. The files are queued up for posting by a “robot” each day. They use the same tools they used at the beginning: Raw HTML code written using the vi text editor in Linux. This simple format has now become such a part of the brand that they would upset all the people and websites and mobile apps that link to their feed if they were to change anything at this point. Where do they find the images? Candidates are volunteered from large and small observatories, space telescopes (like the Hubble and Spitzer), and independent astronomers and astro-photographers. The good doctors receive ten images for every one they publish on APOD. But, as Dr. Nemiroff emphasizes, being picked or not picked is no reflection on the value of the image. Some of the selections are picked for their quirkiness. Some are videos instead of images. Some have nothing to do with astronomy at all, like the astonishing August 21, 2012, video of a replicating DNA molecule. Among the many mobile apps taking advantage of the APOD feed is Space Place Prime, a NASA magazine that updates daily with the best of NASA. It’s available free (in iOS only at this time) at the Apple Store. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The January 20, 2013, Astronomy Picture of the Day is one that might fall into the “quirky” category. The object was found at the bottom of the sea aboard a Greek ship that sank in 80 BCE. It is an Antikythera mechanism, a mechanical computer of an accuracy thought impossible for that era. Its wheels and gears create a portable orrery of the sky that predicts star and planet locations as well as lunar and solar eclipses. Tackling the Really BIG QuestionsBy Diane K. Fisher How does NASA get its ideas for new astronomy and astrophysics missions? It starts with a Decadal Survey by the National Research Council, sponsored by NASA, the National Science Foundation, and the Department of Energy. The last one, New Worlds, New Horizons in Astronomy and Astrophysics was completed in 2010. It defines the highest-priority research activities in the next decade for astronomy and astrophysics that will “set the nation firmly on the path to answering profound questions about the cosmos.” It defines space- and ground-based research activities in the large, midsize, and small budget categories. The recommended activities are meant to advance three science objectives: 1. Deepening understanding of how the first stars, galaxies, and black holes formed, 2. Locating the closest habitable Earth-like planets beyond the solar system for detailed study, and 3. Using astronomical measurements to unravel the mysteries of gravity and probe fundamental physics. For the 2012-2021 period, the highest-priority large mission recommended is the Wide-field Infrared Survey Telescope (WFIRST). It would orbit the second Lagrange point and perform wide-field imaging and slitless spectroscopic surveys of the near-infrared sky for the community. It would settle essential questions in both exoplanet and dark energy research and would advance topics ranging from galaxy evolution to the study of objects within the galaxy and within the solar system. Naturally, NASA’s strategic response to the recommendations in the decadal survey must take budget constraints and uncertainties into account. The goal is to begin building this mission in 2017, after the launch of the James Webb Space Telescope. But this timeframe is not assured. Alternatively, a different, less ambitious mission that also addresses the Decadal Survey science objectives for WFIRST would remain a high priority. The Astrophysics Division is also doing studies of moderate-sized missions, including: gravitational wave mission concepts that would advance some or all of the science objectives of the Laser Interferometer Space Antenna (LISA), but at lower cost; X-ray mission concepts to advance the science objectives of the International X-ray Observatory (IXO), but at lower cost; and mission concept studies of probe-class missions to advance the science of a planet characterization and imaging mission. For a summary of NASA’s plans for seeking answers to the big astrophysics questions and to read the complete Astrophysics Implementation Plan (dated December 2012), see http://science.nasa.gov/astrophysics/. For kids, find lots of astrophysics fun facts and games on The Space Place, http://spaceplace.nasa.gov/menu/space/. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Clusters of galaxies collide in this composite image of “Pandora's Cluster.” Data (in red) from NASA's Chandra X-ray Observatory show gas with temperatures of millions of degrees. Blue maps the total mass concentration (mostly dark matter) based on data from the Hubble Space Telescope (HST), the European Southern Observatory's Very Large Telescope (VLT), and the Japanese Subaru telescope. Optical data from HST and VLT also show the constituent galaxies of the clusters. Such images begin to reveal the relationship between concentration of dark matter and the overall structure of the universe. The Art of Space ImageryBy Diane K. Fisher When you see spectacular space images taken in infrared light by the Spitzer Space Telescope and other non-visible-light telescopes, you may wonder where those beautiful colors came from? After all, if the telescopes were recording infrared or ultraviolet light, we wouldn’t see anything at all. So are the images “colorized” or “false colored”? No, not really. The colors are translated. Just as a foreign language can be translated into our native language, an image made with light that falls outside the range of our seeing can be “translated” into colors we can see. Scientists process these images so they can not only see them, but they can also tease out all sorts of information the light can reveal. For example, wisely done color translation can reveal relative temperatures of stars, dust, and gas in the images, and show fine structural details of galaxies and nebulae. Spitzer’s Infrared Array Camera (IRAC), for example, is a four-channel camera, meaning that it has four different detector arrays, each measuring light at one particular wavelength. Each image from each detector array resembles a grayscale image, because the entire detector array is responding to only one wavelength of light. However, the relative brightness will vary across the array. So, starting with one detector array, the first step is to determine what is the brightest thing and the darkest thing in the image. Software is used to pick out this dynamic range and to re-compute the value of each pixel. This process produces a grey-scale image. At the end of this process, for Spitzer, we will have four grayscale images, one for each for the four IRAC detectors. Matter of different temperatures emit different wavelengths of light. A cool object emits longer wavelengths (lower energies) of light than a warmer object. So, for each scene, we will see four grayscale images, each of them different. Normally, the three primary colors are assigned to these gray-scale images based on the order they appear in the spectrum, with blue assigned to the shortest wavelength, and red to the longest. In the case of Spitzer, with four wavelengths to represent, a secondary color is chosen, such as yellow. So images that combine all four of the IRAC’s infrared detectors are remapped into red, yellow, green, and blue wavelengths in the visible part of the spectrum. Download a new Spitzer poster of the center of the Milky Way. On the back is a more complete and colorfully-illustrated explanation of the “art of space imagery.” Go to http://spaceplace.nasa.gov/posters/#milky-way. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This image of M101 combines images from four different telescopes, each detecting a different part of the spectrum. Red indicates infrared information from Spitzer’s 24-micron detector, and shows the cool dust in the galaxy. Yellow shows the visible starlight from the Hubble telescope. Cyan is ultraviolet light from the Galaxy Evolution Explorer space telescope, which shows the hottest and youngest stars. And magenta is X-ray energy detected by the Chandra X-ray Observatory, indicating incredibly hot activity, like accretion around black holes. Partnering to Solve Saturn’s MysteriesBy Diane K. Fisher From December 2010 through mid-summer 2011, a giant storm raged in Saturn’s northern hemisphere. It was clearly visible not only to NASA’s Cassini spacecraft orbiting Saturn, but also astronomers here on Earth—even those watching from their back yards. The storm came as a surprise, since it was about 10 years earlier in Saturn’s seasonal cycle than expected from observations of similar storms in the past. Saturn’s year is about 30 Earth years. Saturn is tilted on its axis (about 27° to Earth’s 23°), causing it to have seasons as Earth does. But even more surprising than the unseasonal storm was the related event that followed. First, a giant bubble of very warm material broke through the clouds in the region of the now-abated storm, suddenly raising the temperature of Saturn’s stratosphere over 150 °F. Accompanying this enormous “burp” was a sudden increase in ethylene gas. It took Cassini’s Composite Infrared Spectrometer instrument to detect it. According to Dr. Scott Edgington, Deputy Project Scientist for Cassini, “Ethylene [C2H4] is normally present in only very low concentrations in Saturn’s atmosphere and has been very difficult to detect. Although it is a transitional product of the thermochemical processes that normally occur in Saturn’s atmosphere, the concentrations detected concurrent with the big ‘burp’ were 100 times what we would expect.” So what was going on? Chemical reaction rates vary greatly with the energy available for the process. Saturn’s seasonal changes are exaggerated due to the effect of the rings acting as venetian blinds, throwing the northern hemisphere into shade during winter. So when the Sun again reaches the northern hemisphere, the photochemical reactions that take place in the atmosphere can speed up quickly. If not for its rings, Saturn’s seasons would vary as predictably as Earth’s. But there may be another cycle going on besides the seasonal one. Computer models are based on expected reaction rates for the temperatures and pressures in Saturn’s atmosphere, explains Edgington. However, it is very difficult to validate those models here on Earth. Setting up a lab to replicate conditions on Saturn is not easy! Also contributing to the apparent mystery is the fact that haze on Saturn often obscures the view of storms below. Only once in a while do storms punch through the hazes. Astronomers may have previously missed large storms, thus failing to notice any non-seasonal patterns. As for atmospheric events that are visible to Earth-bound telescopes, Edgington is particularly grateful for non-professional astronomers. While these astronomers are free to watch a planet continuously over long periods and record their finding in photographs, Cassini and its several science instruments must be shared with other scientists. Observation time on Cassini is planned more than six months in advance, making it difficult to immediately train it on the unexpected. That’s where the volunteer astronomers come in, keeping a continuous watch on the changes taking place on Saturn. Edgington says, “Astronomy is one of those fields of study where amateurs can contribute as much as professionals.” Go to http://saturn.jpl.nasa.gov/ to read about the latest Cassini discoveries. For kids, The Space Place has lots of ways to explore Saturn at http://spaceplace.nasa.gov/search/cassini/. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This false-colored Cassini image of Saturn was taken in near-infrared light on January 12, 2011. Red and orange show clouds deep in the atmosphere. Yellow and green are intermediate clouds. White and blue are high clouds and haze. The rings appear as a thin, blue horizontal line. It Takes More Than Warm Porridge to Make a Goldilocks ZoneBy Diane K. Fisher The “Goldilocks Zone” describes the region of a solar system that is just the right distance from the star to make a cozy, comfy home for a life-supporting planet. It is a region that keeps the planet warm enough to have a liquid ocean, but not so warm that the ocean boils off into space. Obviously, Earth orbits the Sun in our solar system’s “Goldilocks Zone.” But there are other conditions besides temperature that make our part of the solar system comfortable for life. Using infrared data from the Spitzer Space Telescope, along with theoretical models and archival observations, Rebecca Martin, a NASA Sagan Fellow from the University of Colorado in Boulder, and astronomer Mario Livio of the Space Telescope Science Institute in Baltimore, Maryland, have published a new study suggesting that our solar system and our place in it is special in at least one other way. This fortunate “just right” condition involves Jupiter and its effect on the asteroid belt. Many other solar systems discovered in the past decade have giant gas planets in very tight orbits around their stars. Only 19 out of 520 solar systems studied have Jupiter-like planets in orbits beyond what is known as the “snow line”—the distance from the star at which it is cool enough for water (and ammonia and methane) to condense into ice. Scientists believe our Jupiter formed a bit farther away from the Sun than it is now. Although the giant planet has moved a little closer to the Sun, it is still beyond the snow line. So why do we care where Jupiter hangs out? Well, the gravity of Jupiter, with its mass of 318 Earths, has a profound effect on everything in its region, including the asteroid belt. The asteroid belt is a region between Mars and Jupiter where millions of mostly rocky objects (some water-bearing) orbit. They range in size from dwarf planet Ceres at more than 600 miles in diameter to grains of dust. In the early solar system, asteroids (along with comets) could have been partly responsible for delivering water to fill the ocean of a young Earth. They could have also brought organic molecules to Earth, from which life eventually evolved. Jupiter’s gravity keeps the asteroids pretty much in their place in the asteroid belt, and doesn’t let them accrete to form another planet. If Jupiter had moved inward through the asteroid belt toward the Sun, it would have scattered the asteroids in all directions before Earth had time to form. And no asteroid belt means no impacts on Earth, no water delivery, and maybe no life-starting molecules either. Asteroids may have also delivered such useful metals as gold, platinum, and iron to Earth’s crust. But, if Jupiter had not migrated inward at all since it formed father away from the Sun, the asteroid belt would be totally undisturbed and would be a lot more dense with asteroids than it is now. In that case, Earth would have been blasted with a lot more asteroid impacts, and life may have never had a chance to take root. The infrared data from the Spitzer Space Telescope contributes in unexpected ways in revealing and supporting new ideas and theories about our universe. Read more about this study and other Spitzer contributions at spitzer.caltech.edu. Kids can learn about infrared light and enjoy solving Spitzer image puzzles at http://spaceplace.nasa.gov/spitzer-slyder. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Our solar system is represented by the middle scenario, where the gas giant planet has migrated inward, but still remains beyond the asteroid belt. A Cosmic Tease: Trials of the Herschel Space Telescope Science TeamsBy Dr. Marc J. Kuchner Vast fields of marble-sized chunks of ice and rock spun slowly in the darkness this week, and I sat in the back of a grey conference room with white plastic tables spread with papers and laptops. I was sitting in on a meeting of an international team of astronomers gathered to analyze data from the Herschel Infrared Observatory. This telescope, sometimes just called Herschel, orbits the Sun about a million miles from the Earth. The meeting began with dinner at Karl’s house. Karl charred chorizo on the backyard grill while the airplanes dribbled into Dulles airport. Our colleagues arrived, jetlagged and yawning, from Germany, Sweden, and Spain, and we sat on Karl’s couches catching up on the latest gossip. The unemployment level in Spain is about twenty percent, so research funding there is hard to come by these days. That’s not nice to hear. But it cheered us up to be with old friends. The meeting commenced the next morning, as the vast fields of ice and rock continued to spin—shards glinting in the starlight. Or maybe they didn’t. Maybe they didn’t exist at all. You see, this team is looking at a series of images of stars taken by a device called a bolometer that is blind to ordinary starlight. Instead, the bolometer inside Herschel senses infrared light, a kind of light that we would probably refer to as heat if we could feel it. But the idea of pointing the bolometer at the stars was not to collect ordinary starlight. It was to measure heat coming from the vicinity of these stars, like an infrared security camera, in case there was something else to be found lurking nearby. And lo and behold, for a handful of stars, the bolometer measurements were off the charts! Maybe something was orbiting these stars. From the details of the bolometer readings—which channels lit up and so on—you would guess that this stuff took the form of majestic fields or rings of icy and rocky particles. It would be a new kind of disk, a discovery worth writing home to Madrid about. There are several teams of astronomers analyzing data from the Herschel Space Telescope. They call themselves by oddly inappropriate sounding acronyms: GASPS, DUNES, DEBRIS. For the time being, the scientists on these teams are the only ones with access to the Herschel data. But in January, all the data these teams are working on will suddenly be released to the public. So they are all under pressure to finish their work by then. The team whose meeting I was sitting in on would like to publish a paper about the new disks by then. But it’s not so simple. The stars that this team had measured were relatively nearby as stars go, less than a few hundred light years. But the universe is big, and full of galaxies of all kinds—a sea of galaxies starting from maybe a hundred thousand light years away, and stretching on and on. Maybe one of those background galaxies was lined up with each of the stars that had lit up the bolometer—fooling us into thinking they were seeing disks around these stars. The team argued and paced, and then broke for lunch. We marched to the cafeteria through the rain. Meanwhile, vast fields of marble-sized chunks of ice and rock spun slowly in the darkness. Or maybe they didn’t. What else did Herschel recently uncover? Find out at http://spaceplace.nasa.gov/comet-ocean. Dr. Marc J. Kuchner is an astrophysicist at the Exoplanets and Stellar Astrophysics Laboratory at NASA’s Goddard Space Flight Center. NASA’s Astrophysics Division works on big questions about the origin and evolution of the universe, galaxies, and planetary systems. Explore more at http://www.science.nasa.gov/astrophysics/. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Samuel Pierpoint Langley, who developed the bolometer in 1878. His instrument detects a broad range of infrared wavelengths, sensitive to differences in temperature of one hundred-thousandth of a degree Celsius (0.00001 C). In 1961, Frank Low developed the germanium bolometer, which is hundreds of times more sensitive than previous detectors and capable of detecting far-infrared radiation. Doing Science with a Spacecraft’s SignalBy David Doody Mariner 2 to Venus, the first interplanetary flight, was launched August 27 fifty years ago. This was a time when scientists were first learning that Venus might not harbor jungles under its thick atmosphere after all. A Russian scientist had discovered that atmosphere during the rare Venus transit of 1761, because of the effects of sunlight from behind. Mariner 2 proved interplanetary flight was possible, and our ability to take close-up images of other planets would be richly rewarding in scientific return. But it also meant we could use the spacecraft itself as a “light” source, planting it behind an object of our choosing and making direct measurements. Mariner 4 did the first occultation experiment of this sort when it passed behind Mars as seen from Earth in July 1965. But, instead of visible light from the Sun, this occultation experiment used the spacecraft’s approximately 2-GHz radio signal. The Mariner 4 experiment revealed Mars’ thin atmosphere. Since then, successful radio science occultation experiments have been conducted at every planet and many large moons. And another one is on schedule to investigate Pluto and its companion Charon, when the New Horizons spacecraft flies by in July 2015. Also, during that flyby, a different kind of radio science experiment will investigate the gravitational field. The most recent radio science occultation experiment took place September 2, 2012, when the Cassini spacecraft carried its three transmitters behind Saturn. These three different frequencies are all kept precisely “in tune” with one another, based on a reference frequency sent from Earth. Compared to observations of the free space for calibration just before ingress to occultation, the experiment makes it possible to tease out a wide variety of components in Saturn's ionosphere and atmosphere. Occultation experiments comprise only one of many categories of radio science experiments. Others include tests of General Relativity, studying the solar corona, mapping gravity fields, determining mass, and more. They all rely on NASA’s Deep Space Network to capture the signals, which are then archived and studied. Find out more about spacecraft science experiments in “Basics of Space Flight,” a website and book by this author, http://www2.jpl.nasa.gov/basics. Kids can learn all about NASA’s Deep Space Network by playing the “Uplink-Downlink” game at http://spaceplace.nasa.gov/dsn-game. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: In this poster art of Mariner 4, you can see the parabolic reflector atop the spacecraft bus. Like the reflector inside a flashlight, it sends a beam of electromagnetic energy in a particular direction. Credit: NASA/JPL/Corby Waste. A Brand New Age: Queue Observing at Mt. ParanalBy Dr. Marc J. Kuchner First a caravan of white observatory cars arrives, winding up the narrow road to the 2600-m- (~8500-foot-) high summit. Then the shutters around the domes open, and rays from the setting sun alight on colossal mirrors and metal struts. It’s the beginning of another busy night at Mt. Paranal, Chile, where I am learning about new, more efficient ways of managing a modern observatory. I stepped into the observatory’s control room to soak up some of the new, unfamiliar culture. Here, under florescent lights and drop ceilings are banks of computer screens, one bank to control each of the four big telescopes on the mountaintop and a few others too. At each bank sits two people, a telescope operator and an astronomer. The layout of this workspace was not unfamiliar to me. But the way these Mt. Paranal astronomers work certainly was. When I was cutting my teeth at Mt. Palomar observatory in California, I would only go to the telescope to take my own data. In stark contrast, everyone observing at Mt Paranal tonight is taking data for someone else. The Mt. Paranal astronomers each spend 105 nights a year here on the mountain performing various duties, including taking data for other astronomers. The latter, they call “executing the queue.” Headquarters in Germany decides what parts of the sky will have priority on any given night (the queue). Then the Mt. Paranal astronomers march up the mountain and carry out this program, choosing calibrators, filling the log books, and adapting to changing conditions. They send the data back to headquarters, and from there it makes its way out to the wider astronomical community for study. This new way of working allows the Mt. Paranal astronomers to specialize in just one or two telescope instruments each. Surely this plan is more efficient than the old-fashioned way, where each of us had to learn every instrument we used from scratch—sifting through manuals at 3:00 AM when the filter wheel got stuck or the cryogen ran out, watching precious observing time tick away. Here at Mt. Paranal, much of the work is done in a big room full of people, not off by yourself, reducing some dangers of the process. Also, queue observing cuts down on plane travel, an important step for cutting carbon emissions. It’s a brand new age, I thought as I watched the giant domes spin in the silent, cold Chilean night. And maybe with queue observing, some of the romance is gone. Still, my colleagues and I couldn’t help saying as we stared out across the moonlit mountains: I can’t believe how lucky we are to be here. Dr. Marc J. Kuchner is an astrophysicist at the Exoplanets and Stellar Astrophysics Laboratory at NASA’s Goddard Space Flight Center. NASA’s Astrophysics Division works on big questions about the origin and evolution of the universe, galaxies, and planetary systems. Explore more at http://www.science.nasa.gov/astrophysics/. Kids can explore these topics at http://spaceplace.nasa.gov/space. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: European Southern Observatory at Mt. Paranal, Chile. How Many Discoveries Can You Make in a Month?By Dr. Tony Phillips This year NASA has announced the discovery of 11 planetary systems hosting 26 planets; a gigantic cluster of galaxies known as “El Gordo;” a star exploding 9 billion light years away; alien matter stealing into the solar system; massive bullets of plasma racing out of the galactic center; and hundreds of unknown objects emitting high-energy photons at the edge of the electromagnetic spectrum. That was just January. Within NASA’s Science Mission Directorate, the Astrophysics Division produces such a list nearly every month. Indeed, at this very moment, data is pouring in from dozens of spacecraft and orbiting observatories. “The Hubble, Spitzer, Chandra, and Fermi space telescopes continue to make groundbreaking discoveries on an almost daily basis,” says NASA Administrator Charlie Bolden(1). NASA astrophysicists and their colleagues conduct an ambitious research program stretching from the edge of the solar system to the edge of the observable Universe. Their work is guided in large part by the National Research Council’s Decadal Survey of Astronomy and Astrophysics, which identified the following priorities: Finding new planets—and possibly new life—around other stars. Discovering the nature of dark energy and dark matter. Understanding how stars and galaxies have evolved since the Big Bang. Studying exotic physics in extreme places like black holes. Observing time on Hubble and the other “Great Observatories” is allocated accordingly. Smaller missions are important, too: The Kepler spacecraft, which is only “medium-sized” by NASA standards, has single-handedly identified more than 2300 planet candidates. Recent finds include planets with double suns, massive “super-Earths” and “hot Jupiters,” and a miniature solar system. It seems to be only a matter of time before Kepler locates an Earth-sized world in the Goldilocks zone of its parent star, just right for life. A future astrophysics mission, the James Webb Space Telescope, will be able to study the atmospheres of many of the worlds Kepler is discovering now. The telescope’s spectrometers can reveal the chemistry of distant exoplanets, offering clues to their climate, cloud cover, and possibilities for life. That’s not the telescope’s prime mission, though. With a primary mirror almost 3 times as wide as Hubble’s, and a special sensitivity to penetrating infrared radiation, Webb is designed to look into the most distant recesses of the universe to see how the first stars and galaxies formed after the Big Bang. It is, in short, a Genesis Machine. Says Bolden, “We’re on track in the construction of the James Webb Space Telescope, the most sophisticated science telescope ever constructed to help us reveal the mysteries of the cosmos in ways never before possible.” Liftoff is currently scheduled for 2018. How long will the list of discoveries be in January of that year? Stay tuned for Astrophysics. For more on NASA’s astrophysics missions, check out http://science.nasa.gov/astrophysics/. Kids can get some of their mind-boggling astrophysics questions answered by resident Space Place astrophysicist “Dr. Marc” at http://spaceplace.nasa.gov/dr-marc-space. (1)Bolden made these statements in an April 20th editorial he co-authored with John Holdren, Director of the Office of Science and Technology Policy: http://blogs.nasa.gov/cm/blog/bolden/posts/post_1334967201693.html This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s concepts such as this one are based on infrared spectrometer data from NASA’s Spitzer Space Telescope. This rendering depicts a quadruple-star system called HD 98800. The system is approximately 10 million years old and is located 150 light-years away in the constellation Crater. Credit: NASA/JPL-Caltech/T. Pyle (SSC) Thank Goodness for MagnetismBy Dr. Tony Phillips Only 93 million miles from Earth, a certain G-type star is beginning to act up. Every 11 years or so, the solar cycle brings a period of high solar activity. Giant islands of magnetism— ”sunspots” —break through the stellar surface in increasing numbers. Sometimes they erupt like a billion atomic bombs going off at once, producing intense flares of X-rays and UV radiation, and hurling massive clouds of plasma toward Earth. This is happening right now. Only a few years ago the Sun was in a state of deep quiet, but as 2012 unfolds, the pendulum is swinging. Strong flares are becoming commonplace as sunspots once again pepper the solar disk. Fortunately, Earth is defended from solar storms by a strong, global magnetic field. In March 2012, those defenses were tested. At the very beginning of the month, a remarkable sunspot appeared on the Sun’s eastern limb. AR1429, as experts called it, was an angry-looking region almost as wide as the planet Jupiter. Almost as soon as it appeared, it began to erupt. During the period March 2nd to 15th, it rotated across the solar disk and fired off more than 50 flares. Three of those eruptions were X-class flares, the most powerful kind. As the eruptions continued almost non-stop, Earth’s magnetic field was buffeted by coronal mass ejections or “CMEs.” One of those clouds hit Earth’s magnetosphere so hard, our planet’s magnetic field was sharply compressed, leaving geosynchronous satellites on the outside looking in. For a while, the spacecraft were directly exposed to solar wind plasma. Charged particles propelled by the blasts swirled around Earth, producing the strongest radiation storm in almost 10 years. When those particles rained down on the upper atmosphere, they dumped enough energy in three days alone (March 7-10) to power every residence in New York City for two years. Bright auroras circled both poles, and Northern Lights spilled across the Canadian border into the lower 48 states. Luminous sheets of red and green were sighted as far south as Nebraska. When all was said and done, the defenses held — no harm done. This wasn’t the strongest solar storm in recorded history—not by a long shot. That distinction goes to the Carrington Event of September 1859 when geomagnetic activity set telegraph offices on fire and sparked auroras over Mexico, Florida, and Tahiti. Even with that in mind, however, March 2012 was remarkable. It makes you wonder, what if? What if Earth didn’t have a magnetic field to fend off CMEs and deflect the most energetic particles from the Sun. The answer might lie on Mars. The red planet has no global magnetic field and as a result its atmosphere has been stripped away over time by CMEs and other gusts of solar wind. At least that’s what many researchers believe. Today, Mars is a desiccated and apparently lifeless wasteland. Only 93 million miles from Earth, a G-type star is acting up. Thank goodness for magnetism. With your inner and outer children, read, watch, and listen in to “Super Star Meets the Plucky Planet,” a rhyming and animated conversation between the Sun and Earth, at http://spaceplace.nasa.gov/story-superstar. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Multiple-wavelength view of X5.4 solar flare on March 6, captured by the Solar Dynamics Observatory (SDO) in multiple wavelengths (94, 193, 335 angstroms). Credit: NASA/SDO/AIA NASA Helps Europe Study a Comet– Up Close and PersonalBy Dr. Tony Phillips Europe’s Rosetta spacecraft is on its way to intercept comet 67P/Churyumov-Gerasimenko. Comets have been intercepted before, but this mission is different. Rosetta aims to make history by landing a probe on the comet’s surface while the mother ship orbits overhead. “Rosetta is the European equivalent of a NASA flagship mission,” explains Claudia Alexander, project scientist for the U.S. Rosetta Project at NASA's Jet Propulsion Laboratory. “It will conduct the most comprehensive study of a comet ever performed.” Rosetta’s payload contains 21 instruments (11 on the orbiter, 10 on the lander) designed to study almost every aspect of the comet’s chemistry, structure, and dynamics. Three of the sensors were contributed by the U.S.: Alice (an ultraviolet spectrometer), IES (an ion and electron sensor), and MIRO (a microwave sounder). The main event of the mission will likely be the landing. The 100-kg lander, which looks a bit like a cross between NASA’s old Viking Mars landers and a modern microsatellite, will spend two weeks fastened to the comet’s icy surface. The European-built probe will collect samples for analysis by onboard microscopes and take stunning panoramic images from ground level. “First the lander will study the surface from close range to establish a baseline before the comet becomes active,” explains Alexander. “Then the orbiter will investigate the flow of gas and dust around the comet's active, venting nucleus.” Rosetta’s sensors will perform the experiments that reveal how the chemicals present interact with one another and with the solar wind. Alice and MIRO detect uncharged atoms and molecules, while IES detects the ions and electrons as the solar wind buffets the nucleus. One problem that often vexes astronomers when they try to study comets is visibility. It’s hard to see through the dusty veil of gas billowing away from the heated nucleus. The microwaves MIRO detects can penetrate the dust, so MIRO can see and measure its target molecules even when other instruments can’t. MIRO is one of several experiments focused on the comet’s structural properties. It will determine the comet’s dielectric constant, emissivity, and thermal conductivity to determine whether it is made of a powdery loose material, has a detectable layer of loose material, or is hard as rock. “We want to find out whether comets have retained material from when the solar system formed,” says Alexander. “If the ancient materials are still there, we can get an idea of what conditions were like at the dawn of the solar system.” Rosetta enters orbit in 2014. Stay tuned for updates! Check out “Comet Quest,” the new, free iPhone/iPad game that has you operating the Rosetta spacecraft yourself. Get the link at http://spaceplace.nasa.gov/comet-quest. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Rosetta’s lander Philae will eject from the spacecraft, touch down on the comet’s nucleus, and immediately fire a harpoon into the surface to anchor itself, so it won’t drift off in the weak gravity. The Planet in the MachineBy Diane K. Fisher and Tony Phillips The story goes that a butterfly flapping its wings in Brazil can, over time, cause a tornado in Kansas. The “butterfly effect” is a common term to evoke the complexity of interdependent variables affecting weather around the globe. It alludes to the notion that small changes in initial conditions can cause wildly varying outcomes. Now imagine millions of butterflies flapping their wings. And flies and crickets and birds. Now you understand why weather is so complex. All kidding aside, insects are not in control. The real “butterfly effect” is driven by, for example, global winds and ocean currents, polar ice (melting and freezing), clouds and rain, and blowing desert dust. All these things interact with one another in bewilderingly complicated ways. And then there’s the human race. If a butterfly can cause a tornado, what can humans cause with their boundlessly reckless disturbances of initial conditions? Understanding how it all fits together is a relatively new field called Earth system science. Earth system scientists work on building and fine-tuning mathematical models (computer programs) that describe the complex inter-relationships of Earth’s carbon, water, energy, and trace gases as they are exchanged between the terrestrial biosphere and the atmosphere. Ultimately, they hope to understand Earth as an integrated system, and model changes in climate over the next 50-100 years. The better the models, the more accurate and detailed will be the image in the crystal ball. NASA’s Earth System Science program provides real-world data for these models via a swarm of Earth-observing satellites. The satellites, which go by names like Terra and Aqua, keep an eye on Earth’s land, biosphere, atmosphere, clouds, ice, and oceans. The data they collect are crucial to the modeling efforts. Some models aim to predict short-term effects—in other words, weather. They may become part of severe weather warning systems and actually save lives. Other models aim to predict long-term effects—or climate. But, long-term predictions are much more difficult and much less likely to be believed by the general population, since only time can actually prove or disprove their validity. After all, small errors become large errors as the model is left to run into the future. However, as the models are further validated with near- and longer-term data, and as different models converge on a common scenario, they become more and more trustworthy to show us the future while we can still do something about it—we hope. For a listing and more information on each of NASA’s (and their partners’) Earth data-gathering missions, visit http://science.nasa.gov/earth-science/missions/. Kids can get an easy introduction to Earth system science and play Earthy word games at http://spaceplace.nasa.gov/ecosphere. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: CloudSat is one of the Earth-observing satellites collecting data that will help develop and refine atmospheric circulation models and other types of weather and climate models. CloudSat’s unique radar system reads the vertical structure of clouds, including liquid water and ice content, and how clouds affect the distribution of the Sun’s energy in the atmosphere. See animation of this data simulation at http://www.nasa.gov/mission_pages/calipso/multimedia/cloud_calip_mm.html. The Hidden Power of Sea Salt, RevealedBy Dauna Coulter Last year, when NASA launched the Aquarius/SAC-D satellite carrying the first sensor for measuring sea salt from space, scientists expected the measurements to have unparalleled sensitivity. Yet the fine details it's revealing about ocean saltiness are surprising even the Aquarius team. "We have just four months of data, but we're already seeing very rich detail in surface salinity patterns," says principal investigator Gary Lagerloef of Earth & Space Research in Seattle. "We're finding that Aquarius can monitor even small scale changes such as specific river outflow and its influence on the ocean." Using one of the most sensitive microwave radiometers ever built, Aquarius can sense as little as 0.2 parts salt to 1,000 parts water. That's about like a dash of salt in a gallon jug of water. "You wouldn't even taste it," says Lagerloef. "Yet Aquarius can detect that amount from 408 miles above the Earth. And it's working even better than expected." Salinity is critical because it changes the density of surface seawater, and density controls the ocean currents that move heat around our planet. A good example is the Gulf Stream, which carries heat to higher latitudes and moderates the climate. "When variations in density divert ocean currents, weather patterns like temperature and rainfall are affected. In turn, precipitation and evaporation, and fresh water from river outflow and melt ice determine salinity. It's an intricately connected cycle." The atmosphere is the ocean’s partner. The freshwater exchange between the atmosphere and the ocean dominates the global water cycle. Seventy-eight percent of global rainfall occurs over the ocean, and 85 percent of global evaporation is from the ocean. An accurate picture of the ocean's salinity will help scientists better understand the profound ocean/atmosphere coupling that determines climate variability. "Ocean salinity has been changing,” says Lagerloef. “Decades of data from ships and buoys tell us so. Some ocean regions are seeing an increase in salinity, which means more fresh water is being lost through evaporation. Other areas are getting more rainfall and therefore lower salinity. We don't know why. We just know something fundamental is going on in the water cycle." With Aquarius's comprehensive look at global salinity, scientists will have more clues to put it all together. Aquarius has collected as many sea surface salinity measurements in the first few months as the entire 125-year historical record from ships and buoys. "By this time next year, we'll have met two of our goals: a new global map of annual average salinity and a better understanding of the seasonal cycles that determine climate." Stay tuned for the salty results. Read more about the Aquarius mission at http://aquarius.nasa.gov. Other NASA oceanography missions are Jason-1 (studying ocean surface topography), Jason-2 (follow-on to Jason-1), Jason-3 (follow-on to Jason-2, planned for launch in 2014), and Seawinds on the QuikSCAT satellite (measures wind speeds over the entire ocean). The GRACE mission (Gravity Recovery and Climate Experiment), among its other gravitational field studies, monitors fresh water supplies underground. All these missions, including Aquarius, are sponsors of a fun and educational ocean game for kids called “Go with the Flow” at http://spaceplace.nasa.gov/ocean-currents. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Aquarius produced this map of global ocean salinity. It is a composite of the first two and a half weeks of data. Yellow and red represent areas of higher salinity, with blues and purples indicating areas of lower salinity. The Nerdiest Video Game EverBy Dr. Tony Phillips NASA has a job opening. Wanted: People of all ages to sort, stack, and catalogue terabytes of simulated data from a satellite that launches in 2015. Agile thumbs required. Sorting terabytes of data? It’s more fun than it sounds. In fact it’s a game: Satellite Insight. The Space Place Team at the Jet Propulsion Laboratory created the entertaining app for iPhones to get the word out about GOES-R, an advanced Earth science satellite built by NOAA and NASA. Described by the Los Angeles Times as possibly “the nerdiest game ever,” Satellite Insight may be downloaded for free from Apple’s app store. Be careful, though, once you start playing it’s hard to stop. Some reviewers have likened it to Tetris, one of the most popular video games of all time. GOES, short for “Geostationary Operational Environmental Satellite,” is the workhorse spacecraft for weather forecasters. NOAA operates two (at a time) in geosynchronous orbit, one above the west coast of N. America and one above the east coast. They monitor clouds, wind, rain, hurricanes, tornadoes and even solar flares. The GOES program has been in action since 1975. GOES-R is the next-generation satellite with advanced technologies far beyond those of the older GOES satellites. It has sensors for lightning detection, wildfire mapping, storm tracking, search and rescue, solar imaging, and more. Many of the sensors are trailblazers. For example, the Advanced Baseline Imager has 60 times the capability of the current imager—16 channels instead of 5. It has twice the spatial resolution and five times the temporal refresh rate, including the 30-second imaging of weather systems over a region of 1000 km x 1000 km. Also, the Geostationary Lightning Mapper can count and pinpoint lightning bolts over the Americas 24/7. It’s the first such detector to fly on a geosynchronous satellite, and it could lead to transformative advances in severe storm warning capability. All in all, GOES-R represents a “huge technological leap from the current GOES.” We know this because Satellite Insight tells us so. The app has an informative “Learn More” feature where players can find out about the satellite and the data they have been sorting. Which brings us back to sorting data. It’s a bit like eating Cheerios; just don’t tell the kids it’s nutritious, and they love it. Helping GOES-R gather and stash data from all those advanced sensors is just as satisfying, too—a dose of Earth science wrapped in thumb-flying fun. More information about Satellite Insight may be found on the web at http://itunes.apple.com/us/app/satellite-insight/id463588902?mt=8. The game also available in web form (flying thumbs optional) at http://spaceplace.nasa.gov/satellite-insight. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: New iPhone game is first NOAA app and only the second NASA game app. Just as with the real GOES-R, the challenge with Satellite Insight is to keep up with the massive influx of weather and other environmental data. Dawn Takes a Closer Lookby Dr. Marc Rayman Dawn is the first space mission with an itinerary that includes orbiting two separate solar system destinations. It is also the only spacecraft ever to orbit an object in the main asteroid belt between Mars and Jupiter. The spacecraft accomplishes this feat using ion propulsion, a technology first proven in space on the highly successful Deep Space 1 mission, part of NASA’s New Millennium program. Launched in September 2007, Dawn arrived at protoplanet Vesta in July 2011. It will orbit and study Vesta until July 2012, when it will leave orbit for dwarf planet Ceres, also in the asteroid belt. Dawn can maneuver to the orbit best suited for conducting each of its scientific observations. After months mapping this alien world from higher altitudes, Dawn spiraled closer to Vesta to attain a low altitude orbit, the better to study Vesta’s composition and map its complicated gravity field. Changing and refining Dawn’s orbit of this massive, irregular, heterogeneous body is one of the most complicated parts of the mission. In addition, to meet all the scientific objectives, the orientation of this orbit needs to change. These differing orientations are a crucial element of the strategy for gathering the most scientifically valuable data on Vesta. It generally requires a great deal of maneuvering to change the plane of a spacecraft’s orbit. The ion propulsion system allows the probe to fly from one orbit to another without the penalty of carrying a massive supply of propellant. Indeed, one of the reasons that traveling from Earth to Vesta (and later Ceres) requires ion propulsion is the challenge of tilting the orbit around the sun. Although the ion propulsion system accomplishes the majority of the orbit change, Dawn’s navigators are enlisting Vesta itself. Some of the ion thrusting was designed in part to put the spacecraft in certain locations from which Vesta would twist its orbit toward the target angle for the low-altitude orbit. As Dawn rotates and the world underneath it revolves, the spacecraft feels a changing pull. There is always a tug downward, but because of Vesta’s heterogeneous interior structure, sometimes there is also a slight force to one side or another. With their knowledge of the gravity field, the mission team plotted a course that took advantage of these variations to get a free ride. The flight plan is a complex affair of carefully timed thrusting and coasting. Very far from home, the spacecraft is making excellent progress in its expedition at a fascinating world that, until a few months ago, had never seen a probe from Earth. Keep up with Dawn’s progress by following the Chief Engineer’s (yours truly’s) journal at http://dawn.jpl.nasa.gov/mission/journal.asp. And check out the illustrated story in verse of “Professor Starr’s Dream Trip: Or, how a little technology goes a long way,” at http://spaceplace.nasa.gov/story-prof-starr. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This full view of the giant asteroid Vesta was taken by NASA’s Dawn spacecraft, as part of a rotation characterization sequence on July 24, 2011, at a distance of 5,200 kilometers (3,200 miles). Credit: NASA/JPL-Caltech/UCLA/MPS/DLR/IDA Re-thinking an Alien World: The Strange Case of 55 Cancri eForty light years from Earth, a rocky world named “55 Cancri e” circles perilously close to a stellar inferno. Completing one orbit in only 18 hours, the alien planet is 26 times closer to its parent star than Mercury is to the Sun. If Earth were in the same position, the soil beneath our feet would heat up to about 3200 F. Researchers have long thought that 55 Cancri e must be a wasteland of parched rock. Now they’re thinking again. New observations by NASA's Spitzer Space Telescope suggest that 55 Cancri e may be wetter and weirder than anyone imagined. Spitzer recently measured the extraordinarily small amount of light 55 Cancri e blocks when it crosses in front of its star. These transits occur every 18 hours, giving researchers repeated opportunities to gather the data they need to estimate the width, volume and density of the planet. According to the new observations, 55 Cancri e has a mass 7.8 times and a radius just over twice that of Earth. Those properties place 55 Cancri e in the “super-Earth” class of exoplanets, a few dozen of which have been found. Only a handful of known super-Earths, however, cross the face of their stars as viewed from our vantage point in the cosmos, so 55 Cancri e is better understood than most. When 55 Cancri e was discovered in 2004, initial estimates of its size and mass were consistent with a dense planet of solid rock. Spitzer data suggest otherwise: About a fifth of the planet’s mass must be made of light elements and compounds—including water. Given the intense heat and high pressure these materials likely experience, researchers think the compounds likely exist in a “supercritical” fluid state. A supercritical fluid is a high-pressure, high-temperature state of matter best described as a liquid-like gas, and a marvelous solvent. Water becomes supercritical in some steam turbines—and it tends to dissolve the tips of the turbine blades. Supercritical carbon dioxide is used to remove caffeine from coffee beans, and sometimes to dry-clean clothes. Liquid-fueled rocket propellant is also supercritical when it emerges from the tail of a spaceship. On 55 Cancri e, this stuff may be literally oozing — or is it steaming? — out of the rocks. With supercritical solvents rising from the planet’s surface, a star of terrifying proportions filling much of the daytime sky, and whole years rushing past in a matter of hours, 55 Cancri e teaches a valuable lesson: Just because a planet is similar in size to Earth does not mean the planet is like Earth. It’s something to re-think about. Get a kid thinking about extrasolar planets by pointing him or her to “Lucy’s Planet Hunt,” a story in rhyme about a girl who wanted nothing more than to look for Earth-like planets when she grew up. Go to http://spaceplace.nasa.gov/story-lucy. The original research reported in this story has been accepted for publication in Astronomy and Astrophysics. The lead author is Brice-Olivier Demory, a post-doctoral associate in Professor Sara Seager’s group at MIT. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering compares the size Earth with the rocky “super-Earth” 55 Cancri e. Its year is only about 18 hours long! The Gray Cubicle You Want to Work Inby Dr. Tony Phillips It's another day at the office. You're sitting in a gray cubicle, tap-tap-taping away on your keyboard, when suddenly your neighbor lets out a whoop of delight. Over the top of the carpeted divider you see a star exploding on the computer screen. An unauthorized video game? No, this explosion is real. A massive star just went supernova in the Whirlpool Galaxy, and the first images from Hubble are popping up on your office-mate’s screen. It's another day at the office ... at NASA. Just down the hall, another office-mate is analyzing global temperature trends. On the floor below, a team of engineers gathers to decode signals from a spaceship that entered “safe mode” when it was hit by a solar flare. And three floors above, a financial analyst snaps her pencil-tip as she tries to figure out how to afford just one more sensor for a new robotic spacecraft. These are just a few of the things going on every day at NASA headquarters in Washington DC and more than a dozen other NASA centers scattered around the country. The variety of NASA research and, moreover, the variety of NASA people required to carry it out often comes as a surprise. Consider the following: NASA's Science Mission Directorate (SMD) supports research in four main areas: Earth Science, Heliophysics, Astrophysics, and Planetary Science. Read that list one more time. It includes everything in the cosmos from the ground beneath our feet to the Sun in the sky to the most distant galaxies at the edge of the Universe. Walking among the cubicles in NASA’s science offices, you are likely to meet people working on climate change, extraterrestrial life, Earth-threatening asteroids, black holes or a hundred other things guaranteed to give a curious-minded person goose bumps. Truly, no other government agency has a bigger job description. And it’s not just scientists doing the work. NASA needs engineers to design its observatories and build its spacecraft, mathematicians to analyze orbits and decipher signals, and financial wizards to manage the accounts and figure out how to pay for everything NASA dreamers want to do. Even writers and artists have a place in the NASA scheme of things. Someone has to explain it all to the general public. Clearly, some cubicles are more interesting than others. For more information about the Science Mission Directorate, visit http://science.nasa.gov. And for another way to reach the Space Place, go to http://science.nasa.gov/kids. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Some of the employees of NASA’s Science Mission Directorate may work in gray cubicles, but their jobs are anything but dull. They get to study Earth, the Sun, the Solar System, and the Universe! Dark Clues to the UniverseBy Dr. Marc Rayman Urban astronomers are always wishing for darker skies. But that complaint is due to light from Earth. What about the light coming from the night sky itself? When you think about it, why is the sky dark at all? Of course, space appears dark at night because that is when our side of Earth faces away from the Sun. But what about all those other suns? Our own Milky Way galaxy contains over 200 billion stars, and the entire universe probably contains over 100 billion galaxies. You might suppose that that many stars would light up the night like daytime! Until the 20th century, astronomers didn't think it was even possible to count all the stars in the universe. They thought the universe was infinite and unchanging. Besides being very hard to imagine, the trouble with an infinite universe is that no matter where you look in the night sky, you should see a star. Stars should overlap each other in the sky like tree trunks in the middle of a very thick forest. But, if this were the case, the sky would be blazing with light. This problem greatly troubled astronomers and became known as “Olbers’ Paradox” after the 19th century astronomer Heinrich Olbers who wrote about it, although he was not the first to raise this astronomical mystery. To try to explain the paradox, some 19th century scientists thought that dust clouds between the stars must be absorbing a lot of the starlight so it wouldn’t shine through to us. But later scientists realized that the dust itself would absorb so much energy from the starlight that eventually it would glow as hot and bright as the stars themselves. Astronomers now realize that the universe is not infinite. A finite universe—that is, a universe of limited size—even one with trillions of stars, just wouldn't have enough stars to light up all of space. Although the idea of a finite universe explains why Earth's sky is dark at night, other factors work to make it even darker. The universe is expanding. As a result, the light that leaves a distant galaxy today will have much farther to travel to our eyes than the light that left it a million years ago or even one year ago. That means the amount of light energy reaching us from distant stars dwindles all the time. And the farther away the star, the less bright it will look to us. Also, because space is expanding, the wavelengths of the light passing through it are expanding. Thus, the farther the light has traveled, the more red-shifted (and lower in energy) it becomes, perhaps red-shifting right out of the visible range. So, even darker skies prevail. The universe, both finite in size and finite in age, is full of wonderful sights. See some bright, beautiful images of faraway galaxies against the blackness of space at the Space Place image galleries. Visit http://spaceplace.nasa.gov/search/?q=gallery. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This Hubble Space Telescope image of Galaxy NGC 4414 was used to help calculate the expansion rate of the universe. The galaxy is about 60 million light-years away. Credit: NASA and The Hubble Heritage Team (STScI/AURA) Solar System Size Surpriseby Dr. Tony Phillips News flash: You may be closer to interstellar space than you previously thought. A team of researchers led by Tom Krimigis of the Johns Hopkins University Applied Physics Laboratory announced the finding in the June 2011 issue of Nature. The complicated title of their article, “Zero outward flow velocity for plasma in a heliosheath transition layer,” belies a simple conclusion: The solar system appears to be a billion or more kilometers smaller than earlier estimates. The recalculation is prompted by data from NASA’s Voyager 1 probe, now 18 billion kilometers from Earth. Voyagers 1 and 2 were designed and built and are managed by NASA’s Jet Propulsion Laboratory. Aging but active, the spacecraft have been traveling toward the stars since 1977 on a heroic mission to leave the solar system and find out what lies beyond. To accomplish their task, the Voyagers must penetrate the outer walls of the heliosphere, a great bubble of plasma and magnetism blown in space by the solar wind. The heliosphere is so big, it contains all the planets, comets, and asteroids that orbit the sun. Indeed many astronomers hold that the heliosphere defines the boundaries of the solar system. Inside it is “home.” Outside lies the Milky Way. For 30+ years, the spacecraft have been hurtling toward the transition zone. Voyager 1 is closing in. Much of Voyager 1’s long journey has been uneventful. Last year, however, things began to change. In June 2010, Voyager 1 beamed back a startling number: zero. That’s the outward velocity of the solar wind where the probe is now. “This is the first sign that the frontier is upon us,” says Krimigis. Previously, researchers thought the crossing was still years and billions of kilometers away, but a new analysis gave them second thoughts. Krimigis and colleagues combined Voyager data with previously unpublished measurements from the Cassini spacecraft. Cassini, on a mission to study Saturn, is nowhere near the edge of the solar system, but one of its instruments can detect atoms streaming into our solar system from the outside. Comparing data from the two locations, the team concluded that the edge of the heliosphere lies somewhere between16 to 23 billion kilometers from the sun, with a best estimate of approximately 18 billion kilometers. Because Voyager 1 is already nearly 18 billion kilometers out, it could cross into interstellar space at any time—maybe even as you are reading this article. “How close are we?” wonders Ed Stone, Caltech professor and principal investigator of the Voyager project since the beginning. “We don't know, but Voyager 1 speeds outward a billion miles every three years, so we may not have long to wait.” Stay tuned for the crossing. For more about the missions of Voyager 1 and 2, see http://voyager.jpl.nasa.gov/. Another Voyager project scientist, Merav Opher, is the guest on the newest Space Place Live cartoon interview show for kids at http://spaceplace.nasa.gov/space-place-live. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This artist's concept shows NASA's two Voyager spacecraft exploring a turbulent region of space known as the heliosheath, the outer shell of the bubble of charged particles around our sun. Image credit: NASA/JPL-Caltech. New GOES-R to Give More Tornado Warning Timeby Dauna Coulter and Dr. Tony Phillips So far this spring, more than 1,400 tornadoes have struck the U.S. Some of them have cut jaw-dropping trails of destruction across the countryside and, tragically, across inhabited communities, too. Hundreds of lives have been lost in the onslaught. Throughout the season, the National Weather Service has routinely issued tornado alerts. In the case of the Alabama tornadoes of April 27th, forecasters warned of severe weather five full days before the twisters struck. Because they couldn’t say precisely where the twisters would strike, however, many of their warnings went unheeded. “If people get a hurricane warning, they often evacuate the area,” notes NOAA's Steve Goodman. “But we react differently to tornado warnings.” Perhaps it’s because tornadoes are smaller than hurricanes, and the odds of a direct hit seem so remote. Recent pictures from Tuscaloosa, Alabama, and Joplin, Missouri, however, show the perils of playing those odds. Goodman believes that more precise warnings could save lives. To fine-tune tornado warnings, NOAA will soon launch the first in a series of next-generation weather satellites – GOES-R (Geostationary Operational Environmental Satellites-R series). The spacecraft is brimming with advanced sensors for measuring key ingredients of severe weather including winds, cloud growth, and lightning. “GOES-R will be the first geostationary spacecraft to carry a lightning sensor,” says Goodman, the GOES-R Program Senior Scientist. “Studies show that sudden changes in the total lightning activity correlate with storm intensity—and with tornadoes.” The lightning mapper will detect and map not only cloud-to-ground lightning, but also bolts within and between clouds. The kind of cloud-to-ground lightning we see from our front yards accounts for only 15-20 percent of total lightning. To get a clear idea of a storm's intensity, meteorologists need to know about all the lightning—a view GOES-R can provide. All by itself, the lightning mapper will provide 7 minutes more lead time in tornado warnings, according to Goodman. GOES-R’s state-of-the-art instruments will also improve long-range forecasts. “The satellite's Advanced Baseline Imager (ABI), for instance, will provide a much clearer picture of clouds,” says NOAA research meteorologist Tim Schmit. Compared to lesser instruments already in orbit, ABI can better detect super-cold “overshooting tops,” evidence of enormous energy and upward velocity that correlate with subsequent severe weather. “Accurate advanced notice of high-risk tornadic conditions can cue officials to close schools and businesses even before tornadoes are actually detected,” says Schmit. Forecasters doubt tornadoes can ever be predicted with 100% accuracy. The twisters are just too capricious. GOES-R, however, is a step in the right direction. Find out more about GOES-R’s unprecedented capabilities at http://www.goes-r.gov. Young people can learn more about tornadoes and all kinds of other weather at http://scijinks.gov. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This GOES image shows the storms that spurred the intense April 27 tornado outbreak in the southern U.S. Animation showing the development of weather can be seen at http://earthobservatory.nasa.gov/NaturalHazards/view.php?id=50347. Finding Planets Among The Starsby Dr. Tony Phillips Strange but true: When it comes to finding new extra-solar planets, or exoplanets, stars can be an incredible nuisance. It’s a matter of luminosity. Stars are bright, but their planets are not. Indeed, when an astronomer peers across light years to find a distant Earth-like world, what he often finds instead is an annoying glare. The light of the star itself makes the star's dim planetary system nearly impossible to see. Talk about frustration! How would you like to be an astronomer who's constantly vexed by stars? Fortunately, there may be a solution. It comes from NASA's Galaxy Evolution Explorer, an ultraviolet space telescope orbiting Earth since 2003. In a new study, researchers say the Galaxy Evolution Explorer is able to pinpoint dim stars that might not badly outshine their own planets. “We've discovered a new technique of using ultraviolet light to search for young, low-mass stars near the Earth,” said David Rodriguez, a graduate student of astronomy at UCLA, and the study's lead author. “These M-class stars, also known as red dwarfs, make excellent targets for future direct imaging of exoplanets.” Young red dwarfs produce a telltale glow in the ultraviolet part of the electromagnetic spectrum that Galaxy Evolution Explorer can sense. Because dwarf stars are so numerous—as a class, they account for more than two-thirds of the stars in the galaxy—astronomers could reap a rich bounty of targets. In many ways, these stars represent a best-case scenario for planet hunting. They are close and in clear lines-of-sight, which generally makes viewing easier. Their low mass means they are dimmer than heavier stars, so their light is less likely to mask the feeble light of a planet. And because they are young, their planets are freshly formed, and thus warmer and brighter than older planetary bodies. Astronomers know of more than five hundred distant planets, but very few have actually been seen. Many exoplanets are detected indirectly by means of their “wobbles”—the gravitational tugs they exert on their central stars. Some are found when they transit the parent star, momentarily dimming the glare, but not dimming it enough to reveal the planet itself. The new Galaxy Evolution Explorer technique might eventually lead to planets that can be seen directly. That would be good because, as Rodriguez points out, “seeing is believing.” And it just might make astronomers feel a little better about the stars. The Galaxy Evolution Explorer Web site at http://www.galex.caltech.edu describes many of the other discoveries and accomplishments of this mission. And for kids, how do astronomers know how far away a star or galaxy is? Play “How Old do I Look” on The Space Place at http://spaceplace.nasa.gov/whats-older and find out! This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Exoplanets are easier to see directly when their star is a dim, red dwarf. Milky Way Safariby Dauna Coulter and Dr. Tony Phillips Safari, anyone? Citizen scientists are invited to join a hunt through the galaxy. As a volunteer for Zooniverse's Milky Way Project, you'll track down exotic creatures like mysterious gas bubbles, twisted green knots of dust and gas, and the notorious “red fuzzies.” “The project began about four months ago,” says astrophysicist Robert Simpson of Oxford University. “Already, more than 18,000 people are scouting the Milky Way for these quarry.” The volunteers have been scrutinizing infrared images of the Milky Way's inner regions gathered by NASA’s Spitzer Space Telescope. Spitzer's high resolution in infrared helps it pierce the cloaking haze of interstellar gas and dust, revealing strange and beautiful structures invisible to conventional telescopes. The Milky Way Project is helping astronomers catalogue these intriguing features, map our galaxy, and plan future research. “Participants use drawing tools to flag the objects,” explains Simpson. “So far they've made over a million drawings and classified over 300,000 images.” Scientists are especially interested in bubble-like objects believed to represent areas of active star formation. “Every bubble signifies hundreds to thousands of young, hot stars. Our volunteers have circled almost 300,000 bubble candidates, and counting,” he says. Humans are better at this than computers. Computer searches turn up only the objects precisely defined in a program, missing the ones that don't fit a specified mold. A computer would, for example, overlook partial bubbles and those that are skewed into unusual shapes. “People are more flexible. They tend to pick out patterns computers don't pick up and find things that just look interesting. They're less precise, but very complementary to computer searches, making it less likely we'll miss structures that deserve a closer look. And just the sheer numbers of eyes on the prize mean more comprehensive coverage.” Along the way the project scientists distill the volunteers' data to eliminate repetitive finds (such as different people spotting the same bubbles) and other distortions. The project's main site (http://www.milkywayproject.org) includes links to a blog and a site called Milky Way Talk. Here “hunters” can post comments, chat about images they've found, tag the ones they consider especially intriguing, vote for their favorite images (see the winners at http://talk.milkywayproject.org/collections/CMWS00002u), and more. Zooniverse invites public participation in science missions both to garner interest in science and to help scientists achieve their goals. More than 400,000 volunteers are involved in their projects at the moment. If you want to help with the Milky Way Project, visit the site, take the tutorial, and … happy hunting! You can get a preview some of the bubbles at Spitzer’s own web site, http://www.spitzer.caltech.edu/. Kids will enjoy looking for bubbles in space pictures while playing the Spitzer concentration game at http://spaceplace.nasa.gov/spitzer-concentration/. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Volunteers study infrared images of our galaxy from the Spitzer Space Telescope, identifying interesting features using the special tools of the Milky Way Project, part of the Citizen Science Alliance Zooniverse web site. Cosmic Recountby Dr. Tony Phillips News flash: The Census Bureau has found a way to save time and money. Just count the biggest people. For every NBA star like Shaquille O’Neal or Yao Ming, there are about a million ordinary citizens far below the rim. So count the Shaqs, multiply by a million, and the census is done. Could the Bureau really get away with a scheme like that? Not likely. Yet this is just what astronomers have been doing for decades. Astronomers are census-takers, too. They often have to estimate the number and type of stars in a distant galaxy. The problem is, when you look into the distant reaches of the cosmos, the only stars you can see are the biggest and brightest. There’s no alternative. To figure out the total population, you count the supermassive Shaqs and multiply by some correction factor to estimate the number of little guys. The correction factor astronomers use comes from a function called the “IMF”—short for “initial mass function.” The initial mass function tells us the relative number of stars of different masses. For example, for every 20-solar-mass giant born in an interstellar cloud, there ought to be about 100 ordinary sun-like stars. This kind of ratio allows astronomers to conduct a census of all stars even when they can see only the behemoths. Now for the real news flash: The initial mass function astronomers have been using for years might be wrong. NASA’s Galaxy Evolution Explorer, an ultraviolet space telescope dedicated to the study of galaxies, has found proof that small stars are more numerous than previously believed. “Some of the standard assumptions that we've had—that the brightest stars tell you about the whole population—don’t seem to work, at least not in a constant way,” says Gerhardt R. Meurer who led the study as a research scientist at Johns Hopkins University, Baltimore, Md. (Meurer is now at the University of Western Australia.) Meurer says that the discrepancy could be as high as a factor of four. In other words, the total mass of small stars in some galaxies could be four times greater than astronomers thought. Take that, Shaq! The study relied on data from Galaxy Evolution Explorer to sense UV radiation from the smaller stars in distant galaxies, and data from telescopes at the Cerro Tololo Inter-American Observatory to sense the “H-alpha” (red light) signature of larger stars. Results apply mainly to galaxies where stars are newly forming, cautions Meurer. “I think this is one of the more important results to come out of the Galaxy Evolution Explorer mission,” he says. Indeed, astronomers might never count stars the same way again. Find out about some of the other important discoveries of the Galaxy Evolution Explorer at http://www.galex.caltech.edu/. For an easy-to-understand answer for kids to “How many solar systems are in our galaxy?” go to The Space Place at http://tiny.cc/I2KMa. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Astronomers have recently found that some galaxies have as many as 2000 small stars for every 1 massive star. They used to think all galaxies had only about 500 small stars for every 1 massive star. GOES-R, Zombie Fighterby Dr. Tony Phillips On April 5, 2010, something eerie happened to the Galaxy 15 telecommunications satellite: It turned into a zombie. The day began as usual, with industry-owned Galaxy 15 relaying TV signals to millions of viewers in North America, when suddenly the geosynchronous satellite stopped taking commands from Earth. It was brain dead! Like any good zombie, however, its body continued to function. Within days, Galaxy 15 began to meander among other satellites in geosynchronous orbit, transmitting its own signal on top of the others’. Satellite operators scrambled to deal with the interference, all the while wondering what happened? In horror movies, zombies are usually produced by viruses. “In this case, the culprit was probably the sun,” says Bill Denig of the National Geophysical Data Center in Boulder, Colorado. He and colleague Janet Green of NOAA’s Space Weather Prediction Center recently led a study of the Galaxy 15 anomaly, and here are their conclusions: On April 3rd, a relatively minor solar flare launched a cloud of plasma toward Earth. Galaxy 15 had experienced many such events before, but this time there was a difference. “Galaxy 15 was just emerging from the shadow of Earth when the cloud arrived and triggered a geomagnetic storm,” explains Denig. Suddenly exposed to sunlight and the ongoing storm, “the spacecraft began to heat up and charge [up].” Electrons swirling around Galaxy 15 stuck to and penetrated the spacecraft’s surface. As more and more charged particles accumulated, voltages began to rise, and—zap!—an electrostatic discharge occurred. A zombie was born. “At least, this is what we suspect happened based on data collected by GOES satellites in the vicinity,” he says. “We’ll be able to diagnose events like this much better, however, after GOES-R is launched by NASA in 2015.” GOES-R is NOAA’s next-generation Geostationary Operational Environmental Satellite. One of the instruments it will carry, a low-energy electron counter, is crucial to “zombie fighting.” Low energy-electrons are the ones most likely to stick to a spacecraft’s surface and cause brain-frying discharges. By monitoring these particles in Earth orbit, GOES-R will provide better post-mortems for future zombie outbreaks. This could help satellite designers figure out how to build spacecraft less susceptible to discharges. Also, GOES-R will be able to issue alerts when dangerous electrons appear. Satellite operators could then take protective action—for example, putting their birds in “safe mode”—to keep the zombie population at bay. Meanwhile, Galaxy 15 is a zombie no more. In late December 2010, after 9 months of terrorizing nearby spacecraft, the comsat was re-booted, and began responding to commands from Earth again. All’s well that ends well? True zombie fighters know better than to relax. Says Denig, “We’re looking forward to GOES-R.” You and the kids in your life can learn about space weather at http://scijinks.gov/space-weather-and-us. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Galaxy 15 communication satellite was “brainless” for several months in 2010 after being exposed to a geomagnetic storm. The new GOES-R satellite will warn of such dangers. Thank Goodness the Sun is Singleby Trudy E. Bell It’s a good thing the Sun is single. According to new research, Sun-like stars in close double-star systems “can be okay for a few billion years—but then they go bad,” says Jeremy Drake of the Harvard-Smithsonian Astrophysical Observatory in Cambridge, Mass. How bad? According to data from NASA’s Spitzer Space Telescope, close binary stars can destroy their planets along with any life. Drake and four colleagues reported the results in the September 10, 2010, issue of The Astrophysical Journal Letters. Our Sun, about 864,000 miles across, rotates on its axis once in 24.5 days. “Three billion years ago, roughly when bacteria evolved on Earth, the Sun rotated in only 5 days,” explains Drake. Its rotation rate has been gradually slowing because the solar wind gets tangled up in the solar magnetic field, and acts as a brake. But some sun-like stars occur in close pairs only a few million miles apart. That’s only about five times the diameter of each star—so close the stars are gravitationally distorted. They are actually elongated toward each other. They also interact tidally, keeping just one face toward the other, as the Moon does toward Earth. Such a close binary is “a built-in time bomb,” Drake declares. The continuous loss of mass from the two stars via solar wind carries away some of the double-star system’s angular momentum, causing the two stars to spiral inward toward each other, orbiting faster and faster as the distance shrinks. When each star’s rotation period on its axis is the same as its orbital period around the other, the pair effectively rotates as a single body in just 3 or 4 days. Then, watch out! Such fast spinning intensifies the magnetic dynamo inside each star. The stars “generate bigger, stronger ‘star spots’ 5 to 10 percent the size of the star—so big they can be detected from Earth,” Drake says. “The stars also interact magnetically very violently, shooting out monster flares.” Worst of all, the decreasing distance between the two stars “changes the gravitational resonances of the planetary system,” Drake continued, destabilizing the orbits of any planets circling the pair. Planets may so strongly perturbed they are sent into collision paths. As they repeatedly slam into each other, they shatter into red-hot asteroid-sized bodies, killing any life. In as short as a century, the repeated collisions pulverize the planets into a ring of warm dust. The infrared glow from this pulverized debris is what Spitzer has seen in some self-destructing star systems. Drake and his colleagues now want to examine a much bigger sample of binaries to see just how bad double star systems really are. They’re already sure of one thing: “We’re glad the Sun is single!” Read more about these findings at the NASA Spitzer site at http://www.spitzer.caltech.edu/news/1182-ssc2010-07-Pulverized-Planet-Dust-May-Lie-Around-Double-Stars. For kids, the Spitzer Concentration game shows a big collection of memorable (if you’re good at the game) images from the Spitzer Space Telescope. Visit http://spaceplace.nasa.gov/en/kids/spitzer/concentration. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Planetary collisions such as shown in this artist’s rendering could be quite common in binary star systems where the stars are very close. Planets in Strange Placesby Trudy E. Bell Red star, blue star, big star, small star — planets may form around virtually any type or size of star throughout the universe, not just around mid-sized middle-aged yellow stars like the Sun. That’s the surprising implication of two discoveries in 2006 from the 0.85-meter-diameter Spitzer Space Telescope, which is exploring the universe from orbit at infrared (heat) wavelengths blocked by the Earth’s atmosphere. At one extreme are two blazing, blue “hypergiant” stars 180,000 light-years away in the Large Magellanic Cloud, one of the two companion galaxies to our Milky Way. The stars, called R 66 and R 126, are respectively 30 and 70 times the mass of the Sun, “about as massive as stars can get,” said Joel Kastner, professor of imaging science at the Rochester Institute of Technology in New York. R 126 is so luminous that if it were placed 10 parsecs (32.6 light-years) away — a distance at which the Sun would be one of the dimmest stars visible in the sky — the hypergiant would be as bright as the full moon, “definitely a daytime object,” Kastner remarked. Such hot stars have fierce solar winds, so Kastner and his team are mystified why any dust in the neighborhood hasn’t long since been blown away. But there it is: an unmistakable spectral signature that both hypergiants are surrounded by mammoth disks of what might be planet-forming dust and even sand. At the other extreme is a tiny brown dwarf star called Cha 110913-773444, relatively nearby (500 light-years) in the Milky Way. One of the smallest brown dwarfs known, it has less than 1 percent the mass of the Sun. It’s not even massive enough to kindle thermonuclear reactions for fusing hydrogen into helium. Yet this miniature “failed star,” as brown dwarfs are often called, is also surrounded by a flat disk of dust that may eventually clump into planets. (This brown dwarf discovery was made by a group led by Kevin Luhman of Pennsylvania State University.) Although actual planets have not been detected (in part because of the stars’ great distances), the spectra of the hypergiants show that their dust is composed of forsterite, olivine, aromatic hydrocarbons, and other geological substances found on Earth. These newfound disks represent “extremes of the environments in which planets might form,” Kastner said. “Not what you’d expect if you think our solar system is the rule.” Hypergiants and dwarfs? The Milky Way could be crowded with worlds circling every kind of star imaginable — very strange, indeed. Keep up with the latest findings from the Spitzer at www.spitzer.caltech.edu. Kids and their grownup friends can enjoy beautiful images from Spitzer while playing Spitzer Concentration at The Space Place at http://spaceplace.nasa.gov/en/kids/spitzer/concentration. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering compares size of a hypothetical hypergiant star and its surrounding dusty disk to that of our solar system. Astronomers Stumble onto Huge Space Moleculesby Trudy E. Bell and Dr. Tony Phillips Deep in interstellar space, in a the swirling gaseous envelope of a planetary nebula, hosts of carbon atoms have joined together to form large three-dimensional molecules of a special type previously seen only on Earth. Astronomers discovered them almost accidentally using NASA's Spitzer Space Telescope. “They are the largest molecules known in space,” declared Jan Cami of the University of Western Ontario, lead author of a paper with three colleagues published in Science online on July 22, 2010, and in print on September 3. Not only are the molecules big: they are of a special class of carbon molecules known as “fullerenes” because their structure resembles the geodesic domes popularized by architect Buckminster Fuller. Spitzer found evidence of two types of fullerenes. The smaller type, nicknamed the “buckyball,” is chemical formula C60, made of 60 carbon atoms joined in a series of hexagons and pentagons to form a spherical closed cage exactly like a black-and-white soccer ball. Spitzer also found a larger fullerene, chemical formula C70, consisting of 70 carbon atoms in an elongated closed cage more resembling an oval rugby ball. Neither type of fullerene is rigid; instead, their carbon atoms vibrate in and out, rather like the surface of a large soap bubble changes shape as it floats through the air. “Those vibrations correspond to wavelengths of infrared light emitted or absorbed—and that infrared emission is what Spitzer recorded,” Cami explained. Although fullerenes have been sought in space for the last 25 years, ever since they were first identified in the laboratory, the astronomers practically stumbled into the discovery. Co-author Jeronimo Bernard-Salas of Cornell University, an expert in gas and dust in planetary nebulae, was doing routine research with Spitzer's infrared observations of planetary nebulae with its spectroscopy instrument. When he studied the spectrum (infrared signature) of a dim planetary nebula called Tc 1 in the southern-hemisphere constellation of Ara, he noticed several clear peaks he had not seen before in the spectra of other planetary nebulae. “When he came to me,” recounted Cami, an astrophysicist who specializes in molecular chemistry, “I immediately and intuitively knew it I was looking at buckyballs in space. I've never been that excited!” The authors confirmed his hunch by carefully comparing the Tc 1 spectrum to laboratory experiments described in the literature. “This discovery shows that it is possible—even easy—for complex carbonaceous molecules to form spontaneously in space,” Cami said. “Now that we know fullerenes are out there, we can figure out their roles in the physics and chemistry of deep space. Who knows what other complex chemical compounds exist—maybe even some relevant to the formation of life in the universe!” Stay tuned! Learn more about this discovery at http://www.spitzer.caltech.edu. For kids, there are lots of beautiful Spitzer images to match up in the Spitzer Concentration game at http://spaceplace.nasa.gov/en/kids/spitzer/concentration. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Superimposed on a Spitzer infrared photo of the Small Magellanic Cloud is an artist's illustration depicting a magnified view of a planetary nebula and an even further magnified view of buckyballs, which consist of 60 carbon atoms arranged like soccer balls. Blue Rings Around Red Galaxiesby Trudy E. Bell and Dr. Tony Phillips Beautiful flat rings around the planet Saturn are one thing — but flat rings around entire galaxies? That is the astonishing discovery that two astronomers, Samir Salim of Indiana University at Bloomington and R. Michael Rich of UCLA described in the May 10, 2010, issue of The Astrophysical Journal Letters. “For most of the twentieth century, astronomers observing at visible wavelengths saw that galaxies looked either ‘red and dead’ or ‘blue and new,’” explained Salim. Reddish galaxies were featureless, shaped mostly like balls or lentils; bluish ones were magnificent spirals or irregular galaxies. Elliptical galaxies looked red, astronomers reasoned, because they had mostly old red giant stars near the end of their life cycles, and little gas from which new stars could form. Spiral and irregular galaxies looked blue, however, because they were rich in gas and dust that were active nurseries birthing hot, massive, bluish stars. At least, that's how galaxies appear in visible light. As early as the 1970s, though, the first space-borne telescopes sensitive to ultraviolet radiation (UV) revealed something mysterious: a few red elliptical galaxies emitted “a surprising ultraviolet excess,” said Rich. The observations suggested that some old red galaxies might not be as “dead” as previously supposed. To investigate, Salim and Rich used NASA’s Galaxy Evolution Explorer satellite to identify 30 red elliptical galaxies that also emitted the strongest UV. Then they captured a long, detailed picture of each galaxy using the Hubble Space Telescope. “Hubble revealed the answer,” says Salim. The UV radiation was emitted by enormous, flat bluish rings that completely surrounded each reddish galaxy, reminiscent of the rings of Saturn. In some cases, the bluish rings even showed a faint spiral structure! Because the bluish UV rings looked like star-forming spiral arms and lay mostly beyond the red stars at the centers of the elliptical galaxies “we concluded that the bluish rings must be made of hot young stars,” Salim continued. “But if new stars are still being formed, that means the red-and-dead galaxies must have acquired some new gas to make them.” How does a galaxy “acquire some gas?” Salim speculates that it was an act of theft. Sometimes galaxies have close encounters. If a gas-rich irregular galaxy passed close to a gas-poor elliptical galaxy, the gravity of the elliptical galaxy could steal some gas. Further studies by Galaxy Evolution Explorer, Hubble and other telescopes are expected to reveal more about the process. One thing is certain, says Rich: “The evolution of galaxies is even more surprising and beautiful than we imagined.” The press release is available at http://www.galex.caltech.edu/newsroom/glx2010-03f.html. The full published article is “Star Formation Signatures in Optically Quiescent Early-Type Galaxies” by Samir Salim and R. Michael Rich, The Astrophysical Journal Letters 714: L290–L294, 2010 May 10.Point the kids to the Photon Pile-up Game at http://spaceplace.nasa.gov/en/kids/galex/photon, where they can have fun learning about the particle nature of light. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Galaxy Evolution Explorer UV space telescope helped to identify red elliptical galaxies that also emitted the strongest UV. These are detailed, long-exposure Hubble Space Telescope images of four of these galaxies that capture the UV-emitting rings and arcs indicative of new star formation. Close Encounters with Jupiterby Dr. Tony Phillips Jupiter and Earth just had a close encounter - and it was a good one. In late September 2010, the two worlds were 31 million km (about 19 million miles) closer than at any time in the past 11 years. Soaring high in the midnight sky, Jupiter shone six times brighter than Sirius and looked absolutely dynamite through a backyard telescope. Planetary scientist Scott Bolton of the Southwest Research Institute isn’t satisfied. "I’d like to get even closer," he says. Bolton will get his wish in July 2016. That’s when a NASA spacecraft named "Juno" arrives at Jupiter for a truly close-up look at the giant planet. Swooping as low as 5,000 km (about 3,000 miles) above the cloud tops, Juno will spend a full year orbiting nearer to Jupiter than any previous spacecraft. The goal of the mission is to learn what lies inside the planet. Astronomers have been studying Jupiter since the invention of the telescope 400 years ago, but in all that time the planet’s vast interior has remained hidden from view. Even the Galileo probe, which dived into the clouds in 1995, penetrated no more than about 0.1% of Jupiter’s radius. "Our knowledge of Jupiter is truly skin deep," says Bolton, Juno’s principal investigator. "There are many basic things we just don’t know - like how far down does the Great Red Spot go? And does Jupiter have a heavy core?" Juno will improve the situation without actually diving into the clouds. Bolton explains how. "Juno will spend a full year in close polar orbit around Jupiter, flying over all latitudes and longitudes. We will thus be able to fully map Jupiter’s gravitational field and figure out how the interior is structured." But that’s not all. Researchers have good reason to believe that much of Jupiter’s interior is filled with liquid metallic hydrogen, an exotic metal that could form only in the high-pressure, hydrogen-rich core of a giant planet. Jupiter’s powerful magnetic field almost certainly springs from dynamo action inside this vast realm of electrically conducting metal. "Juno’s magnetometers will precisely map Jupiter’s magnetic field," says Bolton. "This map will tell us a great deal about planet’s inner magnetic dynamo - what it’s made of and how it works." Finally, Juno will probe Jupiter’s atmosphere using a set of microwave radiometers. "Our sensors can measure the temperature 50 times deeper than ever before," says Bolton. Researchers will use that information to figure out how much water is underneath Jupiter’s clouds. "Microwave measurements of Jupiter’s water content are particularly exciting because they will help discriminate among competing theories of the planet’s origin." Now that’s a close encounter. Stay tuned for Juno. Find out more about the Juno mission at http://www.nasa.gov/mission_pages/juno. Play the new Solar System Explorer super game, which includes the Juno Recall mini-game at http://spaceplace.nasa.gov/en/kids/solar-system. It’s not just for kids! This article was provided courtesy of the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Juno mission, arriving at Jupiter in July 2016, will help to solve the mystery of what’s inside the giant planet’s core. The Hunt is On!by Carolyn Brinkworth The world of astronomy was given new direction on August 13, 2010, with the publication of the Astro2010 Decadal Survey. Astro2010 is the latest in a series of surveys produced every 10 years by the National Research Council (NRC) of the National Academy of Sciences. This council is a team of senior astronomers who recommend priorities for the most important topics and missions for the next decade. Up near the top of their list this decade is the search for Earth-like planets around other stars - called "extrasolar planets" or "exoplanets" - which has become one of the hottest topics in astronomy. The first planet to be found orbiting a star like our Sun was discovered in 1995. The planet, called "51 Peg b," is a "Hot Jupiter." It is about 160 times the mass of Earth and orbits so close to its parent star that its gaseous "surface" is seared by its blazing sun. With no solid surface, and temperatures of about 1000 degrees Celsius (1700 Fahrenheit), there was no chance of finding life on this distant world. Since that discovery, astronomers have been on the hunt for smaller and more Earth-like planets, and today we know of around 470 extrasolar planets, ranging from about 4 times to 8000 times the mass of Earth. This explosion in extrasolar planet discoveries is only set to get bigger, with a NASA mission called Kepler that was launched last year. After staring at a single small patch of sky for 43 days, Kepler has detected the definite signatures of seven new exoplanets, plus 706 "planetary candidates" that are unconfirmed and in need of further investigation. Kepler is likely to revolutionize our understanding of Earth's place in the Universe. We don't yet have the technology to search for life on exoplanets. However, the infrared Spitzer Space Telescope has detected molecules that are the basic building blocks of life in two exoplanet atmospheres. Most extrasolar planets appear unsuitable for supporting life, but at least two lie within the "habitable zone" of their stars, where conditions are theoretically right for life to gain a foothold. We are still a long way from detecting life on other worlds, but in the last 20 years, the number of known planets in our Universe has gone from the 8 in our own Solar System to almost 500. It's clear to everyone, including the Astro2010 decadal survey team, that the hunt for exoplanets is only just beginning, and the search for life is finally underway in earnest. Explore Spitzer’s latest findings at http://www.spitzer.caltech.edu. Kids can dream about finding other Earths as they read "Lucy’s Planet Hunt" at http://spaceplace.nasa.gov/en/kids/storybooks/#lucy. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering of hot gas planet HD209458b. Both the Hubble and Spitzer Space Telescopes have detected carbon dioxide, methane, and water vapor - in other words, the basic chemistry for life - in the atmosphere of this planet, although since it is a hot ball of gas, it would be unlikely to harbor life. The Turbulent Tale of a Tiny Galaxyby Trudy Bell and Dr. Tony Phillips Next time you hike in the woods, pause at a babbling stream. Watch carefully how the water flows around rocks. After piling up in curved waves on the upstream side, like the bow wave in front of a motorboat, the water speeds around the rock, spilling into a riotous, turbulent wake downstream. Lightweight leaves or grass blades can get trapped in the wake, swirling round and round in little eddy currents that collect debris. Astronomers have found something similar happening in the turbulent wake of a tiny galaxy that is plunging into a cluster of 1,500 galaxies in the constellation Virgo. In this case, however, instead of collecting grass and leaves, eddy currents in the little galaxy’s tail seem to be gathering gaseous material to make new stars. "It’s a fascinating case of turbulence [rather than gravity] trapping the gas, allowing it to become dense enough to form stars," says Janice A. Hester of the California Institute of Technology in Pasadena. The tell-tale galaxy, designated IC 3418, is only a hundredth the size of the Milky Way and hardly stands out in visible light images of the busy Virgo Cluster. Astronomers realized it was interesting, however, when they looked at it using NASA's Galaxy Evolution Explorer satellite. "Ultraviolet images from the Galaxy Evolution Explorer revealed a long tail filled with clusters of massive, young stars," explains Hester. Galaxies with spectacular tails have been seen before. Usually they are behemoths - large spiral galaxies colliding with one another in the crowded environment of a busy cluster. Tidal forces during the collision pull gas and stars of all ages out of these massive galaxies to form long tails. But in IC 3418, the tail has just young stars. No old stars. "The lack of older stars was one tip-off that IC 3418’s tail isn’t tidal," says Hester. "Something else must be responsible for these stars." Hester and eight coauthors published their findings in the June 10, 2010, issue of The Astrophysical Journal Letters. The team described the following scenario: IC 3418 is speeding toward the center of the Virgo cluster at 1,000 kilometers per second. The space between cluster galaxies is not empty; it is filled with a gaseous atmosphere of diffuse, hot hydrogen. Thus, like a bicyclist coasting downhill feels wind even on a calm day, IC 3418 experiences "a stiff wind" that sweeps interstellar gas right out of the little galaxy, said Hester - gas that trails far behind its galaxy in a choppy, twisting wake akin to the wake downstream of the rock in the babbling brook. Eddy currents swirling in the turbulent wake trap the gas, allowing it to become dense enough to form stars. "Astronomers have long debated the importance of gravity vs. turbulence in star formation," Hester noted. "In IC 3418’s tail, it’s ALL turbulence." To many astronomers, that’s a surprising tale indeed. See other surprising UV images from the Galaxy Evolution Explorer at http://www.galex.caltech.edu. Kids (and grownups) can play the challenging new Photon Pileup game at http://spaceplace.nasa.gov/en/kids/galex/photon/. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: In the ultraviolet image on the left, from the Galaxy Evolution Explorer, galaxy IC 3418 leaves a turbulent star forming region in its wake. In the visible light image on the right (from the Sloan Digital Sky Survey), the wake with its new stars is not apparent. The Sun Can Still Remind Us Who’s Bossby Dr. Tony Phillips Grab your cell phone and take a good long look. It's indispensible, right? It tells time, surfs the web, keeps track of your appointments and, by the way, also makes phone calls. Modern people can hardly live without one. One good solar flare could knock it all out. "In the 21st century, we’re increasingly dependent on technology," points out Tom Bogdan, director of NOAA's Space Weather Prediction Center in Boulder, Colorado. "This makes solar activity an important part of our daily lives." Indeed, bad space weather can knock out power systems, telecommunications, financial and emergency services - basically, anything that needs electronics to work. That’s why NOAA is building a new fleet of "space weather stations," the GOES-R satellites. "GOES-R will bring our existing fleet of weather satellites into the 21st century," says Bogdan. "They're designed to monitor not only Earth weather, but space weather as well." NOAA's existing fleet of Geostationary Operational Environmental Satellites (GOES) already includes some space weather capabilities: solar ultraviolet and X-ray telescopes, a magnetometer and energetic particle sensors. GOES-R will improve upon these instruments and add important new sensors to the mix. One of Bogdan’s favorites is a particle detector named "MPS-Low," which specializes in sensing low-energy (30 ev - 30 keV) particles from the sun. Who cares about low-energy particles? It turns out they can be as troublesome as their high-energy counterparts. Protons and other atomic nuclei accelerated to the highest energies by solar flares can penetrate a satellite’s exterior surface, causing all kinds of problems when they reach internal electronics. Low-energy particles, particularly electrons, can’t penetrate so deeply. Instead, they do their damage on the outside. As Bogdan explains, "Low-energy particles can build up on the surfaces of spacecraft, creating a mist of charge. As voltages increase, sparks and arcs can zap electronics - or emit radio pulses that can be misinterpreted by onboard computers as a command." The Galaxy 15 communications satellite stopped working during a solar wind storm in April 2010, and many researchers believe low-energy particles are to blame. GOES-R will be able to monitor this population of particles and alert operators when it’s time to shut down sensitive systems. "This is something new GOES-R will do for us," says Bogdan. The GOES-R magnetometer is also a step ahead. It will sample our planet’s magnetic field four times faster than its predecessors, sensing vibrations that previous GOES satellites might have missed. Among other things, this will help forecasters anticipate the buildup of geomagnetic storms. And then there are the pictures. GOES-R will beam back striking images of the sun at X-ray and extreme UV wavelengths. These are parts of the electromagnetic spectrum where solar flares and other eruptions make themselves known with bright flashes of high-energy radiation. GOES-R will pinpoint the flashes and identify their sources, allowing forecasters to quickly assess whether or not Earth is in the "line of fire." They might also be able to answer the question, Is my cell phone about to stop working? The first GOES-R satellite is scheduled for launch in 2015. Check www.goes-r.gov for updates. Space weather comes down to Earth in the clear and fun explanation for young people on SciJinks, http://scijinks.gov/space-weather-and-us. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: In spite of Earth’s protective magnetosphere, solar storms can wreak havoc with Earth satellites and other expensive electronics on the ground. Black Holes No Jokeby Dr. Tony Phillips Kip Thorne: Why was the black hole hungry? Stephen Hawking: It had a light breakfast! Black hole humor - you gotta love it. Unless you’re an astronomer, that is. Black holes are among the most mysterious and influential objects in the cosmos, yet astronomers cannot see into them, frustrating their attempts to make progress in fields ranging from extreme gravity to cosmic evolution. How do you observe an object that eats light for breakfast? "Black holes are creatures of gravity," says physicist Marco Cavaglia of the University of Mississippi. "So we have to use gravitational waves to explore them." Enter LIGO - the NSF-funded Laser Interferometer Gravitational-wave Observatory. According to Einstein’s Theory of General Relativity, black holes and other massive objects can emit gravitational waves - ripples in the fabric of space-time that travel through the cosmos. LIGO was founded in the 1990s with stations in Washington state and Louisiana to detect these waves as they pass by Earth. "The principle is simple," says Cavaglia, a member of the LIGO team. "Each LIGO detector is an L-shaped ultra-high vacuum system with arms four kilometers long. We use lasers to precisely measure changes in the length of the arms, which stretch or contract when a gravitational wave passes by." Just one problem: Gravitational waves are so weak, they change the length of each detector by just 0.001 times the width of a proton! "It is a difficult measurement," allows Cavaglia. Seismic activity, thunderstorms, ocean waves, even a truck driving by the observatory can overwhelm the effect of a genuine gravitational wave. Figuring out how to isolate LIGO from so much terrestrial noise has been a major undertaking, but after years of work the LIGO team has done it. Since 2006, LIGO has been ready to detect gravitational waves coming from spinning black holes, supernovas, and colliding neutron stars anywhere within about 30 million light years of Earth. So far the results are...nil. Researchers working at dozens of collaborating institutions have yet to report a definite detection. Does this mean Einstein was wrong? Cavaglia doesn’t think so. "Einstein was probably right, as usual," he says. "We just need more sensitivity. Right now LIGO can only detect events in our little corner of the Universe. To succeed, LIGO needs to expand its range." So, later this year LIGO will be shut down so researchers can begin work on Advanced LIGO - a next generation detector 10 times more sensitive than its predecessor. "We’ll be monitoring a volume of space a thousand times greater than before," says Cavaglia. "This will transform LIGO into a real observational tool." When Advanced LIGO is completed in 2014 or so, the inner workings of black holes could finally be revealed. The punch line may yet make astronomers smile. Find out more about LIGO at http://www.ligo.caltech.edu/ The Space Place has a LIGO explanation for kids (of all ages) at http://spaceplace.nasa.gov/en/kids/ligo, where you can "hear" a star and a black hole colliding! This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Laser Interferometer Gravitational-wave Observatory in Livingston, Louisiana. Each of the two arms is 4 kilometers long. LIGO has another such observatory in Hanford, Washington. Ancient Supernova Riddle, Solvedby Dr. Tony Phillips Australopithecus squinted at the blue African sky. He had never seen a star in broad daylight before, but he could see one today. Was it dangerous? He stared for a long time, puzzled, but nothing happened, and after a while he strode across the savanna unconcerned. Millions of years later, we know better. That star was a supernova, one of many that exploded in our corner of the Milky Way around the Pliocene era of pre-humans. Australopithecus left no records; we know the explosions happened because their debris is still around. The solar system and everything else within about 300 light-years is surrounded by supernova exhaust - a haze of million-degree gas that permeates all of local space. Supernovas are dangerous things, and when one appears in the daytime sky, it is cause for alarm. How did Earth survive? Modern astronomers believe the blasts were too far away (albeit not by much) to zap our planet with lethal amounts of radiation. Also, the Sun’s magnetic field has done a good job holding the hot gas at bay. In other words, we lucked out. The debris from those old explosions has the compelling power of a train wreck; astronomers have trouble tearing their eyes away. Over the years, they’ve thoroughly surveyed the wreckage and therein found a mystery - clouds of hydrogen and helium apparently too fragile to have survived the blasts. One of them, whimsically called "the Local Fluff," is on the doorstep of the solar system. The observed temperature and density of the Fluff do not provide enough pressure to resist the crushing action of the hot supernova gas around it," says astronomer Merav Opher of George Mason University. "It makes us wonder, how can such a cloud exist?" NASA’s Voyager spacecraft may have found the answer. NASA's two Voyager probes have been racing out of the solar system for more than 30 years. They are now beyond the orbit of Pluto and on the verge of entering interstellar space. "The Voyagers are not actually inside the Local Fluff," explains Opher. "But they are getting close and can sense what the cloud is like as they approach it." And the answer is... "Magnetism," says Opher. "Voyager data show that the Fluff is strongly magnetized with a field strength between 4 and 5 microgauss. This magnetic field can provide the pressure required to resist destruction." If fluffy clouds of hydrogen can survive a supernova blast, maybe it’s not so surprising that we did, too. "Indeed, this is helping us understand how supernovas interact with their environment - and how destructive the blasts actually are," says Opher. Maybe Australopithecus was on to something after all. Opher’s original research describing Voyager’s discovery of the magnetic field in the Local Fluff may be found in Nature, 462, 1036-1038 (24 December 2009). The Space Place has a new Amazing Fact page about the Voyagers’ Golden Records, with sample images and sounds of Earth. Just in case one of the Voyager’s ever meets up with ET, we will want to introduce ourselves. Visit http://spaceplace.nasa.gov/en/kids/voyager. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Left-over cloud from the Tycho supernova, witnessed by Tycho Brahe and other astronomers over 400 years ago. This image combines infrared light captured by the Spitzer Space Telescope with x-rays captured by the Chandra X-ray Observatory, plus visible light from the Calar Also Observatory in Spain. A Rock Hound is BornIt’s tough to be a geologist when you can’t tell one rock from another. Is that a meteorite or a chunk of lava? A river rock or an impact fragment? Houston, we have a problem! It’s a problem Spirit and Opportunity have been dealing with for the past six years. The two rovers are on a mission to explore the geology of the Red Planet, yet for the longest time they couldn’t recognize interesting rocks without help from humans back on Earth. Fortunately, it is possible to teach old rovers new tricks. All you have to do is change their programming - and that’s just what NASA has done. "During the winter, we uploaded new software to Opportunity," says Tara Estlin, a rover driver, senior member of JPL’s Artificial Intelligence Group, and the lead developer of AEGIS, short for Autonomous Exploration for Gathering Increased Science. "AEGIS allows the rover to make some decisions on its own." Estlin and her team have been working for several years to develop and upload increasingly sophisticated software to the rovers. As a result, the twins have learned to avoid obstacles, identify dust devils, and calculate the distance to reach their arms to a rock. With the latest upgrade, a rock hound is born. Now, Opportunity's computer can examine images that the rover takes using its wide-angle navigation camera (NavCam) and pick out rocks with interesting colors or shapes. It can then center its narrower-angle panoramic camera (PanCam) on targets of interest for close-up shots through various color filters. All this happens without human intervention. The system was recently put to the test; Opportunity performed splendidly. At the end of a drive on March 4th, the rover settled in for a bit of rock hunting. Opportunity surveyed the landscape and decided that one particular rock, out of more than 50 in the NavCam photo, best met criteria that researchers had set for a target of interest: large and dark. "It found exactly the target we would want it to find," Estlin says. "It appears to be one of the rocks tossed outward onto the surface when an impact dug a nearby crater." The new software doesn’t make humans obsolete. On the contrary, humans are very much "in the loop," setting criteria for what’s interesting and evaluating Opportunity’s discoveries. The main effect of the new software is to strengthen the rover-human partnership and boost their combined exploring prowess. Mindful that Opportunity was only supposed to last about six months after it landed in 2004, Estlin says, "It is amazing to see Opportunity performing a brand new autonomous activity six years later." What will the rock hounds of Mars be up to six years from now? Stay tuned for future uploads! Learn more about how the AEGIS software works at http://scienceandtechnology.jpl.nasa.gov/newsandevents/newsdetails/?NewsID=677 If you work with middle- or high-school kids, you’ll find a fun way to explore another kind of robot software - the kind that enables "fuzzy thinking" - at http://spaceplace.nasa.gov/en/educators/teachers_page2.shtml#fuzzy This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Opportunity spots a rock with its NavCam that its AEGIS software says meets all the criteria for further investigation. Deadly Planetsby Patrick L. Barry and Dr. Tony Phillips About 900 light years from here is a rocky planet not much bigger than Earth. It goes around its star once every hundred days, a trifle fast, but not too different from a standard Earth-year. At least two and possibly three other planets circle the same star, forming a complete solar system. Interested? Don't be. Going there would be the last thing you ever do. The star is a pulsar, PSR 1257+12, the seething-hot core of a supernova that exploded millions of years ago. Its planets are bathed not in gentle, life-giving sunshine but instead a blistering torrent of X-rays and high-energy particles. "It would be like trying to live next to Chernobyl," says Charles Beichman, a scientist at JPL and director of the Michelson Science Center at Caltech. Our own Sun emits small amounts of pulsar-like X-rays and high energy particles, but the amount of such radiation coming from a pulsar is "orders of magnitude more," he says. Even for a planet orbiting as far out as the Earth, this radiation could blow away the planet's atmosphere, and even vaporize sand right off the planet's surface. Astronomer Alex Wolszczan discovered planets around PSR 1257+12 in the 1990s using Puerto Rico’s giant Arecibo radio telescope. At first, no one believed worlds could form around pulsars - it was too bizarre. Supernovas were supposed to destroy planets, not create them. Where did these worlds come from? NASA’s Spitzer Space Telescope may have found the solution. In 2005, a group of astronomers led by Deepto Chakrabarty of MIT pointed the infrared telescope toward pulsar 4U 0142+61. Data revealed a disk of gas and dust surrounding the central star, probably wreckage from the supernova. It was just the sort of disk that could coalesce to form planets! As deadly as pulsar planets are, they might also be hauntingly beautiful. The vaporized matter rising from the planets' surfaces could be ionized by the incoming radiation, creating colorful auroras across the sky. And though the pulsar would only appear as a tiny dot in the sky (the pulsar itself is only 20-40 km across), it would be enshrouded in a hazy glow of light emitted by radiation particles as they curve in the pulsar's strong magnetic field. Wasted beauty? Maybe. Beichman points out the positive: "It's an awful place to try and form planets, but if you can do it there, you can do it anywhere." Find more news and images from Spitzer at http://www.spitzer.caltech.edu/ In addition, The Space Place Web site features several games related to Spitzer and infrared astronomy, as well as a storybook about a girl who dreamed of finding another Earth. Go to http://tiny.cc/lucy208 This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s concept of a pulsar and surrounding disk of rubble called a "fallback" disk, out of which new planets could form. Flipping the Lights on Cosmic DarknessExploring the universe is a bit like groping around a dark room. Aside from the occasional pinprick of starlight, most objects lurk in pitch darkness. But with the recent launch of the largest-ever infrared space telescope, it's like someone walked into the room and flipped on the lights. Suddenly, those dark spaces between stars don’t appear quite so empty. Reflected in the Herschel Space Observatory's 3.5-meter primary mirror, astronomers can now see colder, darker celestial objects than ever before - from the faint outer arms of distant galaxies to the stealthy "dark asteroids" of our own solar system. Many celestial objects are too cold to emit visible light, but they do shine at much longer infrared wavelengths. And Herschel can observe much longer infrared wavelengths than any space telescope before (up to 672 microns). Herschel also has 16 times the collecting area, and hence 16 times better resolution, than previous infrared space telescopes. That lets it resolve details with unprecedented clarity. Together, these abilities open a new window onto the universe. "The sky looks much more crowded when you look in infrared wavelengths," says George Helou, director of the NASA Herschel Science Center at Caltech. "We can't observe the infrared universe from the ground because our atmosphere blocks infrared light, and emits infrared itself. Once you get above the atmosphere, all of this goes away and suddenly you can look without obstruction." Herschel launched in May from the Guiana Space Centre in French Guiana aboard a European Space Agency Ariane 5 rocket. Since then, it has expanded the number of distant galaxies observed at far infrared wavelengths from a few hundred to more than 28,000. And with the instrument testing and system check-out phases finally completed, the discoveries are only now beginning. Beyond simply imaging these dark objects, Herschel can identify the presence of chemicals such as carbon monoxide and water based on their spectral fingerprints. "We will be able to decipher the chemistry of what's going on during the beginnings of star formation, in the discs of dust and gas that form planets, and in the lingering aftermath of stellar explosions," Helou says. And those are just the expected things. Who knows what unexpected discoveries may come from "flipping on the lights?" Helou says, "We can't wait to find out." Herschel is a European Space Agency mission, with science instruments provided by a consortium of European-led institutes and with important participation by NASA. See the ESA Herschel site at http://sci.esa.int/science-e/www/area/index.cfm?fareaid=16 Also, see the NASA sites at http://herschel.jpl.nasa.gov/ and http://www.herschel.caltech.edu/ and http://www.nasa.gov/mission_pages/herschel/ Kids can learn about infrared light by browsing through the Infrared Photo Album at The Space Place, http://spaceplace.nasa.gov/en/kids/sirtf1/sirtf_action.shtml This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Herschel Space Observatory has 3.5-meter primary mirror, allowing astronomers to see colder, darker celestial objects than ever before. Building a Case Against Ozoneby Patrick Barry When it comes to notorious greenhouse gases, carbon dioxide is like Al Capone - always in the headlines. Meanwhile, ozone is more like Carlo Gambino - not as famous or as powerful, but still a big player. After tracking this lesser-known climate culprit for years, NASA’s Tropospheric Emission Spectrometer (TES) has found that ozone is indeed a shifty character. Data from TES show that the amount of ozone - and thus its contribution to the greenhouse effect - varies greatly from place to place and over time. "Ozone tends to be localized near cities where ozone precursors, such as car exhaust and power plant exhaust, are emitted," says Kevin Bowman, a senior member of the TES technical staff at the Jet Propulsion Laboratory. But the ozone doesn't necessarily stay in one place. Winds can stretch the ozone into long plumes. "Looking out over the ocean we can see ozone being transported long distances over open water." Unlike CO2, ozone is highly reactive. It survives in the atmosphere for only a few hours or a few days before it degrades and effectively disappears. So ozone doesn't have time to spread out evenly in the atmosphere the way that CO2 does. The amount of ozone in one place depends on where ozone-creating chemicals, such as the nitrogen oxides in car exhaust. are being released and which way the wind blows. This short lifespan also means that ozone could be easier than CO2 to knock off. "If you reduce emissions of things that generate ozone, then you can have a quicker climate effect than you would with CO2," Bowman says. "From a policy standpoint, there’s been a lot of conversation lately about regulating short-lived species like ozone." To be clear, Bowman isn’t talking about the famous "ozone layer." Ozone in this high-altitude layer shields us from harmful ultraviolet light, so protecting that layer is crucial. Bowman is talking about ozone closer to the ground, so-called tropospheric ozone. This "other" ozone at lower altitudes poses health risks for people and acts as a potent greenhouse gas. TES is helping scientists track the creation and movement of low-altitude ozone over the whole planet each day. "We can see it clearly in our data," Bowman says. Countries will need this kind of data if they decide to go after the heat-trapping gas. Ozone has been caught red-handed, and TES is giving authorities the hard evidence they need to prosecute the case. Learn more about TES and its atmospheric science mission at tes.jpl.nasa.gov. The Space Place has a fun "Gummy Greenhouse Gases" activity for kids that will introduce them to the idea of atoms and molecules. Check it out at http://spaceplace.jpl.nasa.gov/en/kids/tes/gumdrops/ This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: These images are TES ozone plots viewed with Google Earth. Colors map to tropospheric ozone concentrations. The image on the left shows ozone concentrations at an altitude of approximately 32,000 feet, while the one on the right shows ozone at approximately 10,000 feet. The measurements are monthly averages over each grid segment for December 2004. Sunglasses for a Solar Observatoryby Patrick Barry In December 2006, an enormous solar flare erupted on the Sun’s surface. The blast hurled a billion-ton cloud of gas (a coronal mass ejection, or CME) toward Earth and sparked days of intense geomagnetic activity with Northern Lights appearing across much of the United States.
While sky watchers enjoyed the show from Earth's surface, something ironic was happening in Earth orbit.
At the onset of the storm, the solar flare unleashed an intense pulse of X-rays. The flash blinded the Solar X-Ray Imager (SXI) on NOAA's GOES-13 satellite, damaging several rows of pixels. SXI was designed to monitor solar flares, but it must also be able to protect itself in extreme cases.
That’s why NASA engineers gave the newest Geostationary Operational Environmental Satellite a new set of sophisticated "sunglasses." The new GOES-14 launched June 27 and reached geosynchronous orbit July 8.
Its "sunglasses" are a new flight-software package that will enable the SXI sensor to observe even intense solar flares safely. Radiation from these largest flares can endanger military and civilian communications satellites, threaten astronauts in orbit, and even knock out cities’ power grids. SXI serves as an early warning system for these flares and helps scientists better understand what causes them.
"We wanted to protect the sensor from overexposure, but we didn’t want to shield it so much that it couldn’t gather data when a flare is occurring," says Cynthia Tanner, SXI instrument systems manager for the GOES-NOP series at NASA’s Goddard Space Flight Center in Greenbelt, Maryland. (GOES-14 was called GOES-O before achieving orbit).
Shielding the sensor from X-rays also reduces the amount of data it can gather about the flare. It’s like stargazing with dark sunglasses on. So NASA engineers must strike a balance between protecting the sensor and gathering useful data.
When a dangerous flare occurs, the new SXI sensor can protect itself with five levels of gradually "darker" sunglasses. Each level is a combination of filters and exposure times carefully calibrated to control the sensor’s exposure to harmful high-energy X-rays.
As the blast of X-rays from a major solar flare swells, GOES-14 can step up the protection for SXI through these five levels. The damaged sensor on GOES-13 had only two levels of protection - low and high. Rather than gradually increasing the amount of protection, the older sensor would remain at the low level of protection, switching to the high level only when the X-ray dose was very high.
"You can collect more science while you’re going up through the levels of protection," Tanner says. "We’ve really fine-tuned it."
Forecasters anticipate a new solar maximum in 2012-2013, with plenty of sunspots and even more solar flares. "GOES-14 is ready," says Tanner.
For a great kid-level explanation of solar "indigestion" and space weather, check out http://spaceplace.jpl.nasa.gov/en/kids/goes/spaceweather/ This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: X-9 class solar flare December 6, 2006, as seen by GOES-13’s Solar X-ray Imager. It was one of the strongest flares in the past 30 years. A Cosmic Crash by Patrick Barry and Dr. Tony Phillips Two small planets hurtle toward each other at 22,000 miles per hour. They’re on a collision course. With unimaginable force, they smash into each other in a flash of light, blasting streams of molten rock far out into space. This cataclysmic scene has happened countless times in countless solar systems. In fact, scientists think that such collisions could have created Earth’s moon, tilted Uranus on its side, set Venus spinning backward, and sheared the crust off Mercury. But witnessing such a short-lived collision while pointing your telescope in just the right direction would be a tremendous stroke of luck. Well, astronomers using NASA’s Spitzer space telescope recently got lucky. "It’s unusual to catch such a collision in the act, that’s for sure," said Geoffrey Bryden, A cosmic Crashspitzer - an astronomer specializing in extrasolar planet formation at NASA’s Jet Propulsion Laboratory and a member of the science team that made the discovery. When Bryden and his colleagues pointed Spitzer at a star 100 light-years away called HD 172555, they noticed something strange. Patterns in the spectrum of light coming from nearby the star showed distinctive signs of silicon monoxide gas - huge amounts of it - as well as a kind of volcanic rock called tektite. It was like discovering the wreckage from a cosmic car crash. The silicon monoxide was produced as the high-speed collision literally vaporized huge volumes of rock, which is made largely of silicon and oxygen. The impact also blasted molten lava far out into space, where it later cooled to form chunks of tektite. Based on the amount of silicon monoxide and tektites, Bryden’s team calculated that the colliding planetary bodies must have had a combined mass more than twice that of Earth’s moon. The collision probably happened between 1,000 and 100,000 years ago - a blink of an eye in cosmic terms. The scientists used the Spitzer space telescope because, unlike normal telescopes, Spitzer detects light at invisible, infrared wavelengths. "Spitzer wavelengths are the best wavelengths to identify types of rock," Bryden says. "You can pin down which type of rock, dust, or gas you’re looking at." Bryden says the discovery provides further evidence that planet-altering collisions are more common in other star systems than people once thought. The "crash-bang" processes at work in our own solar system may indeed be universal. If so, Spitzer has a front row seat on a truly smashing show. See Spitzer Space Telescope’s brand new Web site at http://spitzer.caltech.edu/ Kids can learn about infrared light and see beautiful Spitzer images by playing the new Spitzer Concentration game at http://spaceplace.jpl.nasa.gov/en/kids/spitzer/concentration This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering of cosmic collision involving two objects whose combined mass was at least twice that of our Moon. Discovered using the Spitzer Space Telescope in the planetary system of a star called HD 172555 100 light-years away. Staring at LightningThere’s something mesmerizing about watching a thunderstorm. You stare at the dark, dramatic clouds waiting for split-second bursts of brilliant light - intricate bolts of lightning spidering across the sky. Look away at the wrong time and (FLASH!) you miss it. Lightning is much more than just a beautiful spectacle, though. It’s a window into the heart of the storm, and it could even provide clues about climate change. Strong vertical motions within a storm cloud help generate the electricity that powers lightning. These updrafts are caused when warm, moist air rises. Because warmth and lightning are inextricably connected, tracking long-term changes in lightning frequency could reveal the progress of climate change. It’s one of many reasons why scientists want to keep an unwavering eye on lightning. The best way to do that? With a satellite 35,800 km overhead. At that altitude, satellites orbit at just the right speed to remain over one spot on the Earth’s surface while the planet rotates around its axis - a "geostationary" orbit. NASA and NOAA scientists are working on an advanced lightning sensor called the Geostationary Lightning Mapper (GLM) that will fly onboard the next generation geostationary operational environmental satellite, called GOES-R, slated to launch around 2015. "GLM will give us a constant, eye-in-the-sky view of lightning over a wide portion of the Earth," says Steven Goodman, NOAA chief scientist for GOES-R at NASA’s Goddard Space Flight Center. Once GLM sensors are flying on GOES-R and its sister GOES-S, that view will extend 18,000 km from New Zealand, east across the Pacific Ocean, across the Americas, and to Africa’s western coast. With this hemisphere-scale view, scientists will gather an unprecedented amount of data on how lightning varies from place to place, year to year, and even decade to decade. Existing lightning sensors are either on the ground - which limits their geographic range - or on satellites that orbit much closer to Earth. These satellites circle the Earth every 90 minutes or so, quickly passing over any one area, which can leave some awkward gaps in the data. Goodman explains: "Low-Earth orbit satellites observe a location such as Florida for only a minute at a time. Many of these storms occur in the late afternoon, and if the satellite’s not overhead at that time, you’re going to miss it." GLM, on the other hand, won't miss a thing. Indeed, in just two weeks of observations, GLM is expected gather more data than NASA’s two low-Earth orbiting research sensors did in 10+ years. The new data will have many uses beyond understanding climate change. For example, wherever lightning flashes are abundant, scientists can warn aircraft pilots of strong turbulence. The data may also offer new insights into the evolution of storms and prompt improvements in severe weather forecasting. (FLASH!) Did you miss another one? The time has come for GLM. Want to know how to build a weather satellite? Check the "how to" booklet at http://scijinks.jpl.nasa.gov//weather/technology/build_satellite/ This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Geostationary Lightning Mapper (GLM) on the next generation of GOES satellites will detect the very rapid and transient bursts of light produced by lightning at near-infrared wavelengths. This image was taken from the International Space Station and shows the Aurora Australis and lightning. Spitzer, the SequelThe Spitzer Space Telescope is getting a second chance at life. The liquid helium "lifeblood" that flows through the telescope has finally run out, bringing Spitzer's primary mission to an end. But a new phase of this infrared telescope's exploration of the universe is just beginning. Even without liquid helium, which cooled the telescope to about 2 degrees above absolute zero (-271°C), Spitzer will continue to do important research - some of which couldn't easily be done during its primary mission. For example, scientists will use Spitzer's "second life" to explore the rate of expansion of the universe, study variable stars, and search for near-Earth asteroids that could pose a threat to our planet. "We always knew that a 'warm phase' of the mission was a possibility, but it became ever more exciting scientifically as we started to plan for it seriously," says JPL's Michael Werner, Project Scientist for Spitzer. "Spitzer is just going on and on like the Energizer bunny." Launched in August 2003 as the last of NASA's four Great Observatories, Spitzer specializes in observing infrared light, which is invisible to normal, optical telescopes. That gives Spitzer the power to see relatively dark, cool objects such as planet-forming discs or nearby asteroids. These objects are too cold to emit light at visible wavelengths, but they're still warm enough to emit infrared light. In fact, all warm objects "glow" with infrared light - even telescopes. That's why Spitzer had to be cooled with liquid helium to such a low temperature. Otherwise, it would be blinded by its own infrared glow. As the helium expires, Spitzer will warm to about 30 degrees above absolute zero (-243°C). At that temperature, the telescope will begin emitting long-wavelength infrared light, but two of its short-wavelength sensors will still work perfectly. And with more telescope time available for the remaining sensors, mission managers can more easily schedule new research proposals designed for those sensors. For example, scientists have recently realized how to use infrared observations to improve our measurements of the rate of expansion of the universe. And interest in tracking near-Earth objects has grown in recent years - a task for which Spitzer is well suited. "Science has progressed, and people always have new ideas," Werner says. In its second life, Spitzer will help turn those ideas into new discoveries. For kids, The Space Place Web site has a fun typing game using Spitzer and infrared astronomy words. Check it out at http://spaceplace.jpl.nasa.gov/en/kids/spitzer/signs/ This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The "warm mission" of the Spitzer Space Telescope will still be able to use two sensors in its Infrared Array Camera (IRAC) to continue its observations of the infrared universe. A Planet Named Easterbunny?You know Uranus, Neptune, and Pluto. But how about their smaller cousins Eris, Ceres, Orcus, and Makemake? How about Easterbunny? These are all names given to relatively large "planet-like" objects recently found in the outer reaches of our solar system. Some were just temporary nicknames, others are now official and permanent. Each has a unique story. "The names we chose are important," says Caltech astronomer Mike Brown, who had a hand in many of the discoveries. "These objects are a part of our solar system; they're in our neighborhood. We ‘gravitate’ to them more if they have real names, instead of technical names like 2003 UB313." Nearby planets such as Venus and Mars have been known since antiquity and were named by the ancient Romans after their gods. In modern times, though, who gets to name newly discovered dwarf planets and other important solar-system bodies? In short, whoever finds it names it. For example, a few days after Easter 2005, Brown and his colleagues discovered a bright dwarf planet orbiting in the Kuiper belt. The team’s informal nickname for this new object quickly became Easterbunny. However, ever since its formation in 1919, the International Astronomical Union (IAU) ultimately decides whether to accept or reject the name suggested by an object’s discoverers. "Easterbunny" probably wouldn’t be approved. According to IAU guidelines, comets are named after whoever discovered them - such as comet Hale-Bopp, named after its discoverers Alan Hale and Thomas Bopp. Asteroids can be named almost anything. IAU rules state that objects in the Kuiper belt should be given mythological names related to creation. So Brown’s team started brainstorming. They considered several Easter-esque names: Eostre, the pagan mythological figure that may be Easter’s namesake; Manabozho, the Algonquin rabbit trickster god. In the end, they settled on Makemake (pronounced MAH-kay MAH-kay), the creator of humanity in the mythology of Easter Island, so named because Europeans first arrived there on Easter 1722. Other names have other rationales. The dwarf planet discovered in 2005 that triggered a fierce debate over Pluto’s status was named Eris, for the Greek goddess of strife and discord. Another dwarf planet with an orbit that mirrors Pluto’s was dubbed Orcus, a god in Etruscan mythology that, like Pluto, ruled the underworld. Brown says he takes "this naming business" very seriously and probably spends too much time on it. "But I enjoy it." More tales of discovery and naming may be found in Brown's blog at http://www.mikebrownsplanets.com/ Constellations have also been named after ancient gods, human figures, and animals. Kids can start to learn their constellations by making a Star Finder for this month at http://spaceplace.nasa.gov/en/kids/st6starfinder/st6starfinder.shtml There you will also find a handy explanation of why astrology has no place in science.This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering of dwarf planet MakeMake, discovered around Easter 2005. Unlikely to gain acceptance their nickname Easterbunny, the discoverers named it for the god of humanity in the mythology of Easter Island. SARSAT to the RescueIf a plane crashes in the woods and nobody hears it, does it make a sound? Never mind contemplating this scenario as a philosophical riddle. This can be a real life or death question. And the answer most of the time is that, even if no people are nearby, "something" is indeed listening high above. That something is a network of satellites orbiting about 450 miles overhead. The "sound" they hear isn’t the crash itself, but a distress signal from a radio beacon carried by many modern ships, aircraft, and even individual people venturing into remote wildernesses. In the last 25 years, more than 25,000 lives have been saved using the satellite response system called Search and Rescue Satellite-aided Tracking (SARSAT). So what are these life-saving superhero satellites? Why, they are mild-mannered weather satellites. "These satellites do double duty," says Mickey Fitzmaurice, a National Oceanic and Atmospheric Administration (NOAA) systems engineer for SARSAT. "Their primary purpose is to gather continuous weather data, of course. But while they’re up there, they might as well be listening for distress signals too." In February, NASA launched the newest of these Polar-orbiting Operational Environmental Satellites (or POES) into orbit. This new satellite, called N-Prime at launch and now dubbed NOAA-19, prevents a gap in this satellite network as another, aging NOAA satellite reached the end of its operational life. "The launch of N-Prime was a big deal for us," Fitzmaurice says. With N-Prime/NOAA-19 in place, there are now six satellites in this network. Amongst them, they pass over every place on Earth, on average, about once an hour. To pinpoint the location of an injured explorer, a sinking ship, or a downed plane, POES use the same Doppler effect that causes a car horn to sound higher-pitched when the car is moving toward you than it sounds after it passes by. In a similar way, POES "hear" a higher frequency when they’re moving toward the source of the distress signal, and a lower frequency when they’ve already passed overhead. It takes only three distress-signal bursts - each about 50 seconds apart - to determine the source’s location. Complementing the POES are the Geostationary Operational Environmental Satellites (GOES), which, besides providing weather data, continuously monitor the Western Hemisphere for distress signals. Since their geostationary orbit leaves them motionless with respect to Earth below, there is no Doppler effect to pinpoint location. However, they do provide near instantaneous notification of distress signals. In the future, the network will be expanded by putting receivers on new Global Positioning System (GPS) satellites, Fitzmaurice says. "We want to be able to locate you after just one burst." With GPS, GOES will also be able to provide the location of the transmitter. Philosophers beware: SARSAT is making "silent crashes" a thing of the past. Download a two-page summary of NOAA-19 at http://www.osd.noaa.gov/POES/NOAA-NP_Fact_Sheet.pdf Also, the Wild Weather Adventure game awaits kids at http://spaceplace.jpl.nasa.gov/en/kids/goes/wwa/ This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: NOAA's polar-orbiting and geostationary satellites, along with Russia's Cospas spacecraft, are part of the sophisticated, international Search and Rescue Satellite-Aided Tracking System. The Cool Chemistry of Alien LifeAlien life on distant worlds. What would it be like? For millennia people could only wonder, but now NASA’s Spitzer Space Telescope is producing some hard data. It turns out that life around certain kinds of stars would likely be very different from life as we know it. Using Spitzer, astronomers have discovered the organic chemical acetylene in the planet-forming discs surrounding 17 M-dwarf stars. It’s the first time any chemical has been detected around one of these small, cool stars. However, scientists are more intrigued by what was not there: a chemical called hydrogen cyanide (HCN), an important building block for life as we know it. "The fact that we do not detect hydrogen cyanide around cool stars suggests that that prebiotic chemistry may unfold differently on planets orbiting cool stars," says Ilaria Pascucci, lead scientist for the Spitzer observations and an astrophysicist at Johns Hopkins University in Baltimore, Maryland. That’s because HCN is the basic component for making adenine, one of the four information-carrying chemicals in DNA. All known life on Earth is based on DNA, but without adenine available, life in a dwarf-star solar system would have to make do without it. "You cannot make adenine in another way," Pascucci explains. "You need hydrogen cyanide." M-dwarf and brown dwarf stars emit far less ultraviolet light than larger, hotter stars such as our sun. Pascucci thinks this difference could explain the lack of HCN around dwarf stars. For HCN to form, molecules of nitrogen must first be split into individual nitrogen atoms. But the triple bond holding molecular nitrogen together is very strong. High-energy ultraviolet photons can break this bond, but the lower-energy photons from M-dwarf stars cannot. "Other nitrogen-bearing molecules are going to be affected by this same chemistry," Pascucci says, possibly including the precursors to amino acids and thus proteins. To search for HCN, Pascucci’s team looked at data from Spitzer, which observes the universe at infrared wavelengths. Planet-forming discs around M-dwarf stars have very faint infrared emissions, but Spitzer is sensitive enough to detect them. HCN’s distinctive 14-micron emission band was absent in the infrared spectra of the M-dwarf stars, but Spitzer did detect HCN in the spectra of 44 hotter, sun-like stars. Infrared astronomy will be a powerful tool for studying other prebiotic chemicals in planet-forming discs, says Pascucci, and the Spitzer Space Telescope is at the forefront of the field. Spitzer can’t yet draw us a picture of alien life forms, but it’s beginning to tell us what they could - and could not - be made of. "That’s pretty wonderful, too," says Pascucci. For news of other discoveries based on Spitzer data, visit http://www.spitzer.caltech.edu/ Kids can learn Spitzer astronomy words and concepts by playing the Spitzer "Sign Here!" game at http://spaceplace.jpl.nasa.gov/en/kids/spitzer/signs/ This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Do alien planets around other stars have the right ingredients for a pre-biotic soup? Scoring More Energy from Less SunlightFor spacecraft, power is everything. Without electrical power, satellites and robotic probes might as well be chunks of cold rock tumbling through space. Hundreds to millions of miles from the nearest power outlet, these spacecraft must somehow eke enough power from ambient sunlight to stay alive. That’s no problem for large satellites that can carry immense solar panels and heavy batteries. But in recent years, NASA has been developing technologies for much smaller microsatellites, which are lighter and far less expensive to launch. Often less than 10 feet across, these small spacecraft have little room to spare for solar panels or batteries, yet must still somehow power their onboard computers, scientific instruments, and navigation and communication systems. Space Technology 5 was a mission that proved, among other technologies, new concepts of power generation and storage for spacecraft. "We tested high efficiency solar cells on ST-5 that produce almost 60 percent more power than typical solar cells. We also tested batteries that hold three times the energy of standard spacecraft batteries of the same size," says Christopher Stevens, manager of NASA’s New Millennium Program. This program flight tests cutting-edge spacecraft technologies so that they can be used safely on mission-critical satellites and probes. "This more efficient power supply allows you to build a science-grade spacecraft on a miniature scale," Stevens says. Solar cells typically used on satellites can convert only about 18 percent of the available energy in sunlight into electrical current. ST-5 tested experimental cells that capture up to 29 percent of this solar energy. These new solar cells, developed in collaboration with the Air Force Research Laboratory in Ohio, performed flawlessly on ST-5, and they’ve already been swooped up and used on NASA’s svelte MESSENGER probe, which will make a flyby of Mercury later this year. Like modern laptop batteries, the high-capacity batteries on ST-5 use lithium-ion technology. As a string of exploding laptop batteries in recent years shows, fire safety can be an issue with this battery type. "The challenge was to take these batteries and put in a power management circuit that protects against internal overcharge," Stevens explains. So NASA contracted with ABSL Power Solutions to develop spacecraft batteries with design control circuits to prevent power spikes that can lead to fires. "It worked like a charm." Now that ST-5 has demonstrated the safety of this battery design, it is flying on NASA’s THEMIS mission (for Time History of Events and Macroscale Interactions during Substorms) and is slated to fly aboard the Lunar Reconnaissance Orbiter and the Solar Dynamics Observatory, both of which are scheduled to launch later this year. Thanks to ST-5, a little sunlight can go a really long way. Find out about other advanced technologies validated in space and now being used on new missions of exploration at http://nmp.nasa.gov/TECHNOLOGY/scorecard Kids can calculate out how old they would be before having to replace lithium-ion batteries in a handheld game at http://spaceplace.nasa.gov/en/kids/st5_bats.shtml This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Helen Johnson, a spacecraft technician at NASA's Goddard Space Flight Center, works on one of the three tiny Space Technology 5 spacecraft in preparation for its technology validation mission. The Swiss Army Knife of Weather SatellitesSpotting volcanic eruptions, monitoring the health of crops, pinpointing distress signals for search and rescue teams. It’s not what you might expect from a weather satellite. But these are just a few of the abilities of NOAA’s newest polar-orbiting weather satellite, launched by NASA on February 6 and turned over to NOAA for full-time operations on February 26. Formerly called NOAA-N Prime and now renamed NOAA-19, it is the last in its line of weather satellites that stretches back almost 50 years to the dawn of the Space Age. Over the decades, the abilities of these Television Infrared Observation Satellites (TIROS) have gradually improved and expanded, starting from the grainy, black-and-white images of Earth’s cloud cover taken by TIROS-1 and culminating in NOAA-19’s amazing array of capabilities. "This TIROS series has become quite the Swiss army knife of weather satellites, and NOAA-19 is the most capable one yet," says Tom Wrublewski, NOAA-19 Satellite Acquisition Manager at NASA’s Goddard Space Flight Center in Greenbelt, Maryland. The evolution of TIROS began in 1998 with NOAA-K. The satellites have carried microwave sensors that can measure temperature variations as small as 1 degree Celsius between Earth’s surface and an altitude of 40 kilometers - even through clouds. Other missions have added the ability to track large icebergs for cargo ships, monitor sea surface temperatures to aid climate change research, measure the amount of ozone in Earth’s protective ozone layer, and even detect hazardous particles from solar flares that can affect communications and endanger satellites, astronauts in orbit, and city power grids. NOAA-19 marks the end of the TIROS line, and for the next four years it will bridge the gap to a new series of satellites called the National Polar-orbiting Operational Environmental Satellite System. NPOESS will merge civilian and military weather satellites into a single system. Like NOAA-19, NPOESS satellites will orbit Earth from pole to pole, circling the planet roughly every 100 minutes and observing every location at least twice each day. NPOESS will have yet more capabilities drawn from its military heritage. Dim-light sensors will improve observations of the Earth at night, and the satellites will better monitor winds over the ocean - important information for ships at sea and for weather and climate models. "A lot more capability is going to come out of NPOESS, improving upon the 161 various environmental data products we already produce today," Wrublewski says. Not even a Swiss army knife can do that many things, he points out. For more on the NPOESS, check out http://www.npoess.noaa.gov Kids can find out about another NOAA satellite capability - tracking endangered migrating species - and play a fun memory game at http://spaceplace.nasa.gov/en/kids/poes_trackingThis article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The new NOAA-19 is the last and most capable in the long line of Television Infrared Observation Satellites (TIROS). Apollo UpgradeThe flight computer onboard the Lunar Excursion Module, which landed on the Moon during the Apollo program, had a whopping 4 kilobytes of RAM and a 74-kilobyte "hard drive." In places, the craft’s outer skin was as thin as two sheets of aluminum foil. It worked well enough for Apollo. Back then, astronauts needed to stay on the Moon for only a few days at a time. But when NASA once again sends people to the Moon starting around 2020, the plan will be much more ambitious - and the hardware is going to need a major upgrade. "Doing all the things we want to do using systems from Apollo would be very risky and perhaps not even possible," says Frank Peri, director of NASA’s Exploration Technology Development Program. So the program is designing new, more capable hardware and software to meet the demands of NASA’s plan to return humans to the moon. Instead of staying for just a few days, astronauts will be living on the Moon’s surface for months on end. Protecting astronauts from harsh radiation at the Moon’s surface for such a long time will require much better radiation shielding than just a few layers of foil. And rather than relying on food and water brought from Earth and jettisoning urine and other wastes, new life support systems will be needed that can recycle as much water as possible, scrub carbon dioxide from the air without depending on disposable filters, and perhaps grow a steady supply of food - far more than Apollo life-support systems could handle. Next-generation lunar explorers will perform a much wider variety of scientific research, so they’ll need vehicles that can carry them farther across the lunar surface. ETDP is building a new lunar rover that outclasses the Apollo-era moon buggy by carrying two astronauts in a pressurized cabin. "This vehicle is like our SUV for the Moon," Peri says. The Exploration Technology Development Program is also designing robots to help astronauts maintain their lunar outpost and perform science reconnaissance. Making the robots smart enough to take simple verbal orders from the astronauts and carry out their tasks semi-autonomously requires vastly more powerful computer brains than those on Apollo; four kilobytes of RAM just won’t cut it. The list goes on: New rockets to carry a larger lunar lander, spacesuits that can cope with abrasive moon dust, techniques for converting lunar soil into building materials or breathable oxygen. NASA’s ambitions for the Moon have been upgraded. By tapping into 21st century technology, this program will ensure that astronauts have the tools they need to turn those ambitions into reality. Learn more about the Exploration Technology Development Program at http://www.nasa.gov/directorates/esmd/aboutesmd/acd/technology_dev.html Kids can build their own Moon habitat at http://spaceplace.jpl.nasa.gov/en/kids/exploration/habitat/This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Chariot Lunar Truck is one idea for a vehicle equal to the lunar terrain. Each of the six wheels pivot in any direction, and two turrets allow the astronauts to rotate 360°. Where Did All These Gadgets Come From?!Ion propulsion. Artificial intelligence. Hyper-spectral imagers. It sounds like science fiction, but all these technologies are now flying around the solar system on real-life NASA missions. How did they get there? Answer: the New Millennium Program (NMP). NMP is a special NASA program that flight tests wild and far-out technologies. And if they pass the test, they can be used on real space missions. The list of probes that have benefited from technologies incubated by NMP reads like the Who’s Who of cutting-edge space exploration: Spirit and Opportunity (the phenomenally successful rovers exploring Mars), the Spitzer Space Telescope, the New Horizons mission to Pluto, the Dawn asteroid-exploration mission, the comet-smashing probe Deep Impact, and others. Some missions were merely enhanced by NMP technologies; others would have been impossible without them. "In order to assess the impact of NMP technologies, NASA has developed a scorecard to keep track of all the places our technologies are being used," says New Millennium Program manager Christopher Stevens of the Jet Propulsion Laboratory. For example, ion propulsion technology flight-tested on the NMP mission Deep Space 1, launched in October 1998, is now flying aboard the Dawn mission. Dawn will be the first probe to orbit an asteroid (Vesta) and then travel to and orbit a dwarf planet (Ceres). The highly efficient ion engine is vital to the success of the 3 billion mile, 8 year journey. The mission could not have been flown using conventional chemical propulsion; launching the enormous amount of fuel required would have broken the project’s budget. "Ion propulsion was the only practical way," says Stevens. In total, 10 technologies tested by Deep Space 1 have been adopted by more than 20 robotic probes. One, the Small Deep Space Transponder, has become the standard system for Earth communications for all deep-space missions. And Deep Space 1 is just one of NMP’s missions. About a half-dozen others have flown or will fly, and their advanced technologies are only beginning to be adopted. That’s because it takes years to design probes that use these technologies, but Stevens says experience shows that "if you validate experimental technologies in space, and reduce the risk of using them, missions will pick them up." Stevens knew many of these technologies when they were just a glimmer in an engineer’s eye. Now they’re "all grown up" and flying around the solar system. It’s enough to make a program manager proud! The results of all NMP's technology validations are online and the list is impressive: http://nmp.nasa.gov/TECHNOLOGY/scorecard/scorecard_results.cfm For kids, the rhyming storybook, "Professor Starr's Dream Trip: Or, How a Little Technology Goes a Long Way" at http://spaceplace.jpl.nasa.gov/en/kids/nmp/starr/ gives a scientist's perspective on the technology that makes possible the Dawn mission.This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Dawn will be the first spacecraft to establish orbits around two separate target bodies during its mission - thanks to ion propulsion validated by Deep Space 1. Severe Space Weatherby Dr. Tony Phillips Did you know a solar flare can make your toilet stop working? That's the surprising conclusion of a NASA-funded study by the National Academy of Sciences entitled Severe Space Weather Events - Understanding Societal and Economic Impacts. In the 132-page report, experts detailed what might happen to our modern, high-tech society in the event of a "super solar flare" followed by an extreme geomagnetic storm. They found that almost nothing is immune from space weather - not even the water in your bathroom. The problem begins with the electric power grid. Ground currents induced during an extreme geomagnetic storm can melt the copper windings of huge, multi-ton transformers at the heart of power distribution systems. Because modern power grids are interconnected, a cascade of failures could sweep across the country, rapidly cutting power to tens or even hundreds of millions of people. According to the report, this loss of electricity would have a ripple effect with "water distribution affected within several hours; perishable foods and medications lost in 12-24 hours; loss of heating/air conditioning, sewage disposal, phone service, fuel re-supply and so on." "The concept of interdependency," the report notes, "is evident in the unavailability of water due to long-term outage of electric power - and the inability to restart an electric generator without water on site." It takes a very strong geomagnetic storm to cause problems on this scale - the type of storm that comes along only every century or so. A point of reference is the "Carrington Event" of August-September 1859, named after British amateur astronomer Richard Carrington who witnessed the instigating solar flare with his unaided eye while he was projecting an image of the Sun on a white screen. Geomagnetic storms triggered by the flare electrified telegraph lines, shocking technicians and setting their telegraph papers on fire; Northern Lights spread as far south as Cuba and Hawaii; auroras over the Rocky Mountains were so bright, the glow woke campers who began preparing breakfast because they thought it was morning! "A contemporary repetition of the Carrington Event would cause...extensive social and economic disruptions," the report warns. Widespread failures could include telecommunications, GPS navigation, banking and finance, and transportation. The total economic impact in the first year alone could reach $2 trillion (some 20 times greater than the costs of Hurricane Katrina). The report concluded with a call for infrastructure designed to better withstand geomagnetic disturbances and improvements in space weather forecasting. Indeed, no one knows when the next super solar storm will erupt. It could be 100 years away or just 100 days. It’s something to think about...the next time you flush. One of the jobs of the Geostationary Operational Environmental Satellites (GOES) and the Polar-orbiting Operational Environmental Satellites (POES) operated by NOAA is to keep an eye on space weather and provide early warning of solar events that could cause trouble for Earth. You can keep an eye on space weather yourself at the National Weather Service's Space Weather Prediction Center at http://www.swpc.noaa.gov And for young people, space weather is explained and illustrated simply and clearly at the SciJinks Weather Laboratory: http://scijinks.gov/weather/howwhy/spaceweather This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: On this power-grid map of the United States, the black-circled areas are regions especially vulnerable to collapse during an extreme geomagnetic storm. Inside those boundaries are more than 130 million people. Credit: National Academy of Sciences report on severe space weather. Superstar Hide and Seekby Dr. Tony Phillips It sounds like an impossible task: Take a star a hundred times larger in diameter and millions of times more luminous than the Sun and hide it in our own galaxy where the most powerful optical telescopes on Earth cannot find it. But it is not impossible. In fact, there could be dozens to hundreds of such stars hiding in the Milky Way right now. Furiously burning their inner stores of hydrogen, these hidden superstars are like ticking bombs poised to ‘go supernova’ at any moment, possibly unleashing powerful gamma-ray bursts. No wonder astronomers are hunting for them. Earlier this year, they found one. "It’s called the Peony nebula star," says Lidia Oskinova of Potsdam University in Germany. "It shines like 3.2 million suns and weighs in at about 90 solar masses." The star lies behind a dense veil of dust near the center of the Milky Way galaxy. Starlight traveling through the dust is attenuated so much that the Peony star, at first glance, looks rather dim and ordinary. Oskinova’s team set the record straight using NASA’s Spitzer Space Telescope. Clouds of dust can hide a star from visible-light telescopes, but Spitzer is an infrared telescope able to penetrate the dusty gloom. "Using data from Spitzer, along with infrared observations from the ESO’s New Technology Telescope in Chile, we calculated the Peony star’s true luminosity," she explains. "In the Milky Way galaxy, it is second only to another known superstar, Eta Carina, which shines like 4.7 million suns." Oskinova believes this is just the tip of the iceberg. Theoretical models of star formation suggest that one Peony-type star is born in our galaxy every 10,000 years. Given that the lifetime of such a star is about one million years, there should be 100 of them in the Milky Way at any given moment. Could that be a hundred deadly gamma-ray bursts waiting to happen? Oskinova is not worried. "There’s no threat to Earth," she believes. "Gamma-ray bursts produce tightly focused jets of radiation and we would be extremely unlucky to be in the way of one. Furthermore, there don’t appear to be any supermassive stars within a thousand light years of our planet." Nevertheless, the hunt continues. Mapping and studying supermassive stars will help researchers understand the inner workings of extreme star formation and, moreover, identify stars on the brink of supernova. One day, astronomers monitoring a Peony-type star could witness with their own eyes one of the biggest explosions since the Big Bang itself. Now that might be hard to hide. Find out the latest news on discoveries using the Spitzer at http://www.spitzer.caltech.edu Kids (of all ages) can read about "Lucy’s Planet Hunt" using the Spitzer Space Telescope at http://spaceplace.nasa.gov/en/kids/spitzer/lucyThis article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The "Peony Nebula" star is the second-brightest found in the Milky Way Galaxy, after Eta Carina. The Peony star blazes with the light of 3.2 million suns. What Happened to Comet Holmes?by Dr. Tony Phillips One year after Comet 17P/Holmes shocked onlookers by exploding in the night sky, researchers are beginning to understand what happened. "We believe that a cavern full of ice, located as much as 100 meters beneath the crust of the comet’s nucleus, underwent a change of phase," says Bill Reach of NASA's Spitzer Science Center at the California Institute of Technology. "Amorphous ice turned into crystalline ice" and, in the transition, released enough heat to cause Holmes to blow its top. Anyone watching the sky in October 2007 will remember how the comet brightened a million-fold to naked-eye visibility. It looked more like a planet than a comet - strangely spherical and utterly lacking a tail. By November 2007, the expanding dust cloud was larger than Jupiter itself, and people were noticing it from brightly-lit cities. Knowing that infrared telescopes are particularly sensitive to the warm glow of comet dust, Reach and colleague Jeremie Vaubaillon, also of Caltech, applied for observing time on the Spitzer Space Telescope - and they got it. "We used Spitzer to observe Comet Holmes in November and again in February and March 2008," says Reach. The infrared glow of the expanding dust cloud told the investigators how much mass was involved and how fast the material was moving. "The energy of the blast was about 10 to the 14th power joules and the total mass was of order 10 to the 10th power kg." In other words, Holmes exploded like 24 kilotons of TNT and ejected 10 million metric tons of dust and gas into space. These astonishing numbers are best explained by a subterranean cavern of phase-changing ice, Reach believes. "The mass and energy are in the right ballpark," he says, and it also explains why Comet Holmes is a "repeat exploder." Another explosion was observed in 1892. It was a lesser blast than the 2007 event, but enough to attract the attention of American astronomer Edwin Holmes, who discovered the comet when it suddenly brightened. Two explosions (1892, 2007) would require two caverns. That’s no problem because comets are notoriously porous and lumpy. In fact, there are probably more than two caverns, which would mean Comet Holmes is poised to explode again. When? "The astronomer who can answer that question will be famous!" laughs Vaubaillon. "No one knows what triggered the phase change," says Reach. He speculates that maybe a comet-quake sent seismic waves echoing through the comet’s caverns, compressing the ice and changing its form. Or a meteoroid might have penetrated the comet’s crust and set events in motion that way. "It’s still a mystery." But not as much as it used to be. See more Spitzer images of comets and other heavenly objects at www.spitzer.caltech.edu. Kids and grownups can challenge their spatial reasoning powers by solving Spitzer infrared "Slyder" puzzles at http://spaceplace.nasa.gov/en/kids/spitzer/slyder This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Comet Holmes as imaged by the multiband imaging photometer (MIPS) on the Spitzer Space Telescope. The enhanced contrast image at the right shows the comet’s outer shell and mysterious filaments of dust. The Chemical Weather Report"Sunny tomorrow with highs in the mid-70s. There’s going to be some carbon monoxide blowing in from forest fires, and all that sunshine is predicted to bring a surge in ground-level ozone by afternoon. Old and young people and anyone with lung conditions are advised to stay indoors between 3 and 5 p.m." Whoever heard of a weather report like that? Get used to it. Weather reports of the future are going to tell you a lot more about the atmosphere than just how warm and rainy it is. In the same way that satellite observations of Earth revolutionized basic weather forecasting in the 1970s and 80s, satellite tracking of air pollution is about to revolutionize the forecasting of air quality. Such forecasts could help people plan around high levels of ground-level ozone - a dangerous lung irritant - just as they now plan around bad storms. "The phrase that people have used is chemical weather forecasting," says Kevin Bowman of NASA’s Jet Propulsion Laboratory. Bowman is a senior member of the technical staff for the Tropospheric Emission Spectrometer, one of four scientific sensors on NASA’s Aura satellite. Aura and other NASA satellites track pollution in the same way that astronomers know the chemical composition of stars and distant planetary atmospheres: using spectrometry. By breaking the light from a planet or star into its spectrum of colors, scientists can read off the atmosphere’s gases by looking at the "fingerprint" of wavelengths absorbed or emitted by those chemicals. From Earth orbit, pollution-watching satellites use this trick to measure trace gases such as carbon monoxide, nitrogen oxide, and ozone. However, as Bowman explains, "Polar sun-synchronous satellites such as Aura are limited at best to two overpasses per day." A recent report by the National Research Council recommends putting a pollution-watching satellite into geosynchronous orbit - a special very high-altitude orbit above the equator in which satellites make only one orbit per day, thus seeming to hover over the same spot on the equator below. There, this new satellite, called GEOCAPE (Geostationary Coastal and Air Pollution Events), would give scientists a continuous eye in the sky, allowing them to predict daily pollution levels just as meteorologists predict storms. "NASA is beginning to investigate what it would take to build an instrument like this," Bowman says. Such a chemical weather satellite could be in orbit as soon as 2013, according to the NRC report. Weather forecasts might never be the same. Learn more about the Tropospheric Emission Spectrometer at http://tes.jpl.nasa.gov Kids can learn some elementary smog chemistry while making "Gummy Greenhouse Gases" out of gumdrops at http://spaceplace.nasa.gov/en/kids/tes/gumdrops This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Example of visualization of data from the Tropospheric Emission Spectrometer. These frames are from an animation that steps through transects of the atmosphere profiling vertical ozone and carbon monoxide concentrations, combining all tracks of the Aura satellite during a given two week period. Extreme Starburstby Dr. Tony Phillips A star is born. A star is born. A star is born. Repeat that phrase 4000 times and you start to get an idea what life is like in distant galaxy J100054+023436. Astronomers using NASA's Spitzer Space Telescope and ground-based observatories have found that the galaxy gives birth to as many as 4000 stars a year. For comparison, in the same period of time the Milky Way produces only about 10. This makes J100054+023436 an extreme starburst galaxy. "We call it the ‘Baby Boom galaxy'," says Peter Capak of NASA’s Spitzer Science Center at the California Institute of Technology in Pasadena, CA. "It is undergoing a major baby boom, producing most of its stars all at once. If our human population was produced in a similar boom, then almost all people alive today would be the same age." Capak is lead author of a paper entitled "Spectroscopic Confirmation of an Extreme Starburst at Redshift 4.547" detailing the discovery in the July 10th issue of Astrophysical Journal Letters. The galaxy appears to be a merger, a "train wreck" of two or more galaxies crashing together. The crash is what produces the baby boom. Clouds of interstellar gas within the two galaxies press against one another and collapse to form stars, dozens to hundreds at a time. This isn’t the first time astronomers have witnessed a galaxy producing so many stars. "There are some other extreme starburst galaxies in the local universe," says Capek. But the Baby Boom galaxy is special because it is not local. It lies about 12.3 billion light years from Earth, which means we are seeing it as it was 12.3 billion years ago. The universe itself is no older than 14 billion years, so this galaxy is just a youngster (Capak likens it to a 6-year-old human) previously thought to be incapable of such rapid-fire star production. The Baby Boom galaxy poses a challenge to the Hierarchical Model of galaxy evolution favored by many astronomers. According to the Hierarchical Model, galaxies grow by merging; Add two small galaxies together, and you get a bigger galaxy. In the early years of the universe, all galaxies were small, and they produced correspondingly small bursts of star formation when they merged. "Yet in J100054+023436, we see an extreme starburst. The merging galaxies must be pretty large." Capak and colleagues are busy looking for more Baby Boomers "to see if this is a one-off case or a common occurrence." The theory of evolution of galaxies hangs in the balance. Meanwhile.... A star is born. A star is born. A star is born. See more breathtaking Spitzer images at http://www.spitzer.caltech.edu/Media/mediaimages Kids can play the new Spitzer "Sign Here!" game at http://spaceplace.nasa.gov/en/kids/spitzer/signs This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The "Baby Boom" galaxy loosely resembles the galaxy shown here, called Zw II 96, in this Hubble Space Telescope image. This galaxy is only 500 million light-years away, while the Baby Boom galaxy is 12.3 billion light-years away. A Google for Satellites: Sensor Web 2.0If you could see every satellite passing overhead each day, it would look like a chaotic meteor shower in slow motion. Hundreds of satellites now swarm over the Earth in a spherical shell of high technology. Many of these satellites gaze at the planet’s surface, gathering torrents of scientific data using a dizzying array of advanced sensors - an extraordinary record of our dynamic planet. To help people tap into this resource, NASA researchers such as Daniel Mandl are developing a "Google for satellites," a web portal that would make requesting data from Earth-observing satellites almost as easy as typing a search into Google. "You just click on it and it takes care of all the details for you across many sensors," Mandl explains. Currently, most satellites are each controlled separately from the others, each one dauntingly complex to use. But starting with NASA’s Earth Observing-1 (EO-1) satellite, part of the agency’s New Millennium Program, Mandl and his team are building a prototype that stitches these satellites together into a seamless, easy-to-use network called "Sensor Web 2.0." The vision is to simply enter a location anywhere on Earth into the website’s search field along with the desired information types - wildfire maps, vegetation types, floodwater salinity, oil spill extent - and software written by the team goes to work. "Not only will it find the best sensor, but with proper access rights, you could actually trigger a satellite to take an image in the area of interest," Mandl says. Within hours, the software will send messages to satellites instructing them to gather the needed data, and then download and crunch that raw data to produce easy-to-read maps. For example, during the recent crisis in Myanmar (Burma) caused by Cyclone Nargis, an experimental gathering of data was triggered through Sensor Web 2.0 using a variety of NASA satellites including EO-1. "One thing we might wish to map is the salinity of flood waters in order to help rescue workers plan their relief efforts," Mandl says. If the floodwater in an area was salty, aid workers would need to bring in bottled water, but if flood water was fresh, water purifiers would suffice. An early and correct decision could save lives. Thus far, Mandl and his team have expanded Sensor Web 2.0 beyond EO-1 to include three other satellites and an unmanned aircraft. He hopes to double the number of satellites in the network every 18 months, eventually weaving the jumble of satellites circling overhead into a web of sensors with unprecedented power to observe and understand our ever-changing planet. To learn more about the EO-1 sensor web initiatives, go to http://eo1.gsfc.nasa.gov/new/extended/sensorWeb/sensorWeb.html Kids (and grown-ups) can get an idea of the resolution of EO-1’s Hyperion Imager and how it can distinguish among species of trees - from space at http://spaceplace.nasa.gov/en/kids/eo1_1.shtml This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: A "Google for satellites" type of web portal will allow users to request real-time data from Earth observing satellites. Death of a SupergiantBy all outward appearances, the red supergiant appeared normal. But below the surface, hidden from probing eyes, its core had already collapsed into an ultra-dense neutron star, sending a shock wave racing outward from the star’s center at around 50 million kilometers per hour. The shock wave superheated the plasma in its path to almost a million degrees Kelvin, causing the star to emit high-energy ultraviolet (UV) radiation. About six hours later, the shock wave reached the star’s surface, causing it to explode in a Type IIP supernova named SNLS-04D2dc. Long before the explosion’s visible light was detected by telescopes on Earth, NASA’s Galaxy Evolution Explorer (GALEX) space telescope captured the earlier pulse of UV light - scientists’ first glimpse of a star entering its death throes. "This UV light has traveled through the star at the moment of its death but before it was blown apart," explains Kevin Schawinski, the University of Oxford astrophysicist who led the observation. "So this light encodes some information about the state of the star the moment it died." And that’s exactly why astronomers are so excited. Observing the beautiful nebula left behind by a supernova doesn’t reveal much about what the star was like before it exploded; most of the evidence has been obliterated. Information encoded in these UV "pre-flashes" could offer scientists an unprecedented window into the innards of stars on the verge of exploding. In this case, Schawinski and his colleagues calculated that just before its death, the star was 500 to 1000 times larger in diameter than our sun, confirming that the star was in fact a red supergiant. "We’ve been able to tell you the size of a star that died in a galaxy several billion light-years away," Schawinski marvels. "GALEX has played a very important role in actually seeing this for a few reasons," Schawinski says. First, GALEX is a space telescope, so it can see far-UV light that’s blocked by Earth’s atmosphere. Also, GALEX is designed to take a broad view of the sky. Its relatively small 20-inch primary mirror gives it a wide, 1.2-degree field of view, making it more likely to catch the UV flash preceding a supernova. With these advantages, GALEX is uniquely equipped to catch a supernova before it explodes. "Just when we like to see it," Schawinski says. For more information, visit http://www.galex.caltech.edu, then click on "Ultraviolet Gives View Inside Real ‘Death Star’." Kids can check out how to make a mobile of glittering galaxies at http://spaceplace.nasa.gov/en/kids/galex_make1.shtml This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Sequence of images shows supernova start to finish. The top left image shows the galaxy before the supernova. At top right, the bright UV flash called the shock breakout indicates a red supergiant has collapsed. At bottom left, moments later, the flash is mostly gone. As the debris expands, it heats up again and becomes brighter (bottom right). The supernova became 10 times the size of the original over the following few days, thus becoming visible to supernova hunters. Space BuoysBy Dr. Tony Phillips Congratulations! You’re an oceanographer and you’ve just received a big grant to investigate the Pacific Ocean. Your task: Map the mighty Pacific’s wind and waves, monitor its deep currents, and keep track of continent-sized temperature oscillations that shape weather around the world. Funds are available and you may start immediately. Oh, there’s just one problem: You’ve got to do this work using no more than one ocean buoy. "That would be impossible," says Dr. Guan Le of the Goddard Space Flight Center. "The Pacific’s too big to understand by studying just one location." Yet, for Le and her space scientist colleagues, this was exactly what they have been magnetosphere is an "ocean" of magnetism and plasma surrounding our planet. Its shores are defined by the outer bounds of Earth’s magnetic field and it contains a bewildering mix of matter-energy waves, electrical currents and plasma oscillations spread across a volume billions of times greater than the Pacific Ocean itself. "For many years we’ve struggled to understand the magnetosphere using mostly single spacecraft," says Le. "To really make progress, we need many spacecraft spread through the magnetosphere, working together to understand the whole." Enter Space Technology 5. In March 2006 NASA launched a trio of experimental satellites to see what three "buoys" could accomplish. Because they weighed only 55 lbs. apiece and measured not much larger than a birthday cake, the three ST5 "micro-satellites" fit onboard a single Pegasus rocket. Above Earth’s atmosphere, the three were flung like Frisbees from the rocket’s body into the magnetosphere by a revolutionary micro-satellite launcher. Space Technology 5 is a mission of NASA’s New Millennium Program, which tests innovative technologies for use on future space missions. The 90-day flight of ST5 validated several devices crucial to space buoys: miniature magnetometers, high-efficiency solar arrays, and some strange-looking but effective micro-antennas designed from principles of Darwinian evolution. Also, ST5 showed that three satellites could maneuver together as a "constellation," spreading out to measure complex fields and currents. "ST5 was able to measure the motion and thickness of current sheets in the magnetosphere," says Le, the mission’s project scientist at Goddard. "This could not have been done with a single spacecraft, no matter how capable." The ST5 mission is finished but the technology it tested will key future studies of the magnetosphere. Thanks to ST5, hopes Le, lonely buoys will soon be a thing of the past. Learn more about ST5’s miniaturized technologies at nmp.nasa.gov/st5. Kids (and grownups) can get a better understanding of the artificial evolutionary process used to design ST5’s antennas at http://spaceplace.nasa.gov/en/kids/st5/emoticon This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Space Technology 5 micro-satellites proved the feasibility of using a constellation of small spacecraft with miniature magnetometers to study Earth’s magnetosphere. Ozone, the Greenhouse GasWe all know that ozone in the stratosphere blocks harmful ultraviolet sunlight, and perhaps some people know that ozone at the Earth's surface is itself harmful, damaging people's lungs and contributing to smog. But did you know that ozone also acts as a potent greenhouse gas? At middle altitudes between the ground and the stratosphere, ozone captures heat much as carbon dioxide does. In fact, pound for pound, ozone is about 3000 times stronger as a greenhouse gas than CO2. So even though there's much less ozone at middle altitudes than CO2, it still packs a considerable punch. Ozone traps up to one-third as much heat as the better known culprit in climate change. Scientists now have an unprecedented view of this mid-altitude ozone thanks to an instrument aboard NASA's Aura satellite called the Tropospheric Emission Spectrometer - "TES" for short. Most satellites can measure only the total amount of ozone in a vertical column of air. They can't distinguish between helpful ozone in the stratosphere, harmful ozone at the ground, and heat-trapping ozone in between. By looking sideways toward Earth’s horizon, a few satellites have managed to probe the vertical distribution of ozone, but only to the bottom of the stratosphere. Unlike the others, TES can measure the distribution of ozone all the way down to the heat-trapping middle altitudes. "We see vertical information in ozone that nobody else has measured before from space," says Annmarie Eldering, Deputy Principal Investigator for TES. The global perspective offered by an orbiting satellite is especially important for ozone. Ozone is highly reactive. It is constantly being created and destroyed by photochemical reactions in the atmosphere and by lightning. So its concentration varies from region to region, from season to season, and as the wind blows. Data from TES show that ozone's heat-trapping effect is greatest in the spring, when intensifying sunlight and warming temperatures fuel the reactions that generate ozone. Most of ozone's contribution to the greenhouse effect occurs within 45 degrees latitude from the equator. Increasing industrialization, particularly in the developing world, could lead to an increase in mid-altitude ozone, Eldering says. Cars and coal-fired power plants release air pollutants that later react to produce more ozone. "There's concern that overall background levels are slowly increasing over time," Eldering says. TES will continue to monitor these trends, she says, keeping a careful eye on ozone, the greenhouse gas. Learn more about TES and the science of ozone at http://tes.jpl.nasa.gov/ Kids can get a great introduction to good ozone and bad ozone at http://spaceplace.nasa.gov/en/kids/tes/gases This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Ozone behaves differently at different altitudes in the atmosphere. High in the stratosphere and at mid-troposphere it has positive effects on life at the surface. At the top of the troposphere ozone is a greenhouse gas and at the surface it makes smog. Stellar Compass for Space Explorersby Patrick Barry In space, there's no up or down, north or south, east or west. So how can robotic spacecraft know which way they're facing when they fire their thrusters, or when they try to beam scientific data back to Earth? Without the familiar compass points of Earth's magnetic poles, spacecraft use stars and gyros to know their orientation. Thanks to a recently completed test flight, future spacecraft will be able to do so using only an ultra-low-power camera and three silicon wafers as small as your pinky fingernail. "The wafers are actually very tiny gyros," explains Artur Chmielewski, project manager at JPL for Space Technology 6 (ST6), a part of NASA's New Millennium Program. Traditional gyros use spinning wheels to detect changes in pitch, yaw, and roll - the three axes of rotation. For ST6's Inertial Stellar Compass, the three gyros instead consist of silicon wafers that resemble microchips. Rotating the wafers distorts microscopic structures on the surfaces of these wafers in a way that generates electric signals. The compass uses these signals - along with images of star positions taken by the camera - to measure rotation. Because the Inertial Stellar Compass (ISC) is based on this new, radically different technology, NASA needed to flight-test it before using it in important missions. That test flight reached completion in December 2007 after about a year in orbit aboard the Air Force's TacSat-2 satellite. "It just performed beautifully," Chmielewski says. "The data checked out really well." The engineers had hoped that ISC would measure the spacecraft's rotation with an accuracy of 0.1 degrees. In the flight tests, ISC surpassed this goal, measuring rotation to within about 0.05 degrees. That success paves the way for using ISC to reduce the cost of future science missions. When launching probes into space, weight equals money. "If you're paying a million dollars per kilogram to send your spacecraft to Mars, you care a lot about weight," Chmielewski says. At less than 3 kilograms, ISC weighs about one-fifth as much as traditional stellar compasses. It also uses about one-tenth as much power, so a spacecraft would be able to use smaller, lighter solar panels. Engineers at Draper Laboratory, the Cambridge, Massachusetts, company that built the ISC, are already at work on a next-generation design that will improve the compass's accuracy ten-fold, Chmielewski says. So ISC and its successors could soon help costs - and spacecraft - stay on target. Find out more about the ISC at http://nmp.nasa.gov/st6/ Kids can do a fun project and get an introduction to navigating by the stars at http://spaceplace.nasa.gov/en/kids/st6starfinder/st6starfinder.shtmlThis article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Compass is built as two separate assemblies, the camera-gyro assembly and the data processor assembly, connected by a wiring harness. The technology uses an active pixel sensor in a wide-field-of-view miniature star camera and micro-electromechanical system (MEMS) gyros. Together, they provide extremely accurate information for navigation and control. Tracking Wildlife from Spaceby Patrick Barry It's 10 o'clock, and do you know where your Oriental Honey Buzzard is? Tracking the whereabouts of birds and other migrating wildlife across thousands of miles of land, air, and sea is no easy feat. Yet to protect the habitats of endangered species, scientists need to know where these roving animals go during their seasonal travels. Rather than chasing these animals around the globe, a growing number of scientists are leveraging the bird's-eye view of orbiting satellites to easily monitor animals' movements anywhere in the world. The system piggybacks on weather satellites called Polar Operational Environmental Satellites, which are operated by the National Oceanic and Atmospheric Administration (NOAA), as well as a European satellite called MetOp. Sensors aboard these satellites pick up signals beamed from portable transmitters on the Earth's surface, 850 kilometers below. NOAA began the project - called Argos - in cooperation with NASA and the French space agency (CNES) in 1974. At that time, scientists placed these transmitters primarily on buoys and balloons to study the oceans and atmosphere. As electronics shrank and new satellites' sensors became more sensitive, the transmitters became small and light enough by the 1990s that scientists could mount them safely on animals. Yes, even on birds like the Oriental Honey Buzzard. "Scientists just never had the capability of doing this before," says Christopher O'Connors, Program Manager for Argos at NOAA. Today, transmitters weigh as little as 1/20th of a pound and require a fraction of a watt of power. The satellites can detect these feeble signals in part because the transmitters broadcast at frequencies between 401 and 403 MHz, a part of the spectrum reserved for environmental uses. That way there's very little interference from other sources of radio noise. "Argos is being used more and more for animal tracking," O’Connors says. More than 17,000 transmitters are currently being tracked by Argos, and almost 4,000 of them are on wildlife. "The animal research has been the most interesting area in terms of innovative science." For example, researchers in Japan used Argos to track endangered Grey-faced Buzzards and Oriental Honey Buzzards for thousands of kilometers along the birds' migrations through Japan and Southeast Asia. Scientists have also mapped the movements of loggerhead sea turtles off the west coast of Africa. Other studies have documented migrations of wood storks, Malaysian elephants, porcupine caribou, right whales, and walruses, to name a few. Argos data is available online at www.argos-system.org, so every evening, scientists can check the whereabouts of all their herds, schools, and flocks. Kids can learn about some of these endangered species and play a memory game with them at http://spaceplace.jpl.nasa.gov/en/kids/poes_tracking/ This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The ARGOS program tracks the whereabouts of endangered migrating animals via miniature transmitters on the animals and the POES satellites in orbit. Invisible Spiral Armsby Patrick Barry At one time or another, we've all stared at beautiful images of spiral galaxies, daydreaming about the billions of stars and countless worlds they contain. What mysteries - and even life forms - must lurk within those vast disks? Now consider this: many of the galaxies you've seen are actually much larger than they appear. NASA's Galaxy Evolution Explorer, a space telescope that "sees" invisible, ultraviolet light, has revealed that roughly 20 percent of nearby galaxies have spiral arms that extend far beyond the galaxies' apparent edges. Some of these galaxies are more than three times larger than they appear in images taken by ordinary visible-light telescopes. "Astronomers have been observing some of these galaxies for many, many years, and all that time, there was a whole side to these galaxies that they simply couldn't see," says Patrick Morrissey, an astronomer at Caltech in Pasadena, California, who collaborates at JPL. The extended arms of these galaxies are too dim in visible light for most telescopes to detect, but they emit a greater amount of UV light. Also, the cosmic background is much darker at UV wavelengths than it is for visible light. "Because the sky is essentially black in the UV, far-UV enables you to see these very faint arms around the outsides of galaxies," Morrissey explains. These "invisible arms" are made of mostly young stars shining brightly at UV wavelengths. Why UV? Because the stars are so hot. Young stars burn their nuclear fuel with impetuous speed, making them hotter and bluer than older, cooler stars such as the sun. (Think of a candle: blue flames are hotter than red ones.) Ultraviolet is a sort of "ultra-blue" that reveals the youngest, hottest stars of all. "That's the basic idea behind the Galaxy Evolution Explorer in the first place. By observing the UV glow of young stars, we can see where star formation is active," Morrissey says. The discovery of these extended arms provides fresh clues for scientists about how some galaxies form and evolve, a hot question right now in astronomy. For example, a burst of star formation so far from the galaxies' denser centers may have started because of the gravity of neighboring galaxies that passed too close. But in many cases, the neighboring galaxies have not themselves sprouted extended arms, an observation that remains to be explained. The Galaxy Evolution Explorer reveals one mystery after another! "How much else is out there that we don't know about?" Morrissey asks. "It makes you wonder." Spread the wonder by seeing for yourself some of these UV images at www.galex.caltech.edu. Also, Chris Martin, principle scientist for Galaxy Evolution Explorer - or rather his cartoon alter-ego - gives kids a great introduction to ultraviolet astronomy at http://spaceplace.nasa.gov/en/kids/live#martin This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption (color image): In this image of galaxy NGC 1512, red represents its visible light appearance, the glow coming from older stars, while the bluish-white ring and the long, blue spiral arms show the galaxy as the Galaxy Evolution Explorer sees it in ultraviolet, tracing primarily younger stars. (Credit: NASA/JPL-Caltech/DSS/GALEX). Caption (greyscale images): Galaxy NGC 1512 is represented in both images. The visible light image on the left shows the glow of older stars, while the Galaxy Evolution Explorer ultraviolet image on the right shows the ring and long, spiral arms, tracing primarily younger stars. (Credit: NASA/JPL-Caltech/DSS/GALEX). No Mars Rock UnturnedImagine someday taking a driving tour of the surface of Mars. You trail-blaze across a dusty valley floor, looking in amazement at the rocky, orange-brown hillsides and mountains all around. With each passing meter, you spy bizarre-looking rocks that no human has ever seen, and may never see again. Are they meteorites or bits of Martian crust? They beg to be photographed. But on this tour, you can't whip out your camera and take on-the-spot close-ups of an especially interesting-looking rock. You have to wait for orders from headquarters back on Earth, and those orders won't arrive until tomorrow. By then, you probably will have passed the rock by. How frustrating! That's essentially the predicament of the Spirit and Opportunity rovers, which are currently in their fourth year of exploring Mars. Mission scientists must wait overnight for the day's data to download from the rovers, and the rovers can't take high-res pictures of interesting rocks without explicit instructions to do so. However, artificial intelligence software developed at JPL could soon turn the rovers into more-autonomous shutterbugs. This software, called Autonomous Exploration for Gathering Increased Science (AEGIS), would search for interesting or unusual rocks using the rovers' low-resolution, black-and-white navigational cameras. Then, without waiting for instructions from Earth, AEGIS could direct the rovers' high-resolution cameras, spectrometers, and thermal imagers to gather data about the rocks of interest. "Using AEGIS, the rovers could get science data that they would otherwise miss," says Rebecca Castańo, leader of the AEGIS project at JPL. The software builds on artificial intelligence technologies pioneered by NASA's Earth Observing-1 satellite (EO-1), one of a series of technology-testbed satellites developed by NASA's New Millennium Program. AEGIS identifies a rock as being interesting in one of two ways. Mission scientists can program AEGIS to look for rocks with certain traits, such as smoothness or roughness, bright or dark surfaces, or shapes that are rounded or flat. In addition, AEGIS can single out rocks simply because they look unusual, which often means the rocks could tell scientists something new about Mars's present and past. The software has been thoroughly tested, Castańo says, and now it must be integrated and tested with other flight software, then uploaded to the rovers on Mars. Once installed, she hopes, Spirit and Opportunity will leave no good Mars rock unturned. Check out other ways that the Mars Rovers have been upgraded with artificial intelligence software at http://nmp.nasa.gov/TECHNOLOGY/infusion.html#sciencecraft This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Are these rocks of any scientific interest? With the new AEGIS software, the Mars Rovers, Spirit and Opportunity, will be able to judge for themselves whether a scene is worth a high-resolution image. (Artist’s rendering). Ultraviolet Surpriseby Patrick L. Barry and Tony Phillips How would you like to visit a universe full of exotic stars and weird galaxies the likes of which astronomers on Earth have never seen before? Now you can. Just point your web browser to http://galex.stsci.edu/GR2/ and start exploring. That's the address of the Galaxy Evolution Explorer image archive, a survey of the whole sky at ultraviolet wavelengths that can't be seen from the ground. Earth's atmosphere blocks far-ultraviolet light, so the only way to see the ultraviolet sky is by using a space telescope such as NASA’s Galaxy Evolution Explorer. About 65% of the images from the all-sky survey haven't been closely examined by astronomers yet, so there are plenty of surprises waiting to be uncovered. "The Galaxy Evolution Explorer produces so much data that, beyond basic quality control, we just don't have time to look at it all," says Mark Seibert, an astronomy postdoc at the Observatories of the Carnegie Institution of Washington in Pasadena, California. This fresh view of the sky has already revealed striking and unexpected features of familiar celestial objects. Mira is a good example. Occasionally visible to the naked eye, Mira is a pulsating star monitored carefully by astronomers for more than 400 years. Yet until Galaxy Evolution Explorer recently examined Mira, no one would have guessed its secret: Mira possesses a comet-like tail 13 light-years long. "Mira shows us that even well-observed stars can surprise us if we look at them in a different way and at different frequencies," Seibert says. Another example: In April, scientists announced that galaxies such as NGC 1512 have giant ultraviolet spiral arms extending three times farther out into space than the arms that can be seen by visible-light telescopes. It would be like looking at your pet dog through an ultraviolet telescope and discovering his ears are really three times longer than you thought! The images from the ultraviolet space telescope are ideal for hunting new phenomena. The telescope's small, 20-inch primary mirror (not much bigger than a typical backyard telescope) offers a wide field of view. Each image covers 1.2 degrees of sky - lots of territory for the unexpected. If someone combing the archives does find something of interest, Seibert advises that she or he should first search astronomy journals to see whether the phenomenon has been observed before. If it hasn't, email a member of the Galaxy Evolution Explorer science team and let them know, Seibert says. So what are you waiting for? Fire up your web browser and let the discoveries begin! This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Astronomers looking at new ultraviolet images from the Galaxy Evolution Explorer spacecraft were surprised to discover a 13-light-year long tail on Mira, a star that has been extensively studied for 400 years. Going My Way?by Diane K. Fisher Not many endeavors require that you plan the mode of transportation before you even know what it is you are transporting. But weighing the physics and economics of getting any sort of cargo to space is a major part of designing a space mission. It’s one of the first issues that NASA’s New Millennium Program (NMP) considers when planning a new mission. NMP has the forward-looking job to identify promising new technologies for space exploration. It then helps to mature the technology so it will be available to space missions of the future. If the technology cannot be tested adequately on Earth, the last part of this process is to actually send the technology into space. With carefully documented test results, future mission planners can confidently incorporate the new technology into their designs. But where to begin? On call from the start, Linda Herrell is the New Millennium Program Architect. Given a list of proposed technologies, she has the job of figuring out the feasibility of wrapping a mission around them. "We might be considering six or more technologies, anything from solar panels to imagers to masts for solar sails to more intelligent software. Of those, we may choose four. My job is to answer the question - can the selected technology be transported to and operated in space within the constraints of a low-cost technology validation project?" Along with the list of possible mission payloads (the technologies), Linda also has a list of spacecraft to put them on, as well as a list of launch vehicle parameters. All she has to do is try them out in every possible combination (of which there are thousands) and see what might work. "Fortunately, we have a software tool to help with this analysis," says Linda. When it comes down to it, her job is primarily to figure out how to get the technologies into space. "Sometimes, it’s like figuring out how to get across town when you don’t have your own car. You have to get creative." She keeps a database of all possible options, including riding piggyback on another spacecraft, hitching a ride on a launch vehicle as a secondary payload, or sharing a launch vehicle with other NASA, Department of Defense, or even commercial payloads. Her assessment is but one of a gazillion factors to be considered in planning a mission, but it is indeed one of the very first "details" that forms the foundation for the rest of the mission. Find out some of the technologies that NMP has already validated or is considering at http://nmp.nasa.gov/TECHNOLOGY/innovative-tech.html Kids will enjoy watching Linda’s cartoon alter-ego talk about her job at http://spaceplace.nasa.gov/en/kids/live This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: NASA’s New Millennium Program selects breakthrough technologies that will be of the greatest use to future space and Earth science missions and that are perceived to be risky to the first user. The Red (Hot?) Planetby Patrick L. Barry Don't let Mars's cold, quiet demeanor fool you. For much of its history, the Red Planet has been a fiery world. Dozens of volcanoes that dot the planet's surface stand as monuments to the eruptions that once reddened Mars's skies with plumes of glowing lava. But the planet has settled down in its old age, and these volcanoes have been dormant for hundreds of millions of years. Or have they? Some evidence indicates that lava may have flowed on Mars much more recently. Images of the Martian surface taken by orbiting probes show regions of solidified lava with surprisingly few impact craters, suggesting that the volcanic rock is perhaps only a million years old. If so, could molten lava still occasionally flow on the surface of Mars today? With the help of some artificial intelligence software, a heat-sensing instrument currently orbiting Mars aboard NASA's Mars Odyssey spacecraft could be just the tool for finding active lava flows. "Discovering such flows would be a phenomenally exciting scientific finding," says Steve Chien, supervisor of the Artificial Intelligence Group at JPL. For example, volcanic activity could provide a source of heat, thus making it more likely that Martian microbes might be living in the frosty soil. The instrument, called THEMIS (for Thermal Emission Imaging System), can "see" the heat emissions of the Martian surface in high resolution - each pixel in a THEMIS image represents only 100 meters on the ground. But THEMIS produces about five times more data than it can transmit back to Earth. Scientists usually know ahead of time which THEMIS data they want to keep, but they can't plan ahead for unexpected events like lava flows. So Chien and his colleagues are customizing artificial intelligence software called ScienceCraft to empower THEMIS to identify important data on its own. This decision-making ability of the ScienceCraft software was first tested in Earth orbit aboard a satellite called Earth Observing-1 by NASA's New Millennium Program. Earth Observing-1 had already completed its primary mission, and the ScienceCraft experiment was part of the New Millennium Program’s Space Technology 6 mission. On Odyssey, ScienceCraft will look for anomalous hotspots on the cold, night side of Mars and flag that data as important. "Then the satellite can look at it more closely on the next orbit," Chien explains. Finding lava is considered a long shot, but since THEMIS is on all the time, "it makes sense to look," Chien says. Or better yet, have ScienceCraft look for you - it’s the intelligent thing to do. To learn more about the Autonomous ScienceCraft software and see an animation of how it works, visit http://ase.jpl.nasa.gov This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Just as changing cloud patterns on Earth were identified using Earth Observing-1’s Advanced Land Imager along with ScienceCraft software, the THEMIS instrument with ScienceCraft on the Mars Odyssey spacecraft can avoid transmitting useless images. A Missile In Your Eyeby Patrick L. Barry Satellite technology designed to catch ballistic missile launches may soon help doctors monitor the health of people's eyes. For the last 15 years, Greg Bearman and his colleagues at JPL have been working on a novel design for a spectrometer, a special kind of camera often used on satellites and spacecraft. Rather than snapping a simple picture, spectrometers measure the spectrum of wavelengths in the light coming from a scene. From that information, scientists can learn things about the physical properties of objects in the photo, be they stars or distant planets or vegetation on Earth's surface. In this case, however, the challenge was to capture snapshots of short-lived events - like missile launches! The team of JPL scientists designed the new spectrometer, called a computed tomographic imaging spectrometer (CTIS), in collaboration with the Ballistic Missile Defense Organization as a way to detect missiles by the spectral signatures of their exhaust. But now the scientists are pointing CTIS at another fast-moving scene: the retina of an eye. Blood flowing through the retina has a different spectral signature when it is rich in oxygen than when it is oxygen deprived. So eye doctors can use a spectrometer to look for low oxygen in the retina: an indicator of disease. However, because the eye is constantly moving, images produced by conventional spectrometers would have motion blurring that is difficult to correct. The spectrometer that Bearman helped to develop is different: It can capture the whole retina and its spectral information in a single snapshot as quick as 3 milliseconds. "We needed something fast," says Bearman, and this spectrometer is "missile-quick." CTIS is even relatively cheap to build, consisting of standard camera lenses and a custom, etched, transparent sheet called a grating. "With the exception of the grating, we bought everything on Amazon," he says. The grating was custom-designed at JPL. It has a pattern of microscopic steps on its surface that split incoming light into 25 separate images arranged in a 5 by 5 grid. The center image in the grid shows the scene undistorted, but colors in the surrounding images are slightly "smeared" apart, as if the light had passed through a prism. This separation of colors reveals the light's spectrum for each pixel in the image. "We're conducting clinical trials now," says Bearman. If all goes well, anti-missile technology may soon be catching eye problems before they have a chance to get off the ground. Information about other NASA-developed technologies with spin-off applications can be found at http://www.sti.nasa.gov/tto This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This three-color composite image from the computed tomographic imaging spectrometer shows the oxygenation of the blood in the arteries and veins of a human retina. (Arteries appear red, veins appear yellow). Cosmic CockroachesBy Dr. Tony Phillips Cockroaches are supposed to be tough, able to survive anything from a good stomping to a nuclear blast. But roaches are wimps compared to a little molecule that has recently caught the eye of biologists and astronomers - the polycyclic aromatic hydrocarbon. Polycyclic aromatic hydrocarbons (PAHs for short) are ring-shaped molecules made of carbon and hydrogen. "They’re all around us," says Achim Tappe of the Harvard Center for Astrophysics. "PAHs are present in mineral oils, coal, tar, tobacco smoke and automobile exhaust." Aromatic, ring-shaped molecules structurally akin to PAHs are found in DNA itself! That’s why Tappe’s recent discovery may be so important. "PAHs are so tough, they can survive a supernova." The story begins a few thousand years ago when a massive star in the Large Magellanic Cloud exploded, blasting nearby star systems and interstellar clouds with hot gas and deadly radiation. The expanding shell, still visible from Earth after all these years and catalogued by astronomers as "N132D," spans 80 light years and has swept up some 600 Suns worth of mass. Last year "we observed N132D using NASA’s Spitzer Space Telescope," says Tappe. Spitzer is an infrared (IR) telescope, and it has a spectrometer onboard sensitive to the IR emissions of PAHs. One look at N132D revealed "PAHs all around the supernova’s expanding shell. They appear to be swept up by a shock wave of 8 million degree gas. This is causing some damage to the molecules, but many of the PAHs are surviving." Astronomers have long known that PAHs are abundant not only on Earth but throughout the cosmos - they’ve been found in comet dust, meteorites and many cold interstellar clouds - but who knew they were so tough? "This is our first evidence that PAHs can withstand a supernova blast," he says. Their ability to survive may be key to life on Earth. Many astronomers are convinced that a supernova exploded in our corner of the galaxy 4-to-5 billion years ago just as the solar system was coalescing from primitive interstellar gas. In one scenario of life’s origins, PAHs survived and made their way to our planet. It turns out that stacks of PAHs can form in water - think, primordial seas - and provide a scaffold for nucleic acids with architectural properties akin to RNA and DNA. PAHs may be just tough enough for genesis. Cockroaches, eat your hearts out. Find out about other Spitzer discoveries at http://www.spitzer.caltech.edu This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Using the IR spectrometer on the Spitzer Space Telescope, scientists found organic molecules in supernova remnant N132D. Omit Needless Bytes!by Patrick Barry and Tony Phillips Now is an exciting time for space enthusiasts. In the history of the Space Age, there have never been so many missions "out there" at once. NASA has, for example, robots on Mars, satellites orbiting Mars, a spacecraft circling Saturn, probes en route to Pluto and Mercury - and four spacecraft, the two Voyagers and the two Pioneers, are exiting the solar system altogether. It’s wonderful, but it is also creating a challenge. The Deep Space Network that NASA uses to communicate with distant probes is becoming overtaxed. Status reports and data transmissions are coming in from all over the solar system - and there’s only so much time to listen. Expanding the network would be expensive, so it would be nice if these probes could learn to communicate with greater brevity. But how? Solving problems like this is why NASA created the New Millennium Program (NMP). The goal of NMP is to flight-test experimental hardware and software for future space missions. In 1998, for instance, NMP launched an experimental spacecraft called Deep Space 1 that carried a suite of new technologies, including a new kind of communication system known as Beacon Monitor. The system leverages the fact that for most of a probe's long voyage to a distant planet or asteroid or comet, it's not doing very much. There’s little to report. During that time, mission scientists usually only need to know whether the spacecraft is in good health. "If you don't need to transmit a full data stream, if you only need some basic state information, then you can use a much simpler transmission system," notes Henry Hotz, an engineer at NASA's Jet Propulsion Laboratory who worked on Beacon Monitor for Deep Space 1. So instead of beaming back complete data about the spacecraft’s operation, Beacon Monitor uses sophisticated software in the probe’s onboard computer to boil that data down to a single "diagnosis." It then uses a low-power antenna to transmit that diagnosis as one of four simple radio tones, signifying "all clear," "need some attention whenever you can," "need attention soon," or "I'm in big trouble - need attention right now!" "These simple tones are much easier to detect from Earth than complex data streams, so the mission needs far less of the network's valuable time and bandwidth," says Hotz. After being tested on Deep Space 1, Beacon Monitor was approved for the New Horizons mission, currently on its way to Pluto, beaming back a simple beacon as it goes. Discover more about Beacon Monitor technology, as well as other technologies, on the NMP Technology Validation Reports page, http://nmp-techval-reports.jpl.nasa.gov This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This artist's concept shows the New Horizons spacecraft during its planned encounter with Pluto and its moon, Charon. The spacecraft is currently using the Beacon Monitor system on its way to Pluto. Credit: Johns Hopkins University Applied Physics Laboratory/Southwest Research Institute (JHUAPL/SwRI) Chew on ThisThe Mars robotic rovers, Spirit and Opportunity, are equipped with RATs, or Rock Abrasion Tools. Their purpose is to abrade the surface patina off the Mars rocks so that the alpha x-ray spectrometer can analyze the minerals inside the rocks, rather than just on the surface. But future robotic missions to Mars will be asked to go even further below the surface. Scrapers and corers will gather rock samples of substantial size, that, in order to be analyzed by a spectrometer, will need to be crushed into a fine powder. Crushing rocks on Mars? Now there’s a problem that brings to mind a multitude of possible approaches: Whack them with a large hammer? Squeeze them until they explode? How about just chewing them up? It was with this latter metaphor that the planetary instrument engineers struck pay dirt - so to speak. Thanks to NASA’s Planetary Instrument Definition and Development Program, a small group of NASA engineers came up with the Mars Rock Crusher. Only six inches tall, it can chew the hardest rocks into a powder. The Mars Rock Crusher has two metal plates that work sort of like our jaws. One plate stays still, while the other plate moves. Rocks are dropped into the jaw between the two plates. As one plate moves in and out (like a lower jaw), rocks are crushed between the two plates. The jaw opening is larger toward the top and smaller towards the bottom. So when larger rocks are crushed near the top, the pieces fall down into the narrower part of the jaw, where they are crushed again. This process repeats until the rock particles are small enough to fall through a slit where the two plates are closest. Engineers have tested the Mars Rock Crusher with Earth rocks similar to those expected to be found on Mars. One kind of rock is hematite. The rusted iron in hematite and other rocks help give Mars its nickname "The Red Planet." Another kind of rock is magnetite, so-called because it is magnetic. Rocks made by volcanoes are called basalts. Some of the volcanoes on Mars may have produced basalts with a lot of a mineral called olivine. We call those olivine basalts, and the Rock Crusher chews them up nicely too. Visit http://www.jpl.nasa.gov/technology to read the latest about other NASA technologies for exploring other planets and improving life on this one. This article was written by Diane K. Fisher and provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Looking down on the jaws of the Mars Rock Crusher, we see a magnetite rock get crushed into smaller and smaller particles. The Ions of DawnBy Patrick L. Barry This summer, NASA will launch a probe bound for two unexplored worlds in our solar system's asteroid belt - giant asteroids Ceres and Vesta. The probe, called Dawn, will orbit first one body and then the other in a never-before-attempted maneuver. It has never been attempted, in part, because this mission would be virtually impossible with conventional propulsion. "Even if we were just going to go to Vesta, we would need one of the largest rockets that the U.S. has to carry all that propellant," says Marc Rayman, Project System Engineer for Dawn at JPL. Traveling to both worlds in one mission would require an even bigger rocket. This is a trip that calls for the unconventional. "We’re using ion propulsion," says Rayman. The ion engines for the Dawn spacecraft proved themselves aboard an earlier, experimental mission known as Deep Space 1 (DS1). Because ion propulsion is a relatively new technology that’s very different from conventional rockets, it was a perfect candidate for DS1, a part of NASA's New Millennium Program, which flight-tests new technologies so that missions such as Dawn can use those technologies reliably. "The fact that those same engines are now making the Dawn mission possible shows that New Millennium accomplished what it set out to," Rayman says. Ion engines work on a principle different from conventional rockets. A normal rocket engine burns a chemical fuel to produce thrust. An ion engine doesn't burn anything; a strong electric field in the engine propels charged atoms such as xenon to very high speed. The thrust produced is tiny - roughly equivalent to the weight of a piece of paper - but over time, it can generate as much speed as a conventional rocket while using only about 1/10 as much propellant. And Dawn will need lots of propulsion. It must first climb into Vesta's orbit, which is tilted about 7 degrees from the plane of the solar system. After studying Vesta, it will have to escape its gravity and maneuver to insert itself in an orbit around Ceres - the first spacecraft to orbit two distant bodies. Dawn's up-close views of these worlds will help scientists understand the early solar system. "They're remnants from the time the planets were being formed," Rayman says. "They have preserved a record of the conditions at the dawn of the solar system." Find out about other New Millennium Program validated technologies and how they are being used in science missions at http://nmp.nasa.gov/TECHNOLOGY/infusion.html. While you’re there, you can also download "Professor Starr’s Dream Trip," a storybook for grown-ups about how ion propulsion enabled a scientist’s dream of visiting the asteroids come true. A simpler children’s version is available at http://spaceplace.nasa.gov/en/kids/nmp/starr. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering of Dawn spacecraft, with asteroids. Largest are Vesta and Ceres. Credits: Dawn spacecraft - Orbital Sciences Corporation; background art - William K. Hartmann, courtesy UCLA. Clouds from Top to BottomBy Patrick L. Barry During the summer and fall of 2006, U.S. Coast Guard planes flew over the North Pacific in search of illegal, unlicensed, and unregulated fishing boats. It was a tricky operation - in part because low clouds often block the pilots' view of anything floating on the ocean surface below. To assist in these efforts, they got a little help from the stars. Actually, it was a satellite - CloudSat, an experimental NASA mission to study Earth’s clouds in an entirely new way. While ordinary weather satellites see only the tops of clouds, CloudSat’s radar penetrates clouds from top to bottom, measuring their vertical structure and extent. By tapping into CloudSat data processed at the Naval Research Laboratory (NRL) in Monterey, CA, Coast Guard pilots were better able to contend with low-lying clouds that might have otherwise hindered their search for illegal fishing activity. In the past, Coast Guard pilots would fly out over the ocean not knowing what visibility to expect. Now they can find out quickly. Data from research satellites usually takes days to weeks to process into a usable form, but NASA makes CloudSat's data publicly available on its QuickLook website and to users such as NRL in only a matter of hours - making the data useful for practical applications. "Before CloudSat, there was no way to measure cloud base from space worldwide," says Deborah Vane, project manager for CloudSat at NASA's Jet Propulsion Laboratory. CloudSat’s primary purpose is to better understand the critical role that clouds play in Earth's climate. But knowledge about the structure of clouds is useful not only for scientific research, but also to operational users such as Coast Guard patrol aircraft and Navy and commercial ships at sea. "Especially when it's dark, there’s limited information about storms at sea," says Vane. "With CloudSat, we can sort out towering thunderclouds from blankets of calmer clouds. And we have the ability to distinguish between light rain and rain that is falling from severe storms." CloudSat’s radar is much more sensitive to cloud structure than are radar systems operating at airports, and from its vantage point in space, Cloudsat builds up a view of almost the entire planet, not just one local area. "That gives you weather information that you don't have in any other way." There is an archive of all data collected since the start of the mission in May 2006 on the CloudSat QuickLook website at http://cloudsat.atmos.colostate.edu And to introduce kids to the fun of observing the clouds, go to http://spaceplace.nasa.gov/en/kids/cloudsat_puz.shtml. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: A CloudSat ground track appears as a red line overlaid upon a GMS-6 (a Japanese weather satellite) infrared image. CloudSat is crossing the north-central Pacific Ocean on a descending orbit (from upper-right to lower-left) near a storm front. The radar data corresponding to this ground track (beginning in the center panel and continuing into the lower panel) shows a vertical cloud profile far more complex than the two-dimensional GMS-6 imagery would suggest. Thicker clouds and larger droplets are shown in yellow/red tones, while thinner clouds are shown in blue. Early Bird Gets the Worm or "Black Hole Breakfast"by Dr. Tony Phillips We all know that birds eat worms. Every day, millions of birds eat millions of worms. It’s going on all around you! But how often have you awakened in the morning, stalked out in the dewy grass, and actually seen a bird having breakfast? Even though we know it happens all the time, a bird gulping a worm is a rare sight. Just like a black hole gulping a star.... Every day in the Universe, millions of stars fall into millions of black holes. And that’s bad news for the stars. Black holes exert terrible tides, and stars that come too close are literally ripped apart as they fall into the gullet of the monster. A long burp of X-rays and ultraviolet radiation signals the meal for all to see. Yet astronomers rarely catch a black hole in the act. "It’s like the problem of the bird and the worm," says astronomer Christopher Martin of Caltech. "You have to be in the right place at the right time, looking in the right direction and paying attention." A great place to look is deep in the cores of galaxies. Most galaxies have massive black holes sitting in their pinwheel centers, with dense swarms of stars all around. An occasional meal is inevitable. A group of astronomers led by Suvi Gezari of Caltech recently surveyed more than 10,000 galactic cores-and they caught one! In a distant, unnamed elliptical galaxy, a star fell into a central black hole and "burped" a blast of ultraviolet radiation. "We detected the blast using the Galaxy Evolution Explorer (GALEX), an ultraviolet space telescope," explains Gezari. Her team reported the observation in the December 2006 issue of The Astrophysical Journal Letters. "Other telescopes have seen black holes devouring stars before," she adds, "but this is the first time we have been able to watch the process from beginning to end." The meal began about two years ago. After the initial blast, radiation diminished as the black hole slowly consumed the star. GALEX has monitored the process throughout. Additional data from the Chandra X-ray Observatory, the Canada-France-Hawaii Telescope and the Keck Telescope in Hawaii helped Gezari’s team chronicle the event in multiple wavelengths. Studying the process in its entirety "helps us understand how black holes feed and grow in their host galaxies," notes Martin. One down, millions to go. "Now that we know we can observe these events with ultraviolet light," says Gezari, "we've got a new tool for finding more." For more on this and other findings of GALEX, see http://www.galex.caltech.edu. For help explaining black holes to kids, visit The Space Place at http://spaceplace.nasa.gov. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: In this artist’s concept, a giant black hole is caught devouring a star that ventured too closely. Even Solar Sails Need a Mastby Patrick L. Barry Like the explorers of centuries past who set sail for new lands, humans may someday sail across deep space to visit other stars. Only it won't be wind pushing their sails, but the slight pressure of sunlight. Solar sails, as they're called, hold great promise for providing propulsion in space without the need for heavy propellant. But building a solar sail will be hard; to make the most of sunlight's tiny push, the sail must be as large as several football fields, yet weigh next to nothing. Creating a super-lightweight material for the sail itself is tricky enough, but how do you build a "mast" for that sail that's equally light and strong? Enter SAILMAST, a program to build and test-fly a mast light enough for future solar sails. With support from NASA’s In-Space Propulsion Program to mature the technology and perform ground demonstrator tests, SAILMAST’s engineers were ready to produce a truss suitable for validation in space that's 40 meters (about 130 feet) long, yet weighs only 1.4 kilograms (about 3 pounds)! In spite of its light weight, this truss is surprisingly rigid. "It's a revelation when people come in and actually play with one of the demo versions - it’s like, whoa, this is really strong!" says Michael McEachen, principal investigator for SAILMAST at ATK Space Systems in Goleta, California. SAILMAST will fly aboard NASA's Space Technology 8 (ST8) mission, scheduled to launch in February 2009. The mission is part of NASA’s New Millennium Program, which flight tests cutting-edge technologies so that they can be used reliably for future space exploration. While actually flying to nearby stars is probably decades away, solar sails may come in handy close to home. Engineers are eyeing this technology for "solar sentinels," spacecraft that orbit the Sun to provide early warning of solar flares. Once in space, ST8 will slowly deploy SAILMAST by uncoiling it. The truss consists of three very thin, 40-meter-long rods connected by short cross-members. The engineers used high-strength graphite for these structural members so that they could make them very thin and light. The key question is how straight SAILMAST will be after it deploys in space. The smaller the curve of the mast the more load it can support. "That's really why we need to fly it in space, to see how straight it is when it's floating weightlessly," McEachen says. It’s an important step toward building a sail for the space-mariners of the future. Find out more about SAILMAST at http://nmp.nasa.gov/st8. Kids can visit http://spaceplace.nasa.gov/en/kids/st8/sailmast to see how SAILMAST is like a Slinky® toy in space. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: SAILMAST is the thin triangular truss in front of the picture. It is attached to a section of a silver foil solar sail section shown here in a laboratory test. The mast in the picture is 2m (6 ft) long. The Space Technology 8 mission will test the SAILMAST, which is 20 times longer. A Great Big Wreckby Dr. Tony Phillips People worry about asteroids. Being hit by a space rock can really ruin your day. But that’s nothing. How would you like to be hit by a whole galaxy? It could happen. Astronomers have long known that the Andromeda Galaxy is on a collision course with the Milky Way. In about 3 billion years, the two great star systems will crash together. Earth will be in the middle of the biggest wreck in our part of the Universe. Astronomer John Hibbard isn’t worried. "Galaxy collisions aren’t so bad," he says. A typical spiral galaxy contains a hundred billion stars, yet when two such behemoths run into each other "very few stars collide. The stars are like pinpricks with lots of space between them. The chance of a direct hit, star vs. star, is very low." Hibbard knows because he studies colliding galaxies, particularly a nearby pair called the Antennae. "The two galaxies of the Antennae system are about the same size and type as Andromeda and the Milky Way." He believes that the Antennae are giving us a preview of what’s going to happen to our own galaxy. The Antennae get their name from two vast streamers of stars that resemble the feelers on top of an insect’s head. These streamers, called "tidal tails," are created by gravitational forces - one galaxy pulling stars from the other. The tails appear to be scenes of incredible violence. But looks can be deceiving: "Actually, the tails are quiet places," says Hibbard. "They’re the peaceful suburbs of the Antennae." He came to this conclusion using data from GALEX, an ultraviolet space telescope launched by NASA in 2003. The true violence of colliding galaxies is star formation. While individual stars rarely collide, vast interstellar clouds of gas do smash together. These clouds collapse. Gravity pulls the infalling gas into denser knots until, finally, new stars are born. Young stars are difficult to be around. They emit intensely unpleasant radiation and tend to "go supernova." GALEX can pinpoint hot young stars by the UV radiation they emit and, in combination with other data, measure the rate of star birth. "Surprisingly," Hibbard says, "star formation rates are low in the tidal tails, several times lower than what we experience here in the Milky Way." The merging cores of the Antennae, on the other hand, are sizzling with new stars, ready to explode. So what should you do when your galaxy collides? A tip from GALEX: head for the tails. To see more GALEX images, visit http://www.galex.caltech.edu. Kids can read about galaxies and how a telescope can be a time machine at http://spaceplace.nasa.gov/en/educators/galex_puzzles.pdf. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This GALEX UV image of the colliding Antennae Galaxies shows areas of active star formation, which is not in the tidal tails as one might expect. Space Weather for Air Travelersby Dr. Tony Phillips At a time when much of the airline industry is struggling, one type of air travel is doing remarkably well: polar flights. In 1999, United Airlines made just twelve trips over the Arctic. By 2005, the number of flights had grown to 1,402. Other airlines report similar growth. The reason for the increase is commerce. Business is booming along Asia’s Pacific Rim, and business travel is booming with it. On our spherical Earth, the shortest distance from Chicago to Beijing or New York to Tokyo is over the North Pole. Suddenly, business travelers are spending a lot of time in the Arctic. With these new routes, however, comes a new concern: space weather. "Solar storms have a big effect on polar regions of our planet," explains Steve Hill of NOAA’s Space Weather Prediction Center in Boulder, Colorado. Everyone knows about the Northern Lights, but there’s more to it than that: "When airplanes fly over the poles during solar storms, they can experience radio blackouts, navigation errors and computer reboots all caused by space radiation." In 2005, United Airlines reported dozens of flights diverted from polar routes by nasty space weather. Delays ranged from 8 minutes to nearly 4 hours, and each unplanned detour burned expensive fuel. Money isn’t the only concern: Pilots and flight attendants who fly too often over the poles could absorb more radiation than is healthy. "This is an area of active research figuring out how much exposure is safe for flight crews," says Hill. "Clearly, less is better." To help airlines avoid bad space weather, NOAA has begun equipping its GOES weather satellites with improved instruments to monitor the Sun. Recent additions to the fleet, GOES 12 and 13, carry X-ray telescopes that take spectacular pictures of sunspots, solar flares, and coronal holes spewing streams of solar wind in our direction. Other GOES sensors detect solar protons swarming around our planet, raising alarms when radiation levels become dangerous. "Our next-generation satellite will be even better," says Hill. Slated for launch in 2014, GOES-R will be able to photograph the Sun through several different X-ray and ultra-violet filters. Each filter reveals a somewhat different layer of the Sun’s explosive atmosphere, a boon to forecasters. Also, advanced sensors will alert ground controllers to a variety of dangerous particles near Earth, including solar protons, heavy ions and galactic cosmic rays. "GOES-R should substantially improve our space weather forecasts," says Hill. That means friendlier skies on your future trips to Tokyo. For the latest space weather report, visit the website of the Space Weather Prediction Center at http://www.sec.noaa.gov . For more about the GOES-R series spacecraft, see http://goespoes.gsfc.nasa.gov/goes/spacecraft/r_spacecraft.html. For help in explaining geostationary orbits to kids, or anyone else, visit The Space Place at http://spaceplace.nasa.gov/en/kids/goes/goes_poes_orbits.shtml. Caption: The shortest airline routes from the Eastern U.S. to popular destinations in Asia go very near the magnetic North Pole, where space weather is of greatest concern. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Martian DevilsDr. Tony Phillips Admit it. Whenever you see a new picture of Mars beamed back by Spirit or Opportunity, you scan the rocks to check for things peeking out of the shadows. A pair of quivering green antennas, perhaps, or a little furry creature crouched on five legs…? Looking for Martians is such a guilty pleasure. Well, you can imagine the thrill in 2004 when scientists were checking some of those pictures and they did see something leap out. It skittered across the rocky floor of Gusev Crater and quickly disappeared. But it wasn’t a Martian; Spirit had photographed a dust devil! Dust devils are tornadoes of dust. On a planet like Mars which is literally covered with dust, and where it never rains, dust devils are an important form of weather. Some Martian dust devils grow almost as tall as Mt. Everest, and researchers suspect they’re crackling with static electricity a form of Martian lightning. NASA is keen to learn more. How strong are the winds? Do dust devils carry a charge? When does devil season begin and end? Astronauts are going to want to know the answers before they set foot on the red planet. The problem is, these dusty twisters can be devilishly difficult to catch. Most images of Martian dust devils have been taken by accident, while the rovers were looking for other things. This catch-as-catch-can approach limits what researchers can learn. No more! The two rovers have just gotten a boost of artificial intelligence to help them recognize and photograph dust devils. It comes in the form of new software, uploaded in July and activated in September 2006. This software is based on techniques developed and tested as part of the NASA New Millennium Program’s Space Technology 6 project. Testing was done in Earth orbit onboard the EO-1 (Earth Observing-1) satellite, says Steve Chien, supervisor of JPL’s Artificial Intelligence Group. Scientists using EO-1 data were especially interested in dynamic events such as volcanoes erupting or sea ice breaking apart. So Chien and colleagues programmed the satellite to notice change. It worked beautifully: We measured a 100-fold increase in science results for transient events. Now that the techniques have been tested in Earth orbit, they are ready to help Spirit and Opportunity catch dust devils or anything else that moves on Mars. If we saw Martians, that would be great, laughs Chien. Even scientists have their guilty pleasures. Find out more about the Space Technology 6 Autonomous Sciencecraft technology experiment at http://nmp.nasa.gov/st6/TECHNOLOGY/sciencecraft_tech.html, and the use of the technology on the Mars Rovers at http://nmp.nasa.gov/TECHNOLOGY/infusion.html. Kids can visit http://spaceplace.nasa.gov/en/kids/nmp_action.shtml and do a New Millennium Program-like test at home to see if a familiar material would work well in space. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The top half of this image is part of a series of images of a passing dust devil on Mars caught by Spirit. In the bottom half, the image has been filtered to remove everything that did not change from one image to the other. Notice the faint track left by the dust devil. Credit NASA/JPL/Mark T. Lemmon, Univ. of Arizona Lunar and Planetary Laboratory. The Planet In The MachineBy Diane K. Fisher and Tony Phillips The story goes that a butterfly flapping its wings in Brazil can, over time, cause a tornado in Kansas. The “butterfly effect” is a common term to evoke the complexity of interdependent variables affecting weather around the globe. It alludes to the notion that small changes in initial conditions can cause wildly varying outcomes. Now imagine millions of butterflies flapping their wings. And flies and crickets and birds. Now you understand why weather is so complex. All kidding aside, insects are not in control. The real “butterfly effect” is driven by, for example, global winds and ocean currents, polar ice (melting and freezing), clouds and rain, and blowing desert dust. All these things interact with one another in bewilderingly complicated ways. And then there’s the human race. If a butterfly can cause a tornado, what can humans cause with their boundlessly reckless disturbances of initial conditions? Understanding how it all fits together is a relatively new field called Earth system science. Earth system scientists work on building and fine-tuning mathematical models (computer programs) that describe the complex inter-relationships of Earth’s carbon, water, energy, and trace gases as they are exchanged between the terrestrial biosphere and the atmosphere. Ultimately, they hope to understand Earth as an integrated system, and model changes in climate over the next 50-100 years. The better the models, the more accurate and detailed will be the image in the crystal ball. NASA’s Earth System Science program provides real-world data for these models via a swarm of Earth-observing satellites. The satellites, which go by names like Terra and Aqua, keep an eye on Earth’s land, biosphere, atmosphere, clouds, ice, and oceans. The data they collect are crucial to the modeling efforts. Some models aim to predict short-term effects—in other words, weather. They may become part of severe weather warning systems and actually save lives. Other models aim to predict long-term effects—or climate. But, long-term predictions are much more difficult and much less likely to be believed by the general population, since only time can actually prove or disprove their validity. After all, small errors become large errors as the model is left to run into the future. However, as the models are further validated with near- and longer-term data, and as different models converge on a common scenario, they become more and more trustworthy to show us the future while we can still do something about it—we hope. For a listing and more information on each of NASA’s (and their partners’) Earth data-gathering missions, visit http://science.hq.nasa.gov/missions/earth.html. Kids can get an easy introduction to Earth system science and play Earthy word games at http://spaceplace.nasa.gov/en/kids/earth/wordfind. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: CloudSat is one of the Earth observing satellites collecting data that will help develop and refine atmospheric circulation models and other types of weather and climate models. CloudSat’s unique radar system reads the vertical structure of clouds, including liquid water and ice content, and how clouds affect the distribution of the Sun’s energy in the atmosphere. See animation of this data simulation at http://www.nasa.gov/mission_pages/calipso/multimedia/cloud_calip_mm.html. Staggering DistanceBy Dr. Tony Phillips Tonight, when the sun sets and the twilight fades to black, go outside and look southwest. There’s mighty Jupiter, gleaming brightly. It looks so nearby, yet Jupiter is 830 million km away. Light from the sun takes 43 minutes to reach the giant planet, and for Earth’s fastest spaceship, New Horizons, it’s a trip of 13 months. That’s nothing. Not far to the left of Jupiter is Pluto. Oh, you won’t be able to see it. Tiny Pluto is almost 5 billion km away. Sunlight takes more than 4 hours to get there, and New Horizons 9 years. From Pluto, the sun is merely the brightest star in a cold, jet-black sky. That’s nothing. A smidgen to the right of Pluto, among the stars of the constellation Ophiuchus, is Voyager 1. Launched from Florida 29 years ago, the spacecraft is a staggering 15 billion km away. It has traveled beyond all the known planets, beyond the warmth of the sun, almost beyond the edge of the solar system itself. Now that’s something. “On August 15, 2006, Voyager 1 reached the 100 AU mark—in other words, it is 100 times farther from the Sun than Earth,” says Ed Stone, Voyager project scientist and the former director of NASA's Jet Propulsion Laboratory. “This is an important milestone in our exploration of the Solar System. No other spacecraft has gone so far.” At 100 AU (astronomical units), Voyager 1 is in a strange realm called “the heliosheath.” As Stone explains, our entire solar system—planets and all—sits inside a giant bubble of gas called the heliosphere. The sun is responsible; it blows the bubble by means of the solar wind. Voyager 1 has traveled all the way from the bubble’s heart to its outer edge, a gassy membrane dividing the solar system from interstellar space. This “membrane” is the heliosheath. Before Voyager 1 reached its present location, researchers had calculated what the heliosheath might be like. “Many of our predictions were wrong,” says Stone. In situ, Voyager 1 has encountered unexpected magnetic anomalies and a surprising increase in low-energy cosmic rays, among other things. It’s all very strange—“and we’re not even out of the Solar System yet.” To report new developments, Voyager radios Earth almost every day. At the speed of light, the messages take 14 hours to arrive. Says Stone, “it’s worth the wait.” Keep up with the Voyager mission at http://voyager.jpl.nasa.gov. To learn the language of Voyager’s messages, kids (of all ages) can check out http://spaceplace.nasa.gov/en/kids/vgr_fact1.shtml. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: In case it is ever found by intelligent beings elsewhere in the galaxy, Voyager carries a recording of images and sounds of Earth and its inhabitants. The diagrams on the cover of the recording symbolize Earth’s location in the galaxy and how to play the record. Deadly PlanetsBy Patrick L. Barry and Dr. Tony Phillips About 900 light years from here, there's a rocky planet not much bigger than Earth. It goes around its star once every hundred days, a trifle fast, but not too different from a standard Earth-year. At least two and possibly three other planets circle the same star, forming a complete solar system. Interested? Don't be. Going there would be the last thing you ever do. The star is a pulsar, PSR 1257+12, the seething-hot core of a supernova that exploded millions of years ago. Its planets are bathed not in gentle, life-giving sunshine but instead a blistering torrent of X-rays and high-energy particles. "It would be like trying to live next to Chernobyl," says Charles Beichman, a scientist at JPL and director of the Michelson Science Center at Caltech. Our own sun emits small amounts of pulsar-like X-rays and high energy particles, but the amount of such radiation coming from a pulsar is "orders of magnitude more," he says. Even for a planet orbiting as far out as the Earth, this radiation could blow away the planet's atmosphere, and even vaporize sand right off the planet's surface. Astronomer Alex Wolszczan discovered planets around PSR 1257+12 in the 1990s using Puerto Rico’s giant Arecibo radio telescope. At first, no one believed worlds could form around pulsars—it was too bizarre. Supernovas were supposed to destroy planets, not create them. Where did these worlds come from? NASA’s Spitzer Space Telescope may have found the solution. Last year, a group of astronomers led by Deepto Chakrabarty of MIT pointed the infrared telescope toward pulsar 4U 0142+61. Data revealed a disk of gas and dust surrounding the central star, probably wreckage from the supernova. It was just the sort of disk that could coalesce to form planets! As deadly as pulsar planets are, they might also be hauntingly beautiful. The vaporized matter rising from the planets' surfaces could be ionized by the incoming radiation, creating colorful auroras across the sky. And though the pulsar would only appear as a tiny dot in the sky (the pulsar itself is only 20-40 km across), it would be enshrouded in a hazy glow of light emitted by radiation particles as they curve in the pulsar's strong magnetic field. Wasted beauty? Maybe. Beichman points out the positive: "It's an awful place to try and form planets, but if you can do it there, you can do it anywhere." More news and images from Spitzer can be found at http://www.spitzer.caltech.edu/. In addition, The Space Place Web site features a cartoon talk show episode starring Michelle Thaller, a scientist on Spitzer. Go to http://spaceplace.nasa.gov/en/kids/live/ for a great place to introduce kids to infrared and the joys of astronomy. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s concept of a pulsar and surrounding disk of rubble called a “fallback” disk, out of which new planets could form. Celebrating 40 Years of Intent ListeningBy Diane K. Fisher In nature, adjacent animals on the food chain tend to evolve together. As coyotes get sneakier, rabbits get bigger ears. Hearing impaired rabbits die young. Clumsy coyotes starve. So each species pushes the other to “improve.” The technologies pushing robotic space exploration have been like that. Improvements in the supporting communications and data processing infrastructure on the ground (the “ears” of the scientists) have allowed spacecraft to go farther, be smaller and smarter, and send increasingly faint signals back to Earth—and with a fire hose instead of a squirt gun. Since 1960, improvements in NASA’s Deep Space Network (DSN) of radio wave antennas have made possible the improvements and advances in the robotic spacecraft they support. “In 1964, when Mariner IV flew past Mars and took a few photographs, the limitation of the communication link meant that it took eight hours to return to Earth a single photograph from the Red Planet. By 1989, when Voyager observed Neptune, the DSN capability had increased so much that almost real-time video could be received from the much more distant Planet, Neptune,” writes William H. Pickering, Director of JPL from 1954 to 1976, in his Foreword to the book, Uplink-Downlink: A History of the Deep Space Network, 1957-1997, by Douglas J. Mudgway. Mudgway, an engineer from Australia, was involved in the planning and construction of the first 64-m DSN antenna, which began operating in the Mojave Desert in Goldstone, California, in 1966. This antenna, dubbed “Mars,” was so successful from the start, that identical 64-m antennas were constructed at the other two DSN complexes in Canberra, Australia, and Madrid, Spain. As Mudgway noted in remarks made during the recent observance of the Mars antenna’s 40 years of service, “In no time at all, the flight projects were competing with radio astronomy, radio science, radar astronomy, SETI [Search for Extra-terrestrial Intelligence], geodynamics, and VLBI [Very Long Baseline Interferometry] for time on the antenna . . . It was like a scientific gold rush.” In 1986 began an ambitious upgrade program to improve the antenna’s performance even further. Engineering studies had shown that if the antenna’s diameter were increased to 70 m and other improvements were made, the antenna’s performance could be improved by a factor of 1.6. Thus it was that all three 64-m DSN antennas around the world became 70-m antennas. Improvements have continued throughout the years. “This antenna has played a key role in almost every United States planetary mission since 1966 and quite a few international space missions as well. Together with its twins in Spain and Australia, it has been a key element in asserting America’s pre-eminence in the scientific exploration of the solar system,” remarks Mudgway. Find out more about the DSN and the history of the Mars antenna at http://deepspace.jpl.nasa.gov/dsn/features/40years.html. Kids (and grownups) can learn how pictures are sent through space at http://spaceplace.nasa.gov/en/kids/phonedrmarc/2003_august.shtml. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: For over 40 years, the “Mars” 70-m Deep Space Network antenna at Goldstone, California, has vigilantly listened for tiny signals from spacecraft that are billions of miles away. From Thunderstorms to Solar Storms...By Patrick L. Barry When severe weather occurs, there's a world of difference for people on the ground between a storm that's overhead and one that's several kilometers away. Yet current geostationary weather satellites can be as much as 3 km off in pinpointing the true locations of storms. A new generation of weather satellites will boost this accuracy by 2 to 4 times. The first in this new installment of NOAA's Geostationary Operational Environmental Satellites series, called GOES-N, was launched May 24 by NASA and Boeing for NOAA (National Oceanic and Atmospheric Administration). (A new polar-orbiting weather satellite, NOAA-18, was launched May 2005.) Along with better accuracy at pinpointing storms, GOES-N sports a raft of improvements that will enhance our ability to monitor the weather—both normal, atmospheric weather and “space weather.” “Satellites eventually wear out or get low on fuel, so we've got to launch new weather satellites every few years if we want to keep up the continuous eye on weather that NOAA has maintained for more than 30 years now,” says Thomas Wrublewski, liaison officer for NOAA at NASA's Goddard Space Flight Center. Currently, GOES-N is in a “parking” orbit at 90° west longitude over the equator. For the next 6 months it will remain there while NASA thoroughly tests all its systems. If all goes well, it will someday replace one of the two active GOES satellites—either the eastern satellite (75°W) or the western one (135°W), depending on the condition of those satellites at the time. Unlike all previous GOES satellites, GOES-N carries star trackers aboard to precisely determine its orientation in space. Also for the first time, the storm-tracking instruments have been mounted to an “optical bench,” which is a very stable platform that resists thermal warping. These two improvements will let scientists say with 2 to 4 times greater accuracy exactly where storms are located. Also, X-ray images of the Sun taken by GOES-N will be about twice as sharp as before. The new Solar X-ray Imager (SXI) will also automatically identify solar flares as they happen, instead of waiting for a scientist on the ground to analyze the images. Flares affect space weather, triggering geomagnetic storms that can damage communications satellites and even knock out city power grids. The improved imaging and detection of solar flares by GOES-N will allow for earlier warnings. So for thunderstorms and solar storms alike, GOES-N will be an even sharper eye in the sky. Find out more about GOES-N at goespoes.gsfc.nasa.gov/goes . Also, for young people, the SciJinks Weather Laboratory at scijinks.nasa.gov now includes a printable booklet titled “How Do You Make a Weather Satellite?” Just click on Technology. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: New GOES-N satellite launches, carrying an imaging radiometer, an atmospheric sounder, and a collection of other space environment monitoring instruments. Not a Moment WastedBy Dr. Tony Phillips The Ring Nebula. Check. M13. Check. Next up: The Whirlpool galaxy. You punch in the coordinates and your telescope takes off, slewing across the sky. You tap your feet and stare at the stars. These Messier marathons would go much faster if the telescope didn’t take so long to slew. What a waste of time! Don’t tell that to the x-ray astronomers. “We’re putting our slew time to good use,” explains Norbert Schartel, project scientist for the European Space Agency’s XMM-Newton x-ray telescope. The telescope, named for Sir Isaac Newton, was launched into Earth orbit in 1999. It’s now midway through an 11-year mission to study black holes, neutron stars, active galaxies and other violent denizens of the Universe that show up particularly well at x-ray wavelengths. For the past four years, whenever XMM-Newton slewed from one object to another, astronomers kept the telescope’s cameras running, recording whatever might drift through the field of view. The result is a stunning survey of the heavens covering 15% of the entire sky. Sifting through the data, ESA astronomers have found entire clusters of galaxies unknown before anyone started paying attention to “slew time.” Some already-known galaxies have been caught in the act of flaring—a sign, researchers believe, of a central black hole gobbling matter from nearby stars and interstellar clouds. Here in our own galaxy, the 20,000 year old Vela supernova remnant has been expanding. XMM-Newton has slewed across it many times, tracing its changing contours in exquisite detail. The slew technique works because of XMM-Newton’s great sensitivity. It has more collecting area than any other x-ray telescope in the history of astronomy. Sources flit through the field of view in only 10 seconds, but that’s plenty of time in most cases to gather valuable data. The work is just beginning. Astronomers plan to continue the slew survey, eventually mapping as much as 80% of the entire sky. No one knows how many new clusters will be found or how many black holes might be caught gobbling their neighbors. One thing’s for sure: “There will be new discoveries,” says Schartel. Tap, tap, tap. The next time you’re in the backyard with your telescope, and it takes off for the Whirlpool galaxy, don’t just stand there. Try to keep up with the moving eyepiece. Look, you never know what might drift by. See some of the other XMM-Newton images at http://sci.esa.int . For more about XMM-Newton’s Education and Public Outreach program, including downloadable classroom materials, go to http://xmm.sonoma.edu. Kids can learn about black holes and play “Black Hole Rescue” at The Space Place, http://spaceplace.nasa.gov/, under “Games.” This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The image on the left is the Vela Supernova Remnant as imaged in X-rays by ROSAT. On the right are some of the slew images obtained by XMM-Newton in its “spare” time. Who Wants to be a Daredevil?By Patrick L. Barry and Dr. Tony Phillips When exploring space, NASA naturally wants to use all the newest and coolest technologies—artificial intelligence, solar sails, onboard supercomputers, exotic materials. But “new” also means unproven and risky, and that could be a problem. Remember HAL in the movie “2001: A Space Odyssey”? The rebellious computer clearly needed some pre-flight testing. Testing advanced technologies in space is the mission of the New Millennium Program (NMP), created by NASA’s Science Mission Directorate in 1995 and run by JPL. Like the daredevil test pilots of the 1950s who would fly the latest jet technology, NMP flies new technologies in space to see if they're ready for prime time. That way, future missions can use the technologies with much less risk. Example: In 1999, the program’s Deep Space 1 probe tested a system called “AutoNav,” short for Autonomous Navigation. AutoNav used artificial intelligence to steer the spacecraft without human intervention. It worked so well that elements of AutoNav were installed on a real mission, Deep Impact, which famously blasted a crater in Comet Tempel 1 on July 4, 2005. Without AutoNav, the projectile would have completely missed the comet. Some NMP technologies “allow us to do things that we literally could not do before,” says Jack Stocky, Chief Technologist for NMP. Dozens of innovative technologies tested by NMP will lead to satellites and space probes that are smaller, lighter, more capable and even cheaper than those of today. Another example: An NMP test mission called Space Technology 9, which is still in the planning phase, may test-fly a solar sail. Solar sails use the slight pressure of sunlight itself, instead of heavy fuels, to propel a spacecraft. Two proposed NASA missions would be possible only with dependable solar sails—L1 Diamond and Solar Polar Imager—both of which would use solar sails to fly spacecraft that would study the Sun. “The technologies that we validate have future missions that need them,” Stocky says. “We try to target [missions] that are about 15 to 20 years out.” A menagerie of other cool NMP technologies include ion thrusters, hyperspectral imagers, and miniaturized electronics for spacecraft navigation and control. NMP focuses on technologies that have been proven in the laboratory but must be tested in the extreme cold, vacuum, and high radiation environment of space, which can’t be fully recreated in the lab. New NMP missions fly every year and one-half to two years, taking tomorrow’s space technology for a daredevil test drive. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering of a four-quadrant solar sail propulsion system, with payload. NASA is designing and developing such concepts, a sub-scale model of which may be tested on a future NMP mission. Planets in Strange PlacesBy Trudy E. Bell Red star, blue star, big star, small star—planets may form around virtually any type or size of star throughout the universe, not just around mid-sized middle-aged yellow stars like the Sun. That’s the surprising implication of two recent discoveries from the 0.85-meter-diameter Spitzer Space Telescope, which is exploring the universe from orbit at infrared (heat) wavelengths blocked by the Earth’s atmosphere. At one extreme are two blazing, blue “hypergiant” stars 180,000 light-years away in the Large Magellanic Cloud, one of the two companion galaxies to our Milky Way. The stars, called R 66 and R 126, are respectively 30 and 70 times the mass of the Sun, “about as massive as stars can get,” said Joel Kastner, professor of imaging science at the Rochester Institute of Technology in New York. R 126 is so luminous that if it were placed 10 parsecs (32.6 light-years) away—a distance at which the Sun would be one of the dimmest stars visible in the sky—the hypergiant would be as bright as the full moon, “definitely a daytime object,” Kastner remarked. Such hot stars have fierce solar winds, so Kastner and his team are mystified why any dust in the neighborhood hasn’t long since been blown away. But there it is: an unmistakable spectral signature that both hypergiants are surrounded by mammoth disks of what might be planet-forming dust and even sand. At the other extreme is a tiny brown dwarf star called Cha 110913-773444, relatively nearby (500 light-years) in the Milky Way. One of the smallest brown dwarfs known, it has less than 1 percent the mass of the Sun. It’s not even massive enough to kindle thermonuclear reactions for fusing hydrogen into helium. Yet this miniature “failed star,” as brown dwarfs are often called, is also surrounded by a flat disk of dust that may eventually clump into planets. (Note: This brown dwarf discovery was made by a group led by Kevin Luhman of Pennsylvania State University.) Although actual planets have not been detected (in part because of the stars’ great distances), the spectra of the hypergiants show that their dust is composed of forsterite, olivine, aromatic hydrocarbons, and other geological substances found on Earth. These newfound disks represent “extremes of the environments in which planets might form,” Kastner said. “Not what you’d expect if you think our solar system is the rule.” Hypergiants and dwarfs? The Milky Way could be crowded with worlds circling every kind of star imaginable—very strange, indeed. Keep up with the latest findings from the Spitzer at www.spitzer.caltech.edu/. For kids, the Infrared Photo Album at The Space Place (spaceplace.nasa.gov/en/kids/sirtf1/sirtf_action.shtml) introduces the electromagnetic spectrum and compares the appearance of common scenes in visible versus infrared light. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Artist’s rendering compares size of a hypothetical hypergiant star and its surrounding dusty disk to that of our solar system. Micro-sats with Macro-potentialBy Patrick L. Barry Future space telescopes might not consist of a single satellite such as Hubble, but a constellation of dozens or even hundreds of small satellites, or “micro-sats,” operating in unison. Such a swarm of little satellites could act as one enormous telescope with a mirror as large as the entire constellation, just as arrays of Earth-bound radio telescopes do. It could also last for a long time, because damage to one micro-sat wouldn’t ruin the whole space telescope; the rest of the swarm could continue as if nothing had happened. And that’s just one example of the cool things that micro-sats could do. Plus, micro-sats are simply smaller and lighter than normal satellites, so they’re much cheaper to launch into space. In February, NASA plans to launch its first experimental micro-sat mission, called Space Technology 5. As part of the New Millennium Program, ST5 will test out the crucial technologies needed for micro-sats—such as miniature thrust and guidance systems—so that future missions can use those technologies dependably. Measuring only 53 centimeters (20 inches) across and weighing a mere 25 kilograms (55 pounds), each of the three micro-sats for ST5 resembles a small television in size and weight. Normal satellites can be as large and heavy as a school bus. ”ST5 will also gather scientific data, helping scientists explore Earth’s magnetic field and space weather,” says James Slavin, Project Scientist for ST5. Slavin suggests some other potential uses for micro-sats: A cluster of micro-sats between the Earth and the Sun—spread out in space like little sensor buoys floating in the ocean—could sample incoming waves of high-speed particles from an erupting solar flare, thus giving scientists hours of warning of the threat posed to city power grids and communications satellites. Or perhaps a string of micro-sats, flying single file in low-Earth orbit, could take a series of snapshots of violent thunderstorms as each micro-sat in the “train” passes over the storm. This technology would combine the continuous large-scale storm monitoring of geosynchronous weather satellites—which orbit far from the Earth at about 36,000 kilometers’ altitude—with the up-close, highly detailed view of satellites only 400 kilometers overhead. If ST5 is successful, these little satellites could end up playing a big role in future exploration. The ST5 Web site at nmp.jpl.nasa.gov/st5 has the details. Kids can have fun with ST5 at http://spaceplace.nasa.gov, by just typing ST5 in the site’s Find It field. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The Space Technology 5 mission will test crucial micro-satellite technologies. Snowstorm on Plutoby Dr. Tony Phillips There’s a nip in the air. Outside it’s beginning to snow, the first fall of winter. A few delicate flakes tumble from the sky, innocently enough, but this is no mere flurry. Soon the air is choked with snow, falling so fast and hard it seems to pull the sky down with it. Indeed, that’s what happens. Weeks later when the storm finally ends the entire atmosphere is gone. Every molecule of air on your planet has frozen and fallen to the ground. That was a snowstorm—on Pluto. Once every year on Pluto (1 Pluto-year = 248 Earth-years), around the beginning of winter, it gets so cold that the atmosphere freezes. Air on Pluto is made mainly of nitrogen with a smattering of methane and other compounds. When the temperature dips to about 32 K (-240 C), these molecules crystallize and the atmosphere comes down. “The collapse can happen quite suddenly,” says Alan Stern of the Southwest Research Institute. “Snow begins to fall, the surface reflects more sunlight, forcing quicker cooling, accelerating the snowfall. It can all be over in a few weeks or months.” Researchers believe this will happen sometime during the next 10 to 20 years. Pluto is receding from the warmth of the Sun, carried outward by its 25% elliptical orbit. Winter is coming. So is New Horizons. Stern is lead scientist for the robotic probe, which left Earth in January bound for Pluto. In 2015 New Horizons will become the first spacecraft to visit that distant planet. The question is, will it arrive before the snowstorm? “We hope so,” says Stern. The spacecraft is bristling with instruments designed to study Pluto’s atmosphere and surface. “But we can’t study the atmosphere if it’s not there.” Furthermore, a layer of snow on the ground (“probably a few centimeters deep,” estimates Stern) could hide the underlying surface from New Horizon’s remote sensors. Stern isn’t too concerned: “Pluto’s atmosphere was discovered in 1988 when astronomers watched the planet pass in front of a distant star—a stellar occultation.” The star, instead of vanishing abruptly at Pluto’s solid edge, faded slowly. Pluto was “fuzzy;” it had air. “Similar occultations observed since then (most recently in 2002) reveal no sign of [impending] collapse,” says Stern. On the contrary, the atmosphere appears to be expanding, puffed up by lingering heat from Pluto’s waning summer. Nevertheless, it’s a good thing New Horizons is fast, hurtling toward Pluto at 30,000 mph. Winter. New Horizons. Only one can be first. The race is on…. Find out more about the New Horizons mission at http://pluto.jhuapl.edu. Kids can learn amazing facts about Pluto at http://spaceplace.nasa.gov/en/kids/pluto. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: This artist’s rendering shows how Pluto and two of its possible three moons might look from the surface of the third moon. Credit: NASA/ESA and G. Bacon (STSci) A New View of the Andromeda GalaxyBy Dr. Tony Phillips and Patrick L. Barry This is a good time of year to see the Andromeda galaxy. When the sun sets and the sky fades to black, Andromeda materializes high in the eastern sky. You can find it with your unaided eye. At first glance, it looks like a very dim, fuzzy comet, wider than the full moon. Upon closer inspection through a backyard telescope—wow! It’s a beautiful spiral galaxy. At a distance of “only” 2 million light-years, Andromeda is the nearest big galaxy to the Milky Way, and astronomers know it better than any other. The swirling shape of Andromeda is utterly familiar. Not anymore. A space telescope named GALEX has captured a new and different view of Andromeda. According to GALEX, Andromeda is not a spiral but a ring. GALEX is the “Galaxy Evolution Explorer,” an ultraviolet telescope launched by NASA in 2003. Its mission is to learn how galaxies are born and how they change with age. GALEX’s ability to see ultraviolet (UV) light is crucial; UV radiation comes from newborn stars, so UV images of galaxies reveal star birth—the central process of galaxy evolution. GALEX’s sensitivity to UV is why Andromeda looks different. To the human eye (or to an ordinary visible-light telescope), Andromeda remains its usual self: a vast whirlpool of stars, all ages and all sizes. To GALEX, Andromeda is defined by its youngest, hottest stars. They are concentrated in the galaxy’s core and scattered around a vast ring some 150,000 light years in diameter. It’s utterly unfamiliar. “Looking at familiar galaxies with a new wavelength, UV, allows us to get a better understanding of the processes affecting their evolution,” says Samuel Boissier, a member of the GALEX team at the Observatories of the Carnegie Institution of Washington. Beyond Andromeda lies a whole universe of galaxies—spirals, ellipticals and irregulars, giants and dwarfs, each with its own surprising patterns of star formation. To discover those patterns, GALEX has imaged hundreds of nearby galaxies. Only a few, such as Andromeda, have been analyzed in complete detail. “We still have a lot of work to do,” says Boissier, enthusiastically. GALEX has photographed an even greater number of distant galaxies—“some as far away as 10 billion light-years,” Boissier adds—to measure how the rate of new star formation has changed over the universe's long history. Contained in those terabytes of data is our universe's “life story.” Unraveling it will keep scientists busy for years to come. For more about GALEX, visit http://www.galex.caltech.edu. Kids can see how to make a galactic art project at http://spaceplace.nasa.gov/en/kids/galex/art.shtml. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: The GALEX telescope took this UV image of the Andromeda galaxy (M31), revealing a surprising shape not apparent in visible light. Voices from the CacophonyBy Trudy E. Bell and Dr. Tony Phillips Around 2015, NASA and the European Space Agency plan to launch one of the biggest and most exacting space experiments ever flown: LISA, the Laser Interferometer Space Antenna. LISA will consist of three spacecraft flying in a triangular formation behind Earth. Each spacecraft will beam a laser at the other two, continuously measuring their mutual separation. The spacecraft will be a mind-boggling 5 million kilometers apart (12 times the Earth-Moon distance) yet they will monitor their mutual separation to one billionth of a centimeter, smaller than an atom’s diameter. LISA’s mission is to detect gravitational waves—ripples in space-time caused by the Universe’s most violent events: galaxies colliding with other galaxies, supermassive black holes gobbling each other, and even echoes still ricocheting from the Big Bang that created the Universe. By studying the shape, frequency, and timing of gravitational waves, astronomers believe they can learn what’s happening deep inside these acts of celestial violence. The problem is, no one has ever directly detected gravitational waves: they’re still a theoretical prediction. So no one truly knows what they “sound” like. Furthermore, theorists expect the Universe to be booming with thousands of sources of gravitational waves. Unlike a regular telescope that can point to one part of the sky at a time, LISA receives gravitational waves from many directions at once. It’s a cacophony. Astronomers must figure how to distinguish one signal from another. An outburst is detected! Was it caused by two neutron stars colliding over here or a pair of supermassive black holes tearing each other apart in colliding galaxies over there? “It’s a profound data-analysis problem that ground-based astronomers don’t encounter,” says E. Sterl Phinney, professor of theoretical physics at the California Institute of Technology in Pasadena. Profound, but not hopeless: “We have lots of good ideas and plans that work—in theory,” he says. “The goal now is to prove that they actually work under real conditions, and to make sure we haven't forgotten something.” To that end, theorists and instrument-designers have been spending time together brainstorming, testing ideas, scrutinizing plans, figuring out how they’ll pluck individual voices from the cacophony. And they’re making progress on computer codes to do the job. Says Bonny Schumaker, a member of the LISA team at the Jet Propulsion Laboratory: “It's a challenge more than a problem, and in fact, when overcome, a gift of information from the universe.” For more info about LISA, see lisa.nasa.gov . Kids can learn about black holes and play the new “Black Hole Rescue!” game on The Space Place Web site at http://spaceplace.nasa.gov/en/kids/blackhole/ . This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. By Trudy E. Bell When a massive star reaches the end of its life, it can explode into a supernova rivaling the brilliance of an entire galaxy. What’s left of the star fades in weeks, but its outer layers expand through space as a turbulent cloud of gases. Astronomers see beautiful remnants from past supernovas all around the sky, one of the most famous being the Crab Nebula in Taurus. When a star throws off nine-tenths of its mass in a supernova, however, it also throws off nine-tenths of its gravitational field. Astronomers see the light from supernovas. Can they also somehow sense the sudden and dramatic change in the exploding star’s gravitational field? Yes, they believe they can. According to Einstein’s general theory of relativity, changes in the star’s gravitational field should propagate outward, just like light—indeed, at the speed of light. Those propagating changes would be a gravitational wave. Einstein said what we feel as a gravitational field arises from the fact that huge masses curve space and time. The more massive an object, the more it bends the three dimensions of space and the fourth dimension of time. And if a massive object’s gravitational field changes suddenly—say, when a star explodes—it should kink or wrinkle the very geometry of space-time. Moreover, that wrinkle should propagate outward like ripples radiating outward in a pond from a thrown stone. The frequency and timing of gravitational waves should reveal what’s happening deep inside a supernova, in contrast to light, which is radiated from the surface. Thus, gravitational waves allow astronomers to peer inside the universe’s most violent events—like doctors peer at patients’ internal organs using CAT scans. The technique is not limited to supernovas: colliding neutron stars, black holes and other exotic objects may be revealed, too. NASA and the European Space Agency are now building prototype equipment for the first space experiment to measure gravitational waves: the Laser Interferometer Space Antenna, or LISA. LISA will look for patterns of compression and stretching in space-time that signal the passage of a gravitational wave. Three small spacecraft will fly in a triangular formation behind the Earth, each beaming a laser at the other two, continuously measuring their mutual separation. Although the three ‘craft will be 5 million kilometers apart, they will monitor their separation to one billionth of a centimeter, smaller than an atom’s diameter, which is the kind of precision needed to sense these elusive waves. LISA is slated for launch around 2015. To learn more about LISA, go to http://lisa.jpl.nasa.gov. Kids can learn about LISA and do a gravitational wave interactive crossword at http://spaceplace.nasa.gov/en/kids/lisaxword/lisaxword.shtml.
Caption: LISA’s three spacecraft will be positioned at the corners of a triangle 5 million kilometers on a side and will be able to detect gravitational wave induced changes in their separation distance of as little as one billionth of a centimeter.
by Dr. Tony Phillips In 1977, Voyager 1 left our planet. Its mission: to visit Jupiter and Saturn and to study their moons. The flybys were an enormous success. Voyager 1 discovered active volcanoes on Io, found evidence for submerged oceans on Europa, and photographed dark rings around Jupiter itself. Later, the spacecraft buzzed Saturn’s moon Titan—alerting astronomers that it was a very strange place indeed! —and flew behind Saturn’s rings, seeing what was hidden from Earth. Beyond Saturn, Neptune and Uranus beckoned, but Voyager 1’s planet-tour ended there. Saturn’s gravity seized Voyager 1 and slingshot it into deep space. Voyager 1 was heading for the stars—just as NASA had planned. Now, in 2005, the spacecraft is nine billion miles (96 astronomical units) from the Sun, and it has entered a strange region of space no ship has ever visited before. “We call this region ‘the heliosheath.’ It’s where the solar wind piles up against the interstellar medium at the outer edge of our solar system,” says Ed Stone, project scientist for the Voyager mission at the Jet Propulsion Laboratory. Out in the Milky Way, where Voyager 1 is trying to go, the “empty space” between stars is not really empty. It’s filled with clouds of gas and dust. The wind from the Sun blows a gigantic bubble in this cloudy “interstellar medium.” All nine planets from Mercury to Pluto fit comfortably inside. The heliosheath is, essentially, the bubble’s skin. “The heliosheath is different from any other place we’ve been,” says Stone. Near the Sun, the solar wind moves at a million miles per hour. At the heliosheath, the solar wind slows eventually to a dead stop. The slowing wind becomes denser, more turbulent, and its magnetic field—a remnant of the sun’s own magnetism--grows stronger. So far from Earth, this turbulent magnetic gas is curiously important to human life. “The heliosheath is a shield against galactic cosmic rays,” explains Stone. Subatomic particles blasted in our direction by distant supernovas and black holes are deflected by the heliosheath, protecting the inner solar system from much deadly radiation. Voyager 1 is exploring this shield for the first time. “We’ll remain inside the heliosheath for 8 to 10 years,” predicts Stone, “then we’ll break through, finally reaching interstellar space.” What’s out there? Stay tuned… For more about the twin Voyager spacecraft, visit voyager.jpl.nasa.gov. Kids can learn about Voyager 1 and 2 and their grand tour of the outer planets at spaceplace.nasa.gov/en/kids/vgr_fact3.shtml. Caption: Voyager 1, after 28 years of travel, has reached the heliosheath of our solar system. Improbable Bull's Eyeby Dr. Tony Phillips Picture this: Eighty-eight million miles from Earth, a robot spacecraft plunges into a billowing cloud almost as wide as the planet Jupiter. It looks around. Somewhere in there, among jets of gas and dust, is an icy nugget invisible to telescopes on Earth—a 23,000 mph moving target. The ship glides deeper into the cloud and jettisons its cargo, the “impactor.” Bulls-eye! A blinding flash, a perfect strike. As incredible as it sounds, this really happened on the 4th of July, 2005. Gliding through the vast atmosphere of Comet Tempel 1, NASA’s Deep Impact spacecraft pinpointed the comet’s 3x7-mile wide nucleus and hit it with an 820-lb copper impactor. The resulting explosion gave scientists their first look beneath the crust of a comet. That’s navigation. Credit the JPL navigation team. By sending commands from Earth, they guided Deep Impact within sight of the comet’s core. But even greater precision would be needed to strike the comet’s spinning, oddly-shaped nucleus. On July 3rd, a day before the strike, Deep Impact released the impactor. No dumb hunk of metal, the impactor was a spaceship in its own right, with its own camera, thrusters and computer brain. Most important of all, it had “AutoNav.” AutoNav, short for Autonomous Navigation, is a computer program full of artificial intelligence. It uses a camera to see and thrusters to steer—no humans required. Keeping its “eye” on the target, AutoNav guided the impactor directly into the nucleus. The system was developed and tested on another “Deep” spacecraft: Deep Space 1, which flew to asteroid Braille in 1999 and Comet Borrelly in 2001. The mission of Deep Space 1 was to try out a dozen new technologies, among them an ion propulsion drive, advanced solar panels and AutoNav. AutoNav worked so well it was eventually installed on Deep Impact. “Without AutoNav, the impactor would have completely missed the nucleus,” says JPL’s Ed Riedel, who led the development of AutoNav on Deep Space 1 and helped colleague Dan Kubitschek implement it on Deep Impact. En route to the nucleus, AutoNav “executed three maneuvers to keep the impactor on course: 90, 35, and 12.5 minutes before impact,” says Riedel. The nearest human navigators were 14 light-minutes away (round trip) on Earth, too far and too slow to make those critical last-minute changes. Having proved itself with comets, AutoNav is ready for new challenges: moons, planets, asteroids … wherever NASA needs an improbable bulls-eye. Dr. Marc Rayman, project manager for Deep Space 1, describes the validation performance of AutoNav in his mission log (http://nmp.nasa.gov/ds1/arch/mrlog13.html) (also check mrlog24.html and the two following). Also, for junior astronomers, the Deep Impact mission is described here (http://spaceplace.nasa.gov/en/kids/deepimpact/deepimpact.shtml). This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: Comet Tempel 1, as seen by the Deep Impact impactor’s camera. Three last-minute AutoNav-controlled impact correction maneuvers enabled the Impactor to hit the bulls-eye. Newest Weather Sentry Takes Up Watchby Patrick L. Barry Today, we've become accustomed to seeing images of the Earth's swirling atmosphere from space every night on the evening news. Before 1960, no one had ever seen such images. The first-ever weather satellite was launched that year, kicking off a long line of weather satellites that have kept a continuous watch on our planet's fickle atmosphere—45 years and counting! The high-quality, extended weather forecasts that these satellites make possible have become an indispensable part of our modern society, helping commercial aircraft, recreational boaters, and even military operations avoid unnecessary risk from hazardous weather. But satellites don't last forever. Parts wear out, radiation takes its toll, and atmospheric drag slowly pulls the satellite out of orbit. Many weather satellites have a design life of only 2 years, though often they can last 5 or 10 years, or more. A steady schedule of new satellite launches is needed to keep the weather report on the news each night. In May 2005, NASA successfully launched the latest in this long line of weather satellites. Dubbed NOAA-N at launch and renamed NOAA-18 once it reached orbit, this satellite will take over for the older satellite NOAA-16, which was launched in September 2000. ”NOAA always keeps at least two satellites in low-Earth orbit, circling the poles 14 times each day,” explains Wilfred E. Mazur, Polar Satellite Acquisition Manager, NOAA/NESDIS. “As Earth rotates, these satellites end up covering Earth’s entire surface each day. In fact, with two satellites in orbit, NOAA covers each spot on the Earth four times each day, twice during the day and twice at night,” Mazur says. By orbiting close to Earth (NOAA-18 is only 870 km above the ground),
these “low-Earth orbit” satellites provide a detailed
view of the weather. The other type of weather satellite, “geosynchronous,”
orbits much farther out at 35,786 Find out more about NOAA-18 and the history of polar-orbiting weather satellites at http://goespoes.gsfc.nasa.gov/poes. For kids and anyone else curious about the concept, the difference between polar and geosynchronous orbits is explained at http://spaceplace.nasa.gov/en/kids/goes/goes_poes_orbits.shtml . This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: by Patrick L. Barry How on earth could someone simply pick up one of NASA’s giant Deep Space Network (DSN) antennas—a colossal steel dish 12 stories high and 112 feet across that weighs more than 800,000 pounds—move it about 80 yards, and delicately set it down again? Yet that's exactly what NASA engineers recently did. One of the DSN dishes near Madrid, Spain, needed to be moved to a new pad. And it had to be done gingerly; the dish is a sensitive scientific instrument full of delicate electronics. Banging it around would not do. “It was a heck of a challenge,” says Benjamin Saldua, the structural engineer at JPL who was in charge of the move. “But thanks to some very careful planning, we pulled it off without a problem!” The Deep Space Network enables NASA to communicate with probes exploring the solar system. Because Earth is constantly rotating, a single antenna on the ground can communicate with a probe for only part of the day, when the probe is overhead. By placing large dishes at three locations around the planet—Madrid, California, and Australia—NASA can maintain contact with spacecraft around the clock. To move the Madrid dish, NASA called in a company from the Netherlands named Mammoet, which specializes in moving massive objects. (Mammoet is the Dutch word for “mammoth.”) On a clear day (bad weather might blow the dish over!), they began to slowly lift the dish. Hydraulic jacks at all four corners gradually raised the entire dish to a height of about 4.5 feet. Then Mammoet engineers positioned specialized crawlers under each corner. Each crawler looks like a mix between a flatbed trailer and a centipede: a flat, load-bearing surface supported by 24 wheels on 12 independently rotating axes, giving each crawler a maximum load of 194 tons! One engineer took the master joystick and steered the whole package in its slow crawl to the new pad, never exceeding the glacial speed of 3 feet per minute. The four crawlers automatically stayed aligned with each other, and their independently suspended wheels compensated for unevenness in the ground. Placement on the new pad had to be perfect, and the alignment was tested with a laser. To position the dish, believe it or not, Mammoet engineers simply followed a length of string tied to the pad’s center pivot where the dish was gently lowered. It worked. So much for “impossible.” Find out more about the DSN at http://deepspace.jpl.nasa.gov/dsn/ . Kids can learn about the amazing DSN antennas and make their own “Super Sound Cone” at The Space Place, http://spaceplace.nasa.gov/en/kids/tmodact.shtml. Caption: Seeing in the Dark with Spitzerby Patrick Barry and Tony Phillips Have you ever gotten up in the middle of the night, walked to the bathroom and, in the darkness, tripped over your dog? A tip from the world of high-tech espionage: next time use night-vision goggles. Night vision goggles detect heat in the form of infrared radiation—a “color” normally invisible to the human eye. Wearing a pair you can see sleeping dogs, or anything that’s warm, in complete darkness. This same trick works in the darkness of space. Much of the exciting action in the cosmos is too dark for ordinary telescopes to see. For example, stars are born in the heart of dark interstellar clouds. While the stars themselves are bright, their birth-clouds are dense, practically impenetrable. The workings of star birth are thus hidden. That's why NASA launched the Spitzer Space Telescope into orbit in 2003. Like a giant set of infrared goggles, Spitzer allows scientists to peer into the darkness of space and see, for example, stars and planets being born. Dogs or dog stars: infrared radiation reveals both. There is one problem, though, for astronomers. “Infrared telescopes on the ground can't see very well,” explains Michelle Thaller, an astronomer at the California Institute of Technology. “Earth's atmosphere blocks most infrared light from above. It was important to put Spitzer into space where it can get a clear view of the cosmos.” The clear view provided by Spitzer recently allowed scientists to make a remarkable discovery: They found planets coalescing out of a disk of gas and dust that was circling—not a star—but a “failed star” not much bigger than a planet! Planets orbiting a giant planet? The celestial body at the center of this planetary system, called OTS 44, is only about 15 times the mass of Jupiter. Technically, it’s considered a “brown dwarf,” a kind of star that doesn’t have enough mass to trigger nuclear fusion and shine. Scientists had seen planetary systems forming around brown dwarfs before, but never around one so small and planet-like. Spitzer promises to continue making extraordinary discoveries like this one. Think of it as being like a Hubble Space Telescope for looking at invisible, infrared light. Like Hubble, Spitzer offers a view of the cosmos that’s leaps and bounds beyond anything that came before. Spitzer was designed to operate for at least two and a half years, but probably will last for five years or more. For more about Spitzer and to see the latest images, go to http://www.spitzer.caltech.edu/spitzer. Kids and grown-ups will enjoy browsing common sights in infrared and visible light at the interactive infrared photo album on The Space Place, http://spaceplace.nasa.gov/en/kids/sirtf1/sirtf_action.shtml. View the artist’s rendering of brown dwarf OTS44 with its rotating planetary disk. Back to TopAsian Tsunami Seen from Spaceby Patrick L. Barry When JPL research scientist Michael Garay first heard the news that a tsunami had struck southern Asia, he felt the same shock and sadness over the tremendous loss of human life that most people certainly felt. Later, though, he began to wonder: were these waves big enough to see from space? So he decided to check. At JPL, Garay analyzes data from MISR—the Multi-angle Imaging SpectroRadiometer instrument aboard NASA's Terra satellite. He scoured MISR images from the day of the tsunami, looking for signs of the waves near the coasts of India, Sri Lanka, Indonesia, and Thailand. Looking at an image of the southern tip of Sri Lanka taken by one of MISR's angled cameras, he spotted the distinct shape of waves made visible by the glint of reflected sunlight. They look a bit like normal waves, except for their scale: These waves were more than a kilometer wide! Most satellites have cameras that point straight down. From that angle, waves are hard to see. But MISR is unique in having nine cameras, each viewing Earth at a different angle. “We could see the waves because MISR's forward-looking camera caught the reflected sunlight just right,” Garay explains. In another set of images, MISR’s cameras caught the white foam of tsunami waves breaking off the coast of India. By looking at various angles as the Terra satellite passed over the area, MISR’s cameras snapped seven shots of the breaking waves, each about a minute apart. This gave scientists a unique time-lapse view of the motion of the waves, providing valuable data such as the location, speed, and direction of the breaking waves. Realizing the importance of the find, Garay contacted Vasily Titov at the National Oceanic and Atmospheric Administration’s Pacific Marine Environmental Laboratory in Seattle, Washington. Titov is a tsunami expert who had made a computer simulation of the Asian tsunami. ”Because the Indian Ocean doesn't have a tsunami warning system, hardly any scientific measurements of the tsunami's propagation exist, making it hard for Dr. Titov to check his simulations against reality,” Garay explains. “Our images provide some important data points to help make his simulations more accurate. By predicting where a tsunami will hit hardest, those simulations may someday help authorities issue more effective warnings next time a tsunami strikes.” Find out more about MISR and see the latest images at http://www-misr.jpl.nasa.gov/. Kids can read their own version of the MISR tsunami story at http://spaceplace.nasa.gov/en/kids/misr_tsunami. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. CAPTION: This December 26, 2004, MISR image of the southern tip of Sri Lanka was taken several hours after the first tsunami wave hit the island. It was taken with MISR’s 46° forward-looking camera. Utterly Alienby Dr. Tony Phillips There's a planet in our solar system so cold that in winter its nitrogen atmosphere freezes and falls to the ground. The empty sky becomes perfectly clear, jet-black even at noontime. You can see thousands of stars. Not one twinkles. The brightest star in the sky is the Sun, so distant and tiny you could eclipse it with the head of a pin. There's a moon, too, so big you couldn't blot it out with your entire hand. Together, moonlight and sunshine cast a twilight glow across the icy landscape revealing . . . what? twisted spires, craggy mountains, frozen volcanoes? No one knows, because no one has ever been to Pluto. "Pluto is an alien world," says Alan Stern of the Southwest Research Institute in Colorado. "It's the only planet never visited or photographed by NASA space probes." That's about to change. A robot-ship called New Horizons is scheduled to blast off for Pluto in January 2006. It's a long journey: More than 6 billion kilometers (about 3.7 billion miles). New Horizons won't arrive until 2015. "I hope we get there before the atmosphere collapses," says Stern, the mission's principal investigator. Winter is coming, and while it's warm enough now for Pluto's air to float, it won't be for long. Imagine seeing a planet's atmosphere collapse. New Horizons might! "This is a flyby mission," notes Stern. “Slowing the spacecraft down to orbit Pluto would burn more fuel than we can carry." New Horizons will glide past the planet furiously snapping pictures. "Our best images will resolve features the size of a house," Stern says. The cameras will also target Pluto's moon, Charon. Charon is more than half the size of Pluto, and the two circle one another only 19,200 kilometers (12,000 miles) apart. (For comparison, the Moon is 382,400 kilometers [239,000 miles] from Earth.) No wonder some astronomers call the pair a "double planet." Researchers believe that Pluto and Charon were created billions of years ago by some terrific impact, which split a bigger planet into two smaller ones. This idea is supported by the fact that Pluto and Charon spin on their sides like sibling worlds knocked askew. Yet there are some curious differences: Pluto is bright; Charon is darker. Pluto is covered with frozen nitrogen; Charon by frozen water. Pluto has an atmosphere; Charon might not. "These are things we plan to investigate," says Stern. Two worlds. So alike, yet so different. So utterly alien. Stay tuned for New Horizons. Find out more about the New Horizons mission at http://pluto.jhuapl.edu/. Kids can learn amazing facts about Pluto at http://spaceplace.nasa.gov/en/kids/pluto. This article was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. CAPTION: New Horizons spacecraft will get a gravity assist from Jupiter on its long journey to Pluto-Charon. A Different Angle on Climate Changeby Patrick L. Barry The smog is overhead as well, but it's much harder to see. Why is there such a difference? It comes down to viewing angles: A vertical line straight up through the atmosphere crosses much less air than a line angled toward the horizon. Less air means less smog, so the sky overhead looks blue. On the other hand, when you look toward the horizon, you're looking through a lot more air. The smog is easier to see. A one-of-a-kind sensor aboard NASA's Terra satellite capitalizes on this angle effect to get a better view of how clouds and air pollutants scatter and absorb sunlight. By doing so, this sensor-called the Multi-angle Imaging SpectroRadiometer (MISR for short)-is helping scientists fill in a major piece of the climate change puzzle. Most satellite instruments look only straight down at the Earth. Layers of airborne particles (called aerosols) and smog are harder to see with this vertical view, and clouds often appear only as two-dimensional sheets of white. Clouds and aerosols both can reflect incoming sunlight back out to space, thus cooling the planet. But they can also absorb sunlight and trap heat rising from below, thus helping warm the planet. What is the net effect? MISR helps scientists figure this out by looking at the atmosphere at several angles-nine to be exact. Its nine cameras fan out across a range of angles from steeply looking forward (70.5 degrees from vertical), to straight down, to the same steep angle backwards. As the Terra satellite passes over a region, the cameras successively view the region at nine different angles. From these data, scientists can construct a three-dimensional picture of the cloud cover, revealing much more about cloud dynamics than a flat image alone. They can also see light bouncing off aerosol pollution from nine different directions, thus getting a fuller picture of how aerosols scatter sunlight. And they can even spot thin layers of heat-trapping air pollutants that might go unnoticed by other satellites. All this information comes just from looking at the atmosphere from a different angle. For more information, see http://www- misr.jpl.nasa.gov . Kids can learn about MISR, see MISR images, and do an online MISR crossword at http://spaceplace.nas a.gov/en/kids/misr_xword/misr_xword2.shtml . Caption: A Summer Vacation Tracking Down UFOsErin Schumacher's summer job for NASA was to look for UFOs. Erin is a 16-year-old high school student from Redondo Beach, California, attending the California Academy of Mathematics and Science in Carson. She was one of ten students selected to work at NASA's Jet Propulsion Laboratory (JPL) in Pasadena as part of the Summer High School Apprenticeship Research Program, or SHARP. But is studying UFOs a useful kind of NASA research? Well, it is when they are "unidentified flashing objects" that appear in certain images of Earth from space. Erin worked with scientists on the Multi-angle Imaging SpectroRadiometer MISR) project to track down these mysterious features. MISR is one of five instruments onboard the Earth-orbiting Terra satellite. MISR's nine separate cameras all point downward at different angles, each camera in turn taking a picture of the same piece of Earth as the satellite passes overhead. Viewing the same scene through the atmosphere at different angles gives far more information about the aerosols, pollution, and water vapor in the air than a single view would give. Ground features may also look slightly or dramatically different from one viewing angle to another. Erin's job was to carefully examine the pictures looking for any flashes of light that might be visible from just one of the nine angles. Such flashes are caused by sunlight bouncing off very reflective surfaces and can be seen if a camera is pointed at just the right angle to catch them. Because the satellite data contain precise locations for each pixel in the images, Erin could figure out exactly where a flashing object on the ground should be. Her job was then to figure out exactly what it was that made the flash-in particular, to see if she could distinguish man-made objects from natural ones. When Erin began working at JPL, scientists on the MISR project had already identified two large flashes out in the middle of the Mojave Desert in Southern California. These turned out to be from solar power generating stations. Soon, Erin began finding flashes all over the place. She learned how to apply her math knowledge to figuring out how the objects would have to be oriented in order to be seen by a particular MISR camera. One time, she and a team of MISR scientists and students went on a field trip to the exact locations of some flashes, where they found greenhouses, large warehouses with corrugated metal roofs, a glass-enclosed shopping mall, and a solar-paneled barn. For some flashes, they could find nothing at all. Those remain "UFOs" to this day! Learn more about Earth science applications of MISR at www-misr.jpl.nasa.gov. Kids can do an online MISR crossword at spaceplace.nasa.gov/en/kids/misr_xword/misr_xword1.shtml. This article was written by Diane K. Fisher. It was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration Caption: Two cameras on MISR made these images of the same part of the Mojave Desert. The camera pointed at an angle of 26 forward saw the flashes from two solar electric power generating stations. These objects are nearly invisible at the other angle. Back to TopWaiting for Cassini's "Safe Arrival" CallThe evening of June 30, 2004, was nail-biting time at Cassini Mission Control. After a seven-year journey that included gravity assist flybys of Venus, Earth, and Jupiter, Cassini had finally arrived at Saturn. A 96-minute burn of its main engine would slow it down enough to be captured into orbit by Saturn's powerful gravitational field. Too short a burn and Cassini would keep going toward the outer reaches of the solar system. Too long a burn and the orbit would be too close and fuel reserves exhausted. According to Dave Doody, a Cassini Mission Controller at the Jet Propulsion Laboratory (JPL) in Pasadena, California, there was a good chance the Earth-bound Cassini crew would have to wait hours to learn whether or not the burn was successful. Of the three spacecraft-tracking Deep Space Network (DSN) complexes around the globe, the complex in Canberra, Australia, was in line to receive Cassini's signal shortly after the beginning of the burn. However, winds of up to 90 kilometers per hour had been forecast. In such winds, the DSN's huge dish antennas must be locked into position pointed straight up and cannot be used to track a tiny spacecraft a billion miles away as Earth turns on its axis. "The winds never came," notes Doody. The DSN complex at Goldstone, California, was tracking the carrier signal from Cassini's low-gain antenna (LGA) when the telltale Doppler shift in the LGA signal was seen, indicating the sudden deceleration of the spacecraft from the successful ignition of the main engine. Soon thereafter, however, Goldstone rotated out of range and Canberra took the watch. After completion of the burn, Cassini was programmed to make a 20-second "call home" using its high-gain antenna (HGA). Although this HGA signal would contain detailed data on the health of the spacecraft, mission controllers would consider it a bonus if any of that data were actually captured. Mostly, they just wanted to see the increase in signal strength to show the HGA was pointed toward Earth and be able to determine the spacecraft's speed from the Doppler data. If possible, they also wanted to try to lock onto the signal with DSN's closed-loop receiver, a necessary step for extracting engineering data. Normally it takes around one minute to establish a lock on the HGA signal once a DSN station rotates into range. Having only 20 second's worth of signal to work with, the DSN not only established a lock within just a few seconds, but extracted a considerable amount of telemetry during the remaining seconds. "The DSN people bent over backwards to get a lock on that telemetry signal. And they weren't just depending on the technology. They really know how to get flawless performance out of it. They were awesome," remarks Doody. Find out more about the DSN from JPL's popular training document for mission controllers, Basics of Space Flight (www.jpl.nasa.gov/basics) and the DSN website at deepspace.jpl.nasa.gov/dsn. For details of the Cassini Saturn orbit insertion, see www.jpl.nasa.gov/basics/soi. Kids can check out The Space Place at spaceplace.nasa.gov/en/kids/dsn_fact1.shtml to learn about the amazing ability of the DSN antennas to detect the tiniest spacecraft signals. This article was written by Diane K. Fisher. It was provided by the Jet Propulsion Laboratory, California Institute of Technology, under a contract with the National Aeronautics and Space Administration. Caption: |
